www.climacoolcorp.com

Control Access Display Table

Page 7 of 15 10/9/2013

Product Line: UGW

Software Version: UGW-H.08B.13

Chiller Type: COOLING 4 PIPE

LOCAL ACCESS DISPLAY TABLE

Mod Active Status DisPr Alm SP:

Module Hi Disch Press Setpt mod_hi_disch_press_sp_5

200.0 FALSE

Default Head Pressure Value:

Module Default Head Pressure mod_default_hp_5

70.0 50 650 TRUE

Head Pressure Min Adj Value:

Module Head Pressure Positive

Adj

mod_hp_pos_adj_5

60.0 50 650 TRUE

SucPr Alm 134a

Low Suction Press Sp 134a mod_lo_suc_press_sp_134_5

15.0 2 200 TRUE

SucPr Alm 410a

Low Suction Press Sp 410a mod_lo_suc_press_sp_410_5

94.0 2 150 TRUE

/SucPr Alm 407C

Low Suction Press Sp 407C mod_lo_suc_press_sp_407_5

50.0 2 120 TRUE

Mod Active Status SucPr Alm SP:

Module Low Suction Press Setpt mod_low_press_sp_5

15.0 FALSE

Mod SucPr Time Delay Before Alarm:

Module LO SUC PSI Delay mod_lo_suc_psi_delay_5

30.0 0 999 TRUE

Mod Extra Low SucPr Alm SP:

Module LO-LO SUC PSI Setpoint mod_low_low_press_sp_5

0.0 -5 50 TRUE

Low Dis Pr Ctrl SP R134a

Low Head Press Sp 134a mod_lo_disch_press_sp_134_5

100.0 20 350 TRUE

Low Dis Pr Ctrl SP R410a

Low Head Press Sp 410a mod_lo_disch_press_sp_410_5

220.0 50 450 TRUE

Low Dis Pr Ctrl SP R407C

Low Head Press Sp 407 mod_lo_disch_press_sp_407_5

150.0 50 300 TRUE

Mod Active Status Low DisPr Alm SP:

Module Lo Disch Press Setpt mod_lo_disch_press_sp_5

100.0 FALSE

M DisTp Alm SP

Module Hi Disch Temp mod_hi_disch_tmp_5

225.0 100 325 TRUE

/M SucTp Alm SP

Module Low Suction Temp mod_lo_suction_tmp_5

32.0 10 75 TRUE

LINK(S): PREV, SYSTEM SETUP, HOME

LO SUC SPRHT & LO DISCH SPRHT SETPTS

Screen Display

Content BACnet Object

Default Min. Value Max. Value Editable

CoolLogic Suc&Dis SuperHt Alrm Setpts

M Lo DisSuprHt

Module Low Disch SuperHt

Setpt

mod_lo_disc_supht_sp_5

15.0 TRUE

/M Lo SucSuprHt

Module Low Suct SuperHt Setpt mod_lo_suc_supht_sp_5

2.0 TRUE

LINK(S): PREV, SYSTEM SETUP, HOME

FREEZE TARGET SETPOINT

Screen Display

Content BACnet Object

Default Min. Value Max. Value Editable

CoolLogic Freeze Target Setpts Menu

Freeze TrgSp (F)

Module Freeze Target Setpoint mod_freeze_trg_sp_5

36.0 0 50 TRUE

LINK(S): PREV, SYSTEM SETUP, HOME

COMPR MIN MAX RUN TIMES

Screen Display

Content BACnet Object

Default Min. Value Max. Value Editable

Compressor Min & Max Run Times

Compr Minimum Run Time (sec)

Module Compr Min Run Time mod_cmpr_min_run_5

120.0 1 999 TRUE

Compr Minimum Off Time (sec)

Module Compr Min Off Delay mod_cmpr_off_delay_5

150.0 1 999 TRUE

LINK(S): PREV, ALARM, SYSTEM SETUP, CLOCKSET

COMPR ALARM DELAY

Screen Display

Content BACnet Object

Default Min. Value Max. Value Editable

CoolLogic Compr Alarm Delays

Mod Alm Delay

Module Compr Status Alarm

Delay

mod_comp_stat_alm_delay_5

9999.0 5 999 TRUE

LINK(S): PREV, SYSTEM SETUP, HOME, ALARM

MODULE WATER TEMP LIMITS

Screen Display

Content BACnet Object

Default Min. Value Max. Value Editable

CoolLogic Module Water Out Temp Limits

Mod Evap Wat Out Lo Limit: (F)

Module Freeze Target Setpoint mod_freeze_trg_sp_5

36.0 0 165 TRUE

Mod Evap Wat Out Hi Limit: (F)

Module High Evaporator Leaving

Temp at Startup

mod_high_evap_lvg_tmp_5

90.0 0 165 TRUE

Mod Cond Wat Out Lo Limit: (F)

Module Low Condenser Leaving

Temp. Setpoint

mod_low_cond_lvg_sp_5

50.0 0 165 TRUE

Mod Cond Wat Out Hi Limit:

HI WTR OUT UGW

UCW Module High Cond Leaving

Temp at Startup

ugw_mod_cwr_trg_sp_5

118.0 10 165 TRUE

/HI WTR OUT UGH

UCH Module High Cond Leaving

Temp at Startup

ugh_mod_cwr_trg_sp_5

140.0 10 165 TRUE

Mod Cond Wat Out Hi Limit: (F)

Module Leaving Cond Water

Temp Setpoint

mod_cwr_trg_sp_5

118.0 10 165 FALSE

LINK(S): PREV, SYSTEM SETUP, HOME

SCREW COMP ALARM SETPOINTS

Screen Display

Content BACnet Object

Default Min. Value Max. Value Editable

Screw Comp Alarm Setpoints

Screw Comp Max Amps Allowed 460:

Compressor Max Amps mod_max_amps_sp_5

105.0 1 999 TRUE

Winding Temp Correlation to ohms:

Compr Max Winding Temp

Sensor Resis

mod_max_wind_sens_ohms_5

275.0 1 999 TRUE

LINK(S): PREV, SYSTEM SETUP, HOME, ALARM

SERVICE MENU SETUP FN7

Screen Display

Content BACnet Object

Default Min. Value Max. Value Editable

Page 7 of 15 10/9/2013

Product Line: UGW

Software Version: UGW-H.08B.13

Chiller Type: COOLING 4 PIPE

LOCAL ACCESS DISPLAY TABLE

Mod Active Status DisPr Alm SP:

Module Hi Disch Press Setpt mod_hi_disch_press_sp_5

200.0 FALSE

Default Head Pressure Value:

Module Default Head Pressure mod_default_hp_5

70.0 50 650 TRUE

Head Pressure Min Adj Value:

Module Head Pressure Positive

Adj

mod_hp_pos_adj_5

60.0 50 650 TRUE

SucPr Alm 134a

Low Suction Press Sp 134a mod_lo_suc_press_sp_134_5

15.0 2 200 TRUE

SucPr Alm 410a

Low Suction Press Sp 410a mod_lo_suc_press_sp_410_5

94.0 2 150 TRUE

/SucPr Alm 407C

Low Suction Press Sp 407C mod_lo_suc_press_sp_407_5

50.0 2 120 TRUE

Mod Active Status SucPr Alm SP:

Module Low Suction Press Setpt mod_low_press_sp_5

15.0 FALSE

Mod SucPr Time Delay Before Alarm:

Module LO SUC PSI Delay mod_lo_suc_psi_delay_5

30.0 0 999 TRUE

Mod Extra Low SucPr Alm SP:

Module LO-LO SUC PSI Setpoint mod_low_low_press_sp_5

0.0 -5 50 TRUE

Low Dis Pr Ctrl SP R134a

Low Head Press Sp 134a mod_lo_disch_press_sp_134_5

100.0 20 350 TRUE

Low Dis Pr Ctrl SP R410a

Low Head Press Sp 410a mod_lo_disch_press_sp_410_5

220.0 50 450 TRUE

Low Dis Pr Ctrl SP R407C

Low Head Press Sp 407 mod_lo_disch_press_sp_407_5

150.0 50 300 TRUE

Mod Active Status Low DisPr Alm SP:

Module Lo Disch Press Setpt mod_lo_disch_press_sp_5

100.0 FALSE

M DisTp Alm SP

Module Hi Disch Temp mod_hi_disch_tmp_5

225.0 100 325 TRUE

/M SucTp Alm SP

Module Low Suction Temp mod_lo_suction_tmp_5

32.0 10 75 TRUE

LINK(S): PREV, SYSTEM SETUP, HOME

LO SUC SPRHT & LO DISCH SPRHT SETPTS

Screen Display

Content BACnet Object

Default Min. Value Max. Value Editable

CoolLogic Suc&Dis SuperHt Alrm Setpts

M Lo DisSuprHt

Module Low Disch SuperHt

Setpt

mod_lo_disc_supht_sp_5

15.0 TRUE

/M Lo SucSuprHt

Module Low Suct SuperHt Setpt mod_lo_suc_supht_sp_5

2.0 TRUE

LINK(S): PREV, SYSTEM SETUP, HOME

FREEZE TARGET SETPOINT

Screen Display

Content BACnet Object

Default Min. Value Max. Value Editable

CoolLogic Freeze Target Setpts Menu

Freeze TrgSp (F)

Module Freeze Target Setpoint mod_freeze_trg_sp_5

36.0 0 50 TRUE

LINK(S): PREV, SYSTEM SETUP, HOME

COMPR MIN MAX RUN TIMES

Screen Display

Content BACnet Object

Default Min. Value Max. Value Editable

Compressor Min & Max Run Times

Compr Minimum Run Time (sec)

Module Compr Min Run Time mod_cmpr_min_run_5

120.0 1 999 TRUE

Compr Minimum Off Time (sec)

Module Compr Min Off Delay mod_cmpr_off_delay_5

150.0 1 999 TRUE

LINK(S): PREV, ALARM, SYSTEM SETUP, CLOCKSET

COMPR ALARM DELAY

Screen Display

Content BACnet Object

Default Min. Value Max. Value Editable

CoolLogic Compr Alarm Delays

Mod Alm Delay

Module Compr Status Alarm

Delay

mod_comp_stat_alm_delay_5

9999.0 5 999 TRUE

LINK(S): PREV, SYSTEM SETUP, HOME, ALARM

MODULE WATER TEMP LIMITS

Screen Display

Content BACnet Object

Default Min. Value Max. Value Editable

CoolLogic Module Water Out Temp Limits

Mod Evap Wat Out Lo Limit: (F)

Module Freeze Target Setpoint mod_freeze_trg_sp_5

36.0 0 165 TRUE

Mod Evap Wat Out Hi Limit: (F)

Module High Evaporator Leaving

Temp at Startup

mod_high_evap_lvg_tmp_5

90.0 0 165 TRUE

Mod Cond Wat Out Lo Limit: (F)

Module Low Condenser Leaving

Temp. Setpoint

mod_low_cond_lvg_sp_5

50.0 0 165 TRUE

Mod Cond Wat Out Hi Limit:

HI WTR OUT UGW

UCW Module High Cond Leaving

Temp at Startup

ugw_mod_cwr_trg_sp_5

118.0 10 165 TRUE

/HI WTR OUT UGH

UCH Module High Cond Leaving

Temp at Startup

ugh_mod_cwr_trg_sp_5

140.0 10 165 TRUE

Mod Cond Wat Out Hi Limit: (F)

Module Leaving Cond Water

Temp Setpoint

mod_cwr_trg_sp_5

118.0 10 165 FALSE

LINK(S): PREV, SYSTEM SETUP, HOME

SCREW COMP ALARM SETPOINTS

Screen Display

Content BACnet Object

Default Min. Value Max. Value Editable

Screw Comp Alarm Setpoints

Screw Comp Max Amps Allowed 460:

Compressor Max Amps mod_max_amps_sp_5

105.0 1 999 TRUE

Winding Temp Correlation to ohms:

Compr Max Winding Temp

Sensor Resis

mod_max_wind_sens_ohms_5

275.0 1 999 TRUE

LINK(S): PREV, SYSTEM SETUP, HOME, ALARM

SERVICE MENU SETUP FN7

Screen Display

Content BACnet Object

Default Min. Value Max. Value Editable

Page 8 of 15 10/9/2013

Product Line: UGW

Software Version: UGW-H.08B.13

Chiller Type: COOLING 4 PIPE

LOCAL ACCESS DISPLAY TABLE

CoolLogic Service Menu Setup FN7

LINK(S): DIAGNOSTICS MANUAL MODE,CALIB WATER DIFF PRESS SENSORS,CALIB WATER MAINS & AIR TEMPS,ALL MODULE SENSOR CALIBRATION MENUS,

ALL MODULE COMP UNLOAD STATUS,RESET MODULE SENSOR OOR ALARMS,RESET COMP ALARMS,MODULE WATER TEMP LIMITS,WATER MAINS & AIR TEMP LIMITS,

PUMP DOWN SETUP,LOCK WATER TEMPS,RESET COMP RUNTIME & CYCLES,TIME MSTR,SCREW PID SEQUENCING DATA,PREV, SYSTEM SETUP, HOME, ALARM

DIAGNOSTICS MANUAL MODE

Screen Display

Content BACnet Object

Default Min. Value Max. Value Editable

(/)

Link (/)

Manual Mode M1, Manual Mode M2

Link (/)

Manual Mode M3, Manual Mode M4

SWAP LEAD COMPR:

Manually Refresh Lead Module man_refr_modlead_1

Do Not

Refresh Lead

Do Not Refresh

Lead, Refresh

Lead

TRUE

LINK(S): MANUAL MODE M5, MANUAL MODE M6,LOCK WATER TEMPS,PREV, SYSTEM SETUP, HOME, ALARM

MANUAL MODE Mx

Screen Display

Content BACnet Object

Default Min. Value Max. Value Editable

M1 Manual Mode

M1 Manual Mode Enable m1_man_mode_5

Off Off, On TRUE

M1C1 Manual ON

M1C1 Manual Run m1c1_man_run_5

Off Off, On TRUE

M1C1 Status:

Module 1 Comp 1 Status m1_comp1_status_5

On Off, On FALSE

LINK(S): PREV, SERVICE MENU SETUP, HOME

CALIB WATER DIFF PRESS SENSORS

Screen Display

Content BACnet Object

Default Min. Value Max. Value Editable

Calibrate Water Diff Press Sensors

Cool Water Dif Psi Stat: (PSID)

Diff Press Cool Load diff_press_cool_load_1

8.48872 °F FALSE

Cool PsiCalib Offset: (PSID)

Chilled Diff Press Calibration

Point

chwpsi_cali_point_1

0.0 -199 199 TRUE

Heat Water Dif Psi Stat: (PSID)

Diff Press Heat Load diff_press_heat_load_1

8.053761 °F FALSE

Heat Psi Calib Offset: (PSID)

Cond Diff Press Calibration Point cwpsi_cali_point_1

0.0 -199 199 TRUE

LINK(S): PREV, SYSTEM SETUP, HOME, ALARM

CALIB WATER MAINS & AIR TEMPS

Screen Display

Content BACnet Object

Default Min. Value Max. Value Editable

Calibrate Main Header Water &Air Temps

Evap InSens: (F)

EVAP IN TMP chwr_temp_1

54.4 °F FALSE

/Evap Wat In: (F)

CHWR In Temp Status chwr_stat_1

54.4 FALSE

Evap In Calib Offset: (F)

CHWR Temp Calibration Point chwr_cali_point_1

0.0 -250 250 TRUE

Evp OutSens: (F)

EVAP OUT TMP chws_temp_1

50.1 °F FALSE

/Evap WatOut: (F)

CHWS Out Temp Status chws_stat_1

50.2 FALSE

Evap Out Calib Offset: (F)

CHWS Temp Calibration Point chws_cali_point_1

0.0 -250 250 TRUE

Cnd Out Sens: (F)

COND OUT TMP cwr_temp_1

83.3 °F FALSE

/CndWat Out: (F)

CWR Out Status cwr_stat_1

83.3 FALSE

Cond Out Calib Offset: (F)

CWR Calibration Point cwr_cali_point_1

0.0 -250 250 TRUE

Cond In Sens: (F)

COND IN TMP cws_temp_1

67.3 °F FALSE

/Cnd Wat In: (F)

CWS In Temp Status cws_stat_1

67.3 °F FALSE

Cond In Calib Offset: (F)

CWS Temp Calibration Point cws_cali_point_1

0.0 -250 250 TRUE

Outdoor Sens: (F)

OA Temp oat_1

-60.2 °F FALSE

/Outdr Air : (F)

OAT Status oat_stat_1

61.0 FALSE

Outdoor Air Calib Offset: (F)

OAT Calibration Point oat_cali_point_1

0.0 -250 250 TRUE

LINK(S): PREV, SYSTEM SETUP, HOME

ALL MODULE SENSOR CALIBRATION MENUS

Screen Display

Content BACnet Object

Default Min. Value Max. Value Editable

CoolLogic All Module Calibration Menus

LINK(S): MODULE 1 SENSOR CALIBRATIONS,MODULE 2 SENSOR CALIBRATIONS,MODULE 3 SENSOR CALIBRATIONS,MODULE 4 SENSOR CALIBRATIONS,

MODULE 5 SENSOR CALIBRATIONS,MODULE 6 SENSOR CALIBRATIONS,PREV, SYSTEM SETUP, HOME, ALARM

MODULE X SENSOR CALIBRATIONS

Screen Display

Content BACnet Object

Default Min. Value Max. Value Editable

ClimaCool Module 1 Water Calibrations

EvpOutCalib: (F)

M1 CHWS Temp Calib. Point m1_chws_temp_cp_5

0.0 -250 250 TRUE

/EvpOutSta: (F)

M1 Evap Leaving Temp m1_chws_temp_stat_5

51.7 FALSE

CndOutCal: (F)

M1 CWR Temp Calib. Point m1_cwr_temp_cp_5

0.0 -250 250 TRUE

/CondOutStat: (F)

M1 Cond Leaving Temp m1_cwr_temp_stat_5

84.6 FALSE

ClimaCool Module 1 Refrig Calibrations

C1DisPresCal: (psi)

M1C1 DIS Pressure Calib. Point m1c1_disch_pres_cp_5

0.0 -250 250 TRUE

/C1DisPr: (psi)

Module 1 Comp 1 Disch Press m1_c1_disch_pres_stat_5

99.3 0 350 FALSE

C1SucPresCal: (psi)

M1C1 SUC Pressure Calib. Point m1c1_suc_pres_cp_5

0.0 -250 250 TRUE
