Control Access Display Table
Page 5 of 15 10/9/2013
Product Line: UGW
Software Version: UGW-H.08B.13
Chiller Type: COOLING 4 PIPE
LOCAL ACCESS DISPLAY TABLE
LINK(S): PREV, SYSTEM SETUP, HOME
RESET COMP VFD ALARMS
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
CoolLogic Reset Compr VFD Alarms
M1 VFD in Alarm?
Module 1 Comp 1 VFD Fail m1_comp1_vfd_fail_5
Off No, Yes FALSE
/M1C1Reset Alm?
Mod 1 Reset VFD Fault m1_reset_vfdfault_5
Off No, Yes TRUE
M2 VFD in Alarm?
Module 2 Comp 1 VFD Fail m2_comp1_vfd_fail_5
Off No, Yes FALSE
/M2C1Reset Alm?
Mod 2 Reset VFD Fault m2_reset_vfdfault_5
Off No, Yes TRUE
M3 VFD in Alarm?
Module 3 Comp 1 VFD Fail m3_comp1_vfd_fail_5
Off No, Yes FALSE
/M3C1Reset Alm?
Mod 3 Reset VFD Fault m3_reset_vfdfault_5
Off No, Yes TRUE
M4 VFD in Alarm?
Module 4 Comp 1 VFD Fail m4_comp1_vfd_fail_5
Off No, Yes FALSE
/M4C1Reset Alm?
Mod 4 Reset VFD Fault m4_reset_vfdfault_5
Off No, Yes TRUE
M5 VFD in Alarm?
Module 5 Comp 1 VFD Fail m5_comp1_vfd_fail_5
Off No, Yes FALSE
/M5C1Reset Alm?
Mod 5 Reset VFD Fault m5_reset_vfdfault_5
Off No, Yes TRUE
M6 VFD in Alarm?
Module 6 Comp 1 VFD Fail m6_comp1_vfd_fail_5
Off No, Yes FALSE
/M6C1Reset Alm?
Mod 6 Reset VFD Fault m6_reset_vfdfault_5
Off No, Yes TRUE
LINK(S): PREV, SYSTEM SETUP, HOME
RESET MODULE FREEZ & HOT ALARMS
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
CoolLogic Reset Mod Freez &Hot Alarms
M1 inFreezAlm?
Module 1 Freeze Alarm m1_freeze_alrm_5
No No, Yes FALSE
/M1 Frz-CWReset?
Reset Mot1 Vlv Fail m1_reset_freeze_5
Off No, Yes TRUE
M1 in CWR Alm? (/)
Module 1 Leaving Cond Water
Alarm
m1_cwr_alrm_5
No No, Yes FALSE
M2 inFreezAlm?
Module 2 Freeze Alarm m2_freeze_alrm_5
No No, Yes FALSE
/M2 Frz-CWReset?
Reset Mot2 Vlv Fail m2_reset_freeze_5
Off No, Yes TRUE
M2 in CWR Alm? (/)
Module 2 Leaving Cond Water
Alarm
m2_cwr_alrm_5
No No, Yes FALSE
M3 inFreezAlm?
Module 3 Freeze Alarm m3_freeze_alrm_5
No No, Yes FALSE
/M3 Frz-CWReset?
Reset Mot3 Vlv Fail m3_reset_freeze_5
Off No, Yes TRUE
M3 in CWR Alm? (/)
Module 3 Leaving Cond Water
Alarm
m3_cwr_alrm_5
No No, Yes FALSE
M4 inFreezAlm?
Module 4 Freeze Alarm m4_freeze_alrm_5
No No, Yes FALSE
/M4 Frz-CWReset?
Reset Mot4 Vlv Fail m4_reset_freeze_5
Off No, Yes TRUE
M4 in CWR Alm? (/)
Module 4 Leaving Cond Water
Alarm
m4_cwr_alrm_5
No No, Yes FALSE
M5 inFreezAlm?
Module 5 Freeze Alarm m5_freeze_alrm_5
No No, Yes FALSE
/M5 Frz-CWReset?
Reset Mot5 Vlv Fail m5_reset_freeze_5
Off No, Yes TRUE
M5 in CWR Alm? (/)
Module 5 Leaving Cond Water
Alarm
m5_cwr_alrm_5
No No, Yes FALSE
M6 inFreezAlm?
Module 6 Freeze Alarm m6_freeze_alrm_5
No No, Yes FALSE
/M6 Frz-CWReset?
Reset Mot6 Vlv Fail m6_reset_freeze_5
Off No, Yes TRUE
M6 in CWR Alm? (/)
Module 6 Leaving Cond Water
Alarm
m6_cwr_alrm_5
No No, Yes FALSE
LINK(S): PREV, SYSTEM SETUP, HOME
RESET COMP RUNTIME & CYCLES
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
Reset Compr Runtime & Cycles Menu
M1C1Reset Runtm
M1C1 Runtime Reset m1reset_c1_rtim_5
Off No, Yes TRUE
/M1C1Reset Cyc
M1C1 Cycles Reset m1c1_cycles_reset_5
Off No, Yes TRUE
M2C1Reset Runtm
M2C1 Runtime Reset m2reset_c1_rtim_5
Off No, Yes TRUE
/M2C1Reset Cyc
M2C1 Cycles Reset m2c1_cycles_reset_5
Off No, Yes TRUE
M3C1Reset Runtm
M3C1 Runtime Reset m3reset_c1_rtim_5
Off No, Yes TRUE
/M3C1Reset Cyc
M3C1 Cycles Reset m3c1_cycles_reset_5
Off No, Yes TRUE
M4C1Reset Runtm
M4C1 Runtime Reset m4reset_c1_rtim_5
Off No, Yes TRUE
/M4C1Reset Cyc
M4C1 Cycles Reset m4c1_cycles_reset_5
Off No, Yes TRUE
M5C1Reset Runtm
M5C1 Runtime Reset m5reset_c1_rtim_5
Off No, Yes TRUE
/M5C1Reset Cyc
M5C1 Cycles Reset m5c1_cycles_reset_5
Off No, Yes TRUE
M6C1Reset Runtm
M6C1 Runtime Reset m6reset_c1_rtim_5
Off No, Yes TRUE
/M6C1Reset Cyc
M6C1 Cycles Reset m6c1_cycles_reset_5
Off No, Yes TRUE
LINK(S): PREV, SYSTEM SETUP, HOME
RESET MODULE SENSOR OOR ALARMS
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
CoolLogic Reset Module Sensor OOR Alms
M1C1 inOOR Alm?
Module 1 Comp 1 Sensor OOR m1_comp1_oor_5
Off No, Yes FALSE
/ Reset M1 OOR?
M1 Sensor OOR Reset m1_oorsl_reset_5
Off No, Yes TRUE
M2C1 inOOR Alm?
Module 2 Comp 1 Sensor OOR m2_comp1_oor_5
Off No, Yes FALSE
/ Reset M2 OOR?
M2 Sensor OOR Reset m2_oorsl_reset_5
Off No, Yes TRUE
M3C1 inOOR Alm?
Module 3 Comp 1 Sensor OOR m3_comp1_oor_5
Off No, Yes FALSE
/ Reset M3 OOR?
M3 Sensor OOR Reset m3_oorsl_reset_5
Off No, Yes TRUE
M4C1 inOOR Alm?
Module 4 Comp 1 Sensor OOR m4_comp1_oor_5
Off No, Yes FALSE
/ Reset M4 OOR?
M4 Sensor OOR Reset m4_oorsl_reset_5
Off No, Yes TRUE
Page 6 of 15 10/9/2013
Product Line: UGW
Software Version: UGW-H.08B.13
Chiller Type: COOLING 4 PIPE
LOCAL ACCESS DISPLAY TABLE
M5C1 inOOR Alm?
Module 5 Comp 1 Sensor OOR m5_comp1_oor_5
Off No, Yes FALSE
/ Reset M5 OOR?
M5 Sensor OOR Reset m5_oorsl_reset_5
Off No, Yes TRUE
M6C1 inOOR Alm?
Module 6 Comp 1 Sensor OOR m6_comp1_oor_5
Off No, Yes FALSE
/ Reset M6 OOR?
M6 Sensor OOR Reset m6_oorsl_reset_5
Off No, Yes TRUE
LINK(S): PREV, SYSTEM SETUP, HOME
ALL MODULE COMP
UNLOAD STATUS FN5
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
CoolLogic All Module Compr Unloads FN5
LINK(S): MOD1 COMPR UNLOAD STATUS,MOD2 COMPR UNLOAD STATUS,MOD3 COMPR UNLOAD STATUS,MOD4 COMPR UNLOAD STATUS,MOD5 COMPR UNLOAD STATUS,
MOD6 COMPR UNLOAD STATUS,PREV, SYSTEM SETUP, HOME, ALARM
MODX COMPR UNLOAD STATUS
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
CoolLogic Module 1 Compr Unload Status
M1C1 Low Suct Press Unload :
Module 1 Comp 1 Suct Pressure
Unload
m1_c1_lo_suc_psi_unld_5
Off Off, On FALSE
M1C1 XLow Suct Press Unload :
Module 1 Comp 1 XLow Suct
Pressure Unload
m1_c1_lolo_suc_psi_unld_5
Off Off, On FALSE
M1C1 Low Suct Temp Unload :
Module 1 Comp 1 Suct Temp
Unload
m1_c1_lo_suc_tmp_unld_5
Off Off, On FALSE
M1 Evap Freeze Temp Unload :
Module 1 Freeze trg Unload m1_freeze_trg_unld_5
Off Off, On FALSE
M1 Cond WatOut Temp Unload :
Module 1 CWR trg Unload m1_cwr_trg_unld_5
Off Off, On FALSE
M1C1 High Dis Press Unload :
Module 1 Comp 1 Dis Pressure
Unload
m1_c1_hi_dis_psi_unld_5
Off Off, On FALSE
M1C1 High Dis Temp Unload :
Module 1 Comp 1 Dis Temp
Unload
m1_c1_hi_dis_tmp_unld_5
Off Off, On FALSE
LINK(S): PREV, SYSTEM SETUP, HOME, ALARM
MODULE FACTORY SETUP FN6
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
CoolLogic Module Factory Setup FN6
LINK(S): REFRIGERANT TYPE,REFRIG TMP & PRESS SENSORS AVAIL,REFRIG TMP & PSI ALARM SETPTS,PUMP DOWN SETUP,LO SUC SPRHT & LO DISCH SPRHT SETPTS,
FREEZE TARGET AND HOT WATER SETPOINT,COMPR MIN MAX RUN TIMES,COMPR ALARM DELAY,MODULE WATER TEMP LIMITS,SCREW COMP ALARM SETPOINTS,PREV,
SYSTEM SETUP, HOME, ALARM
REFRIGERANT TYPE
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
CoolLogic Model & Refrig Setup Menu
Mod Ref Type
Module Compr Ref Type mod_comp_ref_type_5
134a
22, 407C,
410a, 134a
TRUE
Chiller Model Type:
Chiller Model Type chiller_model_type_5
UGW
UGW, UGH,
UGR
TRUE
LINK(S): PREV, SYSTEM SETUP, HOME
REFRIG TMP & PRESS SENSORS AVAIL
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
Module Refr Temp & Press Avail Sensors
Dis Pres Avail
Module DISCH PSI AVAIL mod_disch_psi_avail_5
On Off, On TRUE
/Suc Pres Avail
Module SUC PSI AVAIL mod_suc_psi_avail_5
On Off, On TRUE
Dis Temp Avail
Module DISCH TMP AVAIL mod_disch_tmp_avail_5
On Off, On TRUE
/Suc Temp Avail
Module SUC TMP AVAIL mod_suc_tmp_avail_5
On Off, On TRUE
Avail. Sensor Menu Water Temp.
Leaving Cond Water Temp CWR Avail
Module CWR AVAIL mod_cwr_avail_5
On Off, On TRUE
EnablCWR LoAlm
Module CWR Enable Low Limit mod_cwr_lo_enable_5
On Off, On TRUE
/EnablCHS HiAlm
Module CWR Enable High Limit mod_chs_hi_enable_5
On Off, On TRUE
LINK(S): PREV, SYSTEM SETUP, HOME
REFRIG TMP & PSI ALARM SETPTS
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
Module Refr Temp & Press. Alarm Setpts
DisPrAlm134UGW
High Head Press Sp 134a UCW mod_hi_disch_press_sp_134_ucw_5
200.0 50 650 TRUE
/DisPrAlm134UGH
High Head Press Sp 134a UCH/R mod_hi_disch_press_sp_134_uchr_5
230.0 50 650 TRUE
DisPrAlm410UGW
High Head Press Sp 410a UCW mod_hi_disch_press_sp_410_ucw_5
385.0 250 650 TRUE
/DisPrAlm410UGH
High Head Press Sp 410a UCH-
UCR
mod_hi_disch_press_sp_410_uchr_5
575.0 250 650 TRUE
DisPrAlm407UGW
High Head Press Sp 407C UCW mod_hi_disch_press_sp_407_ucw_5
300.0 100 450 TRUE
/DisPrAlm407UGH
High Head Press Sp R-407C UCH-
UCR
mod_hi_disch_press_sp_407_uchr_5
385.0 100 450 TRUE
Page 6 of 15 10/9/2013
Product Line: UGW
Software Version: UGW-H.08B.13
Chiller Type: COOLING 4 PIPE
LOCAL ACCESS DISPLAY TABLE
M5C1 inOOR Alm?
Module 5 Comp 1 Sensor OOR m5_comp1_oor_5
Off No, Yes FALSE
/ Reset M5 OOR?
M5 Sensor OOR Reset m5_oorsl_reset_5
Off No, Yes TRUE
M6C1 inOOR Alm?
Module 6 Comp 1 Sensor OOR m6_comp1_oor_5
Off No, Yes FALSE
/ Reset M6 OOR?
M6 Sensor OOR Reset m6_oorsl_reset_5
Off No, Yes TRUE
LINK(S): PREV, SYSTEM SETUP, HOME
ALL MODULE COMP
UNLOAD STATUS FN5
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
CoolLogic All Module Compr Unloads FN5
LINK(S): MOD1 COMPR UNLOAD STATUS,MOD2 COMPR UNLOAD STATUS,MOD3 COMPR UNLOAD STATUS,MOD4 COMPR UNLOAD STATUS,MOD5 COMPR UNLOAD STATUS,
MOD6 COMPR UNLOAD STATUS,PREV, SYSTEM SETUP, HOME, ALARM
MODX COMPR UNLOAD STATUS
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
CoolLogic Module 1 Compr Unload Status
M1C1 Low Suct Press Unload :
Module 1 Comp 1 Suct Pressure
Unload
m1_c1_lo_suc_psi_unld_5
Off Off, On FALSE
M1C1 XLow Suct Press Unload :
Module 1 Comp 1 XLow Suct
Pressure Unload
m1_c1_lolo_suc_psi_unld_5
Off Off, On FALSE
M1C1 Low Suct Temp Unload :
Module 1 Comp 1 Suct Temp
Unload
m1_c1_lo_suc_tmp_unld_5
Off Off, On FALSE
M1 Evap Freeze Temp Unload :
Module 1 Freeze trg Unload m1_freeze_trg_unld_5
Off Off, On FALSE
M1 Cond WatOut Temp Unload :
Module 1 CWR trg Unload m1_cwr_trg_unld_5
Off Off, On FALSE
M1C1 High Dis Press Unload :
Module 1 Comp 1 Dis Pressure
Unload
m1_c1_hi_dis_psi_unld_5
Off Off, On FALSE
M1C1 High Dis Temp Unload :
Module 1 Comp 1 Dis Temp
Unload
m1_c1_hi_dis_tmp_unld_5
Off Off, On FALSE
LINK(S): PREV, SYSTEM SETUP, HOME, ALARM
MODULE FACTORY SETUP FN6
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
CoolLogic Module Factory Setup FN6
LINK(S): REFRIGERANT TYPE,REFRIG TMP & PRESS SENSORS AVAIL,REFRIG TMP & PSI ALARM SETPTS,PUMP DOWN SETUP,LO SUC SPRHT & LO DISCH SPRHT SETPTS,
FREEZE TARGET AND HOT WATER SETPOINT,COMPR MIN MAX RUN TIMES,COMPR ALARM DELAY,MODULE WATER TEMP LIMITS,SCREW COMP ALARM SETPOINTS,PREV,
SYSTEM SETUP, HOME, ALARM
REFRIGERANT TYPE
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
CoolLogic Model & Refrig Setup Menu
Mod Ref Type
Module Compr Ref Type mod_comp_ref_type_5
134a
22, 407C,
410a, 134a
TRUE
Chiller Model Type:
Chiller Model Type chiller_model_type_5
UGW
UGW, UGH,
UGR
TRUE
LINK(S): PREV, SYSTEM SETUP, HOME
REFRIG TMP & PRESS SENSORS AVAIL
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
Module Refr Temp & Press Avail Sensors
Dis Pres Avail
Module DISCH PSI AVAIL mod_disch_psi_avail_5
On Off, On TRUE
/Suc Pres Avail
Module SUC PSI AVAIL mod_suc_psi_avail_5
On Off, On TRUE
Dis Temp Avail
Module DISCH TMP AVAIL mod_disch_tmp_avail_5
On Off, On TRUE
/Suc Temp Avail
Module SUC TMP AVAIL mod_suc_tmp_avail_5
On Off, On TRUE
Avail. Sensor Menu Water Temp.
Leaving Cond Water Temp CWR Avail
Module CWR AVAIL mod_cwr_avail_5
On Off, On TRUE
EnablCWR LoAlm
Module CWR Enable Low Limit mod_cwr_lo_enable_5
On Off, On TRUE
/EnablCHS HiAlm
Module CWR Enable High Limit mod_chs_hi_enable_5
On Off, On TRUE
LINK(S): PREV, SYSTEM SETUP, HOME
REFRIG TMP & PSI ALARM SETPTS
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
Module Refr Temp & Press. Alarm Setpts
DisPrAlm134UGW
High Head Press Sp 134a UCW mod_hi_disch_press_sp_134_ucw_5
200.0 50 650 TRUE
/DisPrAlm134UGH
High Head Press Sp 134a UCH/R mod_hi_disch_press_sp_134_uchr_5
230.0 50 650 TRUE
DisPrAlm410UGW
High Head Press Sp 410a UCW mod_hi_disch_press_sp_410_ucw_5
385.0 250 650 TRUE
/DisPrAlm410UGH
High Head Press Sp 410a UCH-
UCR
mod_hi_disch_press_sp_410_uchr_5
575.0 250 650 TRUE
DisPrAlm407UGW
High Head Press Sp 407C UCW mod_hi_disch_press_sp_407_ucw_5
300.0 100 450 TRUE
/DisPrAlm407UGH
High Head Press Sp R-407C UCH-
UCR
mod_hi_disch_press_sp_407_uchr_5
385.0 100 450 TRUE
Page 7 of 15 10/9/2013
Product Line: UGW
Software Version: UGW-H.08B.13
Chiller Type: COOLING 4 PIPE
LOCAL ACCESS DISPLAY TABLE
Mod Active Status DisPr Alm SP:
Module Hi Disch Press Setpt mod_hi_disch_press_sp_5
200.0 FALSE
Default Head Pressure Value:
Module Default Head Pressure mod_default_hp_5
70.0 50 650 TRUE
Head Pressure Min Adj Value:
Module Head Pressure Positive
Adj
mod_hp_pos_adj_5
60.0 50 650 TRUE
SucPr Alm 134a
Low Suction Press Sp 134a mod_lo_suc_press_sp_134_5
15.0 2 200 TRUE
SucPr Alm 410a
Low Suction Press Sp 410a mod_lo_suc_press_sp_410_5
94.0 2 150 TRUE
/SucPr Alm 407C
Low Suction Press Sp 407C mod_lo_suc_press_sp_407_5
50.0 2 120 TRUE
Mod Active Status SucPr Alm SP:
Module Low Suction Press Setpt mod_low_press_sp_5
15.0 FALSE
Mod SucPr Time Delay Before Alarm:
Module LO SUC PSI Delay mod_lo_suc_psi_delay_5
30.0 0 999 TRUE
Mod Extra Low SucPr Alm SP:
Module LO-LO SUC PSI Setpoint mod_low_low_press_sp_5
0.0 -5 50 TRUE
Low Dis Pr Ctrl SP R134a
Low Head Press Sp 134a mod_lo_disch_press_sp_134_5
100.0 20 350 TRUE
Low Dis Pr Ctrl SP R410a
Low Head Press Sp 410a mod_lo_disch_press_sp_410_5
220.0 50 450 TRUE
Low Dis Pr Ctrl SP R407C
Low Head Press Sp 407 mod_lo_disch_press_sp_407_5
150.0 50 300 TRUE
Mod Active Status Low DisPr Alm SP:
Module Lo Disch Press Setpt mod_lo_disch_press_sp_5
100.0 FALSE
M DisTp Alm SP
Module Hi Disch Temp mod_hi_disch_tmp_5
225.0 100 325 TRUE
/M SucTp Alm SP
Module Low Suction Temp mod_lo_suction_tmp_5
32.0 10 75 TRUE
LINK(S): PREV, SYSTEM SETUP, HOME
LO SUC SPRHT & LO DISCH SPRHT SETPTS
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
CoolLogic Suc&Dis SuperHt Alrm Setpts
M Lo DisSuprHt
Module Low Disch SuperHt
Setpt
mod_lo_disc_supht_sp_5
15.0 TRUE
/M Lo SucSuprHt
Module Low Suct SuperHt Setpt mod_lo_suc_supht_sp_5
2.0 TRUE
LINK(S): PREV, SYSTEM SETUP, HOME
FREEZE TARGET SETPOINT
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
CoolLogic Freeze Target Setpts Menu
Freeze TrgSp (F)
Module Freeze Target Setpoint mod_freeze_trg_sp_5
36.0 0 50 TRUE
LINK(S): PREV, SYSTEM SETUP, HOME
COMPR MIN MAX RUN TIMES
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
Compressor Min & Max Run Times
Compr Minimum Run Time (sec)
Module Compr Min Run Time mod_cmpr_min_run_5
120.0 1 999 TRUE
Compr Minimum Off Time (sec)
Module Compr Min Off Delay mod_cmpr_off_delay_5
150.0 1 999 TRUE
LINK(S): PREV, ALARM, SYSTEM SETUP, CLOCKSET
COMPR ALARM DELAY
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
CoolLogic Compr Alarm Delays
Mod Alm Delay
Module Compr Status Alarm
Delay
mod_comp_stat_alm_delay_5
9999.0 5 999 TRUE
LINK(S): PREV, SYSTEM SETUP, HOME, ALARM
MODULE WATER TEMP LIMITS
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
CoolLogic Module Water Out Temp Limits
Mod Evap Wat Out Lo Limit: (F)
Module Freeze Target Setpoint mod_freeze_trg_sp_5
36.0 0 165 TRUE
Mod Evap Wat Out Hi Limit: (F)
Module High Evaporator Leaving
Temp at Startup
mod_high_evap_lvg_tmp_5
90.0 0 165 TRUE
Mod Cond Wat Out Lo Limit: (F)
Module Low Condenser Leaving
Temp. Setpoint
mod_low_cond_lvg_sp_5
50.0 0 165 TRUE
Mod Cond Wat Out Hi Limit:
HI WTR OUT UGW
UCW Module High Cond Leaving
Temp at Startup
ugw_mod_cwr_trg_sp_5
118.0 10 165 TRUE
/HI WTR OUT UGH
UCH Module High Cond Leaving
Temp at Startup
ugh_mod_cwr_trg_sp_5
140.0 10 165 TRUE
Mod Cond Wat Out Hi Limit: (F)
Module Leaving Cond Water
Temp Setpoint
mod_cwr_trg_sp_5
118.0 10 165 FALSE
LINK(S): PREV, SYSTEM SETUP, HOME
SCREW COMP ALARM SETPOINTS
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
Screw Comp Alarm Setpoints
Screw Comp Max Amps Allowed 460:
Compressor Max Amps mod_max_amps_sp_5
105.0 1 999 TRUE
Winding Temp Correlation to ohms:
Compr Max Winding Temp
Sensor Resis
mod_max_wind_sens_ohms_5
275.0 1 999 TRUE
LINK(S): PREV, SYSTEM SETUP, HOME, ALARM
SERVICE MENU SETUP FN7
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
Page 5 of 15 10/9/2013
Product Line: UGW
Software Version: UGW-H.08B.13
Chiller Type: COOLING 4 PIPE
LOCAL ACCESS DISPLAY TABLE
LINK(S): PREV, SYSTEM SETUP, HOME
RESET COMP VFD ALARMS
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
CoolLogic Reset Compr VFD Alarms
M1 VFD in Alarm?
Module 1 Comp 1 VFD Fail m1_comp1_vfd_fail_5
Off No, Yes FALSE
/M1C1Reset Alm?
Mod 1 Reset VFD Fault m1_reset_vfdfault_5
Off No, Yes TRUE
M2 VFD in Alarm?
Module 2 Comp 1 VFD Fail m2_comp1_vfd_fail_5
Off No, Yes FALSE
/M2C1Reset Alm?
Mod 2 Reset VFD Fault m2_reset_vfdfault_5
Off No, Yes TRUE
M3 VFD in Alarm?
Module 3 Comp 1 VFD Fail m3_comp1_vfd_fail_5
Off No, Yes FALSE
/M3C1Reset Alm?
Mod 3 Reset VFD Fault m3_reset_vfdfault_5
Off No, Yes TRUE
M4 VFD in Alarm?
Module 4 Comp 1 VFD Fail m4_comp1_vfd_fail_5
Off No, Yes FALSE
/M4C1Reset Alm?
Mod 4 Reset VFD Fault m4_reset_vfdfault_5
Off No, Yes TRUE
M5 VFD in Alarm?
Module 5 Comp 1 VFD Fail m5_comp1_vfd_fail_5
Off No, Yes FALSE
/M5C1Reset Alm?
Mod 5 Reset VFD Fault m5_reset_vfdfault_5
Off No, Yes TRUE
M6 VFD in Alarm?
Module 6 Comp 1 VFD Fail m6_comp1_vfd_fail_5
Off No, Yes FALSE
/M6C1Reset Alm?
Mod 6 Reset VFD Fault m6_reset_vfdfault_5
Off No, Yes TRUE
LINK(S): PREV, SYSTEM SETUP, HOME
RESET MODULE FREEZ & HOT ALARMS
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
CoolLogic Reset Mod Freez &Hot Alarms
M1 inFreezAlm?
Module 1 Freeze Alarm m1_freeze_alrm_5
No No, Yes FALSE
/M1 Frz-CWReset?
Reset Mot1 Vlv Fail m1_reset_freeze_5
Off No, Yes TRUE
M1 in CWR Alm? (/)
Module 1 Leaving Cond Water
Alarm
m1_cwr_alrm_5
No No, Yes FALSE
M2 inFreezAlm?
Module 2 Freeze Alarm m2_freeze_alrm_5
No No, Yes FALSE
/M2 Frz-CWReset?
Reset Mot2 Vlv Fail m2_reset_freeze_5
Off No, Yes TRUE
M2 in CWR Alm? (/)
Module 2 Leaving Cond Water
Alarm
m2_cwr_alrm_5
No No, Yes FALSE
M3 inFreezAlm?
Module 3 Freeze Alarm m3_freeze_alrm_5
No No, Yes FALSE
/M3 Frz-CWReset?
Reset Mot3 Vlv Fail m3_reset_freeze_5
Off No, Yes TRUE
M3 in CWR Alm? (/)
Module 3 Leaving Cond Water
Alarm
m3_cwr_alrm_5
No No, Yes FALSE
M4 inFreezAlm?
Module 4 Freeze Alarm m4_freeze_alrm_5
No No, Yes FALSE
/M4 Frz-CWReset?
Reset Mot4 Vlv Fail m4_reset_freeze_5
Off No, Yes TRUE
M4 in CWR Alm? (/)
Module 4 Leaving Cond Water
Alarm
m4_cwr_alrm_5
No No, Yes FALSE
M5 inFreezAlm?
Module 5 Freeze Alarm m5_freeze_alrm_5
No No, Yes FALSE
/M5 Frz-CWReset?
Reset Mot5 Vlv Fail m5_reset_freeze_5
Off No, Yes TRUE
M5 in CWR Alm? (/)
Module 5 Leaving Cond Water
Alarm
m5_cwr_alrm_5
No No, Yes FALSE
M6 inFreezAlm?
Module 6 Freeze Alarm m6_freeze_alrm_5
No No, Yes FALSE
/M6 Frz-CWReset?
Reset Mot6 Vlv Fail m6_reset_freeze_5
Off No, Yes TRUE
M6 in CWR Alm? (/)
Module 6 Leaving Cond Water
Alarm
m6_cwr_alrm_5
No No, Yes FALSE
LINK(S): PREV, SYSTEM SETUP, HOME
RESET COMP RUNTIME & CYCLES
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
Reset Compr Runtime & Cycles Menu
M1C1Reset Runtm
M1C1 Runtime Reset m1reset_c1_rtim_5
Off No, Yes TRUE
/M1C1Reset Cyc
M1C1 Cycles Reset m1c1_cycles_reset_5
Off No, Yes TRUE
M2C1Reset Runtm
M2C1 Runtime Reset m2reset_c1_rtim_5
Off No, Yes TRUE
/M2C1Reset Cyc
M2C1 Cycles Reset m2c1_cycles_reset_5
Off No, Yes TRUE
M3C1Reset Runtm
M3C1 Runtime Reset m3reset_c1_rtim_5
Off No, Yes TRUE
/M3C1Reset Cyc
M3C1 Cycles Reset m3c1_cycles_reset_5
Off No, Yes TRUE
M4C1Reset Runtm
M4C1 Runtime Reset m4reset_c1_rtim_5
Off No, Yes TRUE
/M4C1Reset Cyc
M4C1 Cycles Reset m4c1_cycles_reset_5
Off No, Yes TRUE
M5C1Reset Runtm
M5C1 Runtime Reset m5reset_c1_rtim_5
Off No, Yes TRUE
/M5C1Reset Cyc
M5C1 Cycles Reset m5c1_cycles_reset_5
Off No, Yes TRUE
M6C1Reset Runtm
M6C1 Runtime Reset m6reset_c1_rtim_5
Off No, Yes TRUE
/M6C1Reset Cyc
M6C1 Cycles Reset m6c1_cycles_reset_5
Off No, Yes TRUE
LINK(S): PREV, SYSTEM SETUP, HOME
RESET MODULE SENSOR OOR ALARMS
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
CoolLogic Reset Module Sensor OOR Alms
M1C1 inOOR Alm?
Module 1 Comp 1 Sensor OOR m1_comp1_oor_5
Off No, Yes FALSE
/ Reset M1 OOR?
M1 Sensor OOR Reset m1_oorsl_reset_5
Off No, Yes TRUE
M2C1 inOOR Alm?
Module 2 Comp 1 Sensor OOR m2_comp1_oor_5
Off No, Yes FALSE
/ Reset M2 OOR?
M2 Sensor OOR Reset m2_oorsl_reset_5
Off No, Yes TRUE
M3C1 inOOR Alm?
Module 3 Comp 1 Sensor OOR m3_comp1_oor_5
Off No, Yes FALSE
/ Reset M3 OOR?
M3 Sensor OOR Reset m3_oorsl_reset_5
Off No, Yes TRUE
M4C1 inOOR Alm?
Module 4 Comp 1 Sensor OOR m4_comp1_oor_5
Off No, Yes FALSE
/ Reset M4 OOR?
M4 Sensor OOR Reset m4_oorsl_reset_5
Off No, Yes TRUE
