CLIMATE CONTROL CLIMATE CONTROL WALL SPLIT TYPE 66129902621 OWNER'S MANUAL Models: CCS-24HR4LW Thank you for choosing this air conditioner for correct operation, please read this owner's manual carefully before operating the unit and keeps it carefully for consultation.
CONTENTS Operation and maintenance ■ ■ ■ ■ ■ ■ Notices for operation ．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．１ Notices for use ．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．４ Names and functions of each ． part ．．．．．．．．．．．．．．．．．．．．．．５ Operation of wireless remote control ．．．．．．．．．．．．．．．．．．．．．６ ．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．９ Troubleshooting ．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．１１ Clean and care Installation service ■ ■ ■ ■ ■ Notices for installation ．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．１４ Installation dimension diagram ．．．
Operation and maintenance-Notices for operation Please read the following carefully before operating. WARNING When having a burning smell Don't operate the air conditioner Never cut off or damage power cables and control wires. If the power or smoke, please turn off the power with wet hands. cable and signal control wire were supply and contact with the service damaged, change them by professional center of CLIMATE CONTROL.
Notices for operation ★ Earth:The ground be connected! ★ Be sure to pull out the power ★ Select the most appropriate templug when not using the air conditioner for a long time. perature. Keep room cooer than outside about ５ ℃ If not, please ask the qualified personnel to install. Furthermore, don't connect each wire to the gas pipe, water pipe, drainage pipe or any other improper places. Otherwise, the accumulated dust It can preclude the electricity wasted. may cause fire or electric shock.
Notices for operation The power cords of this air conditioner adopt X-type connection, please don't cut off or damage the power cords and control cords. If they are damaged, please ask the qualified personnel to ★ To adjust the airflow and direction appropriately. At operating the louvers of air conditioner could be adjusted by pressing the SWING button on wireless remote control to change the airflow direction. change them.
Notices for use Working principle and special functions for cooling Principle: Air conditioner absorbs heat in the room and transmit to outdoor and discharged, so that indoor ambient temperature decreased, its cooling capacity will increase or decrease by outdoor ambient temperature.
Names and functions of each part Indoor Unit Air inlet ⑶ ⑴ ⑵ Air Outlet Set Temp Heating (This indicator is black for singlecooling unit).
Operation of wireless remote control Name and function of wireless remote control Note: Be sure that there are no obstructions between receiver and remote controoler; Don't drop or throw the remote control; Don't let any liquid in the remote control and put the remote control directly under the sunlight or any place where is very hot. Signal transmitter ON/OFF ON/OFF button ON/OFF button Press it to turn on the unit, repress it to turn off the unit.
Operation of wireless remote control Names and functions of wireless remote control This wireless remote control is universal, and it could be used for many units, some buttons of this control which are not available to this unit will not be described below. TIMER OFF TIMER OFF button TIMER OFF button Press this button once enter into the TIMER OFF setting. TEMP. TEMP. Adjusting , the temp. in In COOL, DRY,FAN or HEAT modes, press these two buttons, could set the temp.
Operation of wireless remote control Guide for operation procedure-Optional operation The general procedure: １．After powered on, there is a warning tone sound by buzzer, all patterns displayer of indoor unit displayed, a few seconds later, all the display will automatically turned off, except the POWER/ RUN light, The POWER/RUN running light turns red, the unit is await.
Clean and care Caution ● Turn power off and pull out the power plug before cleaning air conditioner, or it may cause electric shock. ● Never sprinkle water on the indoor unit and the outdoor unit for cleaning because it can cause an electric shock. ● Volatile liquid (e.g. thinner or gasoline) will damage the air conditioner. (So wipe the units with a dry soft cloth, or a cloth slightly moistened with water or cleanser.
Clean and care ③ Insert the air filter Reinsert the filters along the direction of arrowhead, and then to cover the cover and clasp it. Check before use ① Be sure that nothing obstructs the air outlet and intake vents. ② Check that whether ground wire is properly connected or not. ③ Check that whether the batteries of air conditioner are changed or not. ④ Check that whether the installation stand of the outdoor unit is damaged or not. If damaged, please contact the dealer.
Troubleshooting CAUTION Don't attempt to repair the air conditioner by yourself, it can cause an electric shock or fire. Please check the following items before asking for repair, it can save your time and money. Phenomenon Troubleshooting Not operate immediately when the air conditioner is restarted. waiting Once the air conditioner is stopped, it will not operate in approximately 3minutes to protect itself. There's unusual smell blowing from the outlet after operation is started.
Troubleshooting Troubleshooting Phenomenon The unit can not run Has the power been shut down? Is the circuit protection device tripped off or not? ● Is voltage higher or lower? (Tested by professionals) ● Is the Timer correctly used? ● ● Break off Cooling(Heating) efficiency is not good. Is Temp.
Troubleshooting Phenomenon Indoor unit cannot deliver air Moisture on air outlet vent Troubleshooting ● In HEAT mode, when the temperature of indoor heat exchanger is very low, that will stop deliver air in order to prevent blowing cool air. ● In HEAT mode, when the outdoor temperature is low or high humidity, there are much frost be formed on the outdoor heat exchanger, that the unit will automatically defrost, indoor unit stop blowing air for 3-12min.
Installation service- Notices for installation Important Notices １．The unit installation work must be done by qualified personnel according to the local rules and this manual. 2.Before installating, please contact with local authorized maintenance center, if unit is not installed by the authorized maintenance center, the malfunction may not solved, due to discommodious contacts. 3.
Notices for installation 2. Select a location where there should be sufficient ventilation. 3. Select a location where there should be no obstructions cover the inlet and outlet vent. 4. The location should be able to withstand the full weight and vibration of the outdoor unit and permit safe installation. 5. Select a dry place, but do not expose under the direct sunlight or strong wind. 6.
Installation dimension diagram Installation dimension diagram From the ceiling Over 15cm Over 15cm From the Wall Over 15cm From the Wall Over 300cm Over Above the floor Over 50cm Discharge Side 250cm er Ov Over 30cm From the Wall 2 er Ov cm 30 Over 50cm 00 cm Discharge Side From the Wall 572(m m) １６ 37 m 8( m)
Installation Service- Install indoor unit Install the rear panel １. Always mount the rear panel horizontally. As the water drainage pipe at the left, when adjusting the rear panel, this side should not be too high; the right side should be slightly high. Wall Mark on the middle of it ２．Fix the rear panel on the selected Wall Gradienter location.
Install indoor unit NOTE: When connecting the electric wire if the wire length is not enough, please contact with the authorized service shop to buy a exclusive electric wire that is long enough and the joint on the wire are not allowed. ● The electric wiring must be correctly connected, wrong connection may cause spare parts malfunction. ● Tighten the terminal screw in order to prevent loose. ● After tighten the screw, slightly pull the wire and confirm whether is it firm or not.
Installation service- Install outdoor unit Electric wiring １．Remove the front side plate. ２．Take off wire clamp. Connect and fix power connect cord to terminal of line bank. Wiring should fit that of indoor unit. ３．Fix the power connection cable with wire clamp, for cooling Brown Blue Black and heating unit, then use the wire clamp to fix the signal control wire, then connect the corresponding connector. ４．Ensure wire has been fixed well.
Check after installation and test operation Check after installation Items to be checked Possible malfunction Has it been fixed firmly? The unit may drop, shake or emit noise. Have you done the refrigerant leakage test? It may cause insufficient cooling(heating) capacity. Is heat insulation sufficient? It may cause condensation and dripping. Is water drainage well? It may cause condensation and dripping.
