Control Access Display Table
Page 3 of 15 10/9/2013
Product Line: UGW
Software Version: UGW-H.08B.13
Chiller Type: COOLING 4 PIPE
LOCAL ACCESS DISPLAY TABLE
LINK(S): PREV, STATUS, HOME, ALARM
ALL COMPR RUNTIME STATUS
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
CoolLogic Compressor Runtime Status
M1C1 Runtm: (h)
Module 1 Comp 1 Runtime m1_c1_rtime_1
2.3116667 FALSE
/M4C1 Runtm: (h)
Module 4 Comp 1 Runtime m4_c1_rtime_1
0.015833333 FALSE
M2C1 Runtm: (h)
Module 2 Comp 1 Runtime m2_c1_rtime_1
3.02 FALSE
/M5C1 Runtm: (h)
Module 5 Comp 1 Runtime m5_c1_rtime_1
0.0 FALSE
M3C1 Runtm: (h)
Module 3 Comp 1 Runtime m3_c1_rtime_1
1.773889 FALSE
/M6C1 Runtm: (h)
Module 6 Comp 1 Runtime m6_c1_rtime_1
0.0 FALSE
LINK(S): PREV, SYSTEM SETUP, HOME, ALARM
ALL COMPR CYCLES STATUS
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
CoolLogic Compressor Cycles Status
M1C1 Cycles:
Module 1 Comp 1 Cycles m1_c1_cycles_5
1.0 FALSE
/M4C1 Cycles:
Module 4 Comp 1 Cycles m4_c1_cycles_5
0.0 FALSE
M2C1 Cycles:
Module 2 Comp 1 Cycles m2_c1_cycles_5
1.0 FALSE
/M5C1 Cycles:
Module 5 Comp 1 Cycles m5_c1_cycles_5
0.0 FALSE
M3C1 Cycles:
Module 3 Comp 1 Cycles m3_c1_cycles_5
0.0 FALSE
/M6C1 Cycles:
Module 6 Comp 1 Cycles m6_c1_cycles_5
0.0 FALSE
LINK(S): PREV, SYSTEM SETUP, HOME, ALARM
ALL COMPR SS STATUS
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
CoolLogic Compressor ON/OFF Status
M1C1 Status:
Module 1 Comp 1 Status m1_comp1_status_5
On Off, On FALSE
/ M4C1 Status:
Module 4 Comp 1 Status m4_comp1_status_5
Off Off, On FALSE
M2C1 Status:
Module 2 Comp 1 Status m2_comp1_status_5
On Off, On FALSE
/ M5C1 Status:
Module 5 Comp 1 Status m5_comp1_status_5
Off Off, On FALSE
M3C1 Status:
Module 3 Comp 1 Status m3_comp1_status_5
Off Off, On FALSE
/ M6C1 Status:
Module 6 Comp 1 Status m6_comp1_status_5
Off Off, On FALSE
LINK(S): PREV, SYSTEM SETUP, HOME, ALARM
ALL COMPR AMPERAGE STATUS
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
CoolLogic Compressor Amperage Status
M1C1 Compr Amps:
Module 1 Comp 1 Amps m1c1_amps_stat_5
33.6 FALSE
/M4C1 Compr Amps:
Module 4 Comp 1 Amps m4c1_amps_stat_5
0.4 FALSE
M2C1 Compr Amps:
Module 2 Comp 1 Amps m2c1_amps_stat_5
25.4 FALSE
/M5C1 Compr Amps:
Module 5 Comp 1 Amps m5c1_amps_stat_5
0.0 FALSE
M3C1 Compr Amps:
Module 3 Comp 1 Amps m3c1_amps_stat_5
0.4 FALSE
/M6C1 Compr Amps:
Module 6 Comp 1 Amps m6c1_amps_stat_5
0.0 FALSE
LINK(S): PREV, SYSTEM SETUP, HOME, ALARM
SYSTEM SETUP FN2
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
CoolLogic System Setup FN2
LINK(S): GENERAL SYS SETTINGS,HEAT & COOL SETPOINT MENUS,EVAP PUMP SETUP,COND PUMP SETUP,LEAD COMPR ROTATION SETUP,ALARM LOCKOUT RESET,SCHEDULES,
PREV, STATUS, HOME, ALARM
GENERAL SYS SETTINGS
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
CoolLogic General System Settings FN4
Chiller Control Type
Control Type control_type_1
Cool Control
Cool Cntrl,
Heat Cntrl,
Heat Rcvry
TRUE
Chiller Control Source
Control Source control_source_1
Digital Input
Dig Input,
Keypad, BAS
TRUE
Enable Chiller from Keypad?
Unit Enable (keypad) enable_keypad_1
On Off, On TRUE
Mod Ref Type
Module Compr Ref Type mod_comp_ref_type_5
134a
22, 407C,
410a, 134a
TRUE
Chiller Model Type:
Chiller Model Type chiller_model_type_5
UGW
UGW, UGH,
UGR
TRUE
Cool Design Delta Temp
FULL LD COOL DES TD cool_design_dt_1
-10.0 -50 50 TRUE
Heat Design Delta Temp
FULL LD HEAT DES TD heat_design_dt_1
10.0 -50 50 TRUE
Use High Amb Tmp Limit?
HI AMBIENT TMP LIM hi_amb_tmp_lim_1
No No, Yes TRUE
Software Version: UGW-H.08b.13
LINK(S): PREV, SYSTEM SETUP, HOME, ALARM
HEAT & COOL SETPOINT MENUS
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
CoolLogic Heat and Cool Setpoints
Page 4 of 15 10/9/2013
Product Line: UGW
Software Version: UGW-H.08B.13
Chiller Type: COOLING 4 PIPE
LOCAL ACCESS DISPLAY TABLE
LINK(S): COOL MODE SETPOINT,HEAT MODE SETPOINT,MASTER INPUT CHNLS 6, &10 SETUP,MASTER INPUT 8 & 11 SETUP,LEAD COMPR ROTATION SETUP,PREV, SYSTEM SETUP,
HOME, ALARM
COOL MODE SETPOINT
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
CoolLogic Cool Mode Setpoint Menu
Local Evap Wat Out Setpt: (F)
COOL LVG TRG chw_temp_stp_1
45.0 °F 0 75 TRUE
Min Evap Wat Out Setpt: (F)
MIN COOL TRG LIM min_chw_temp_stp_1
40.0 °F 0 75 TRUE
Max Evap Wat Out Setpt: (F)
MAX COOL TRG LIM max_chw_temp_stp_1
62.0 °F 0 75 TRUE
Remote Evap Wat Out Setpt: (F)
Remote CHW Setpoint rem_chw_stp_stat_1
40.0 °F 10 75 FALSE
Rem Max Neg CHW Setpt Reset: (F)
MAX NEG DEM LIM COOL RESET max_neg_chw_stp_reset_1
0.0 °F 0 75 TRUE
Rem Max Pos CHW Setpt Reset: (F)
MAX POS DEM LIM COOL RESET max_pos_chw_stp_reset_1
10.0 °F 0 75 TRUE
Remote Evap Wat Out Reset: (F)
Remote CHW Setpoint Reset rem_chw_stp_reset_1
0.0 °F 0 75 TRUE
Active Evap Wat Out Setpt: (F)
Active CHW Setpoint chw_stp_stat_1
45.0 °F 10 75 FALSE
LINK(S): PREV, SYSTEM SETUP, HOME, ALARM
HEAT MODE SETPOINT
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
CoolLogic Heat Mode Setpoint Menu
Local Cond Wat Out Setpt: (F)
HEAT LVG TRG cw_temp_stp_1
125.0 °F 10 165 TRUE
Min Cond Wat Out Setpt: (F)
MIN HEAT TRG LIM min_cw_temp_stp_1
75.0 °F 10 165 TRUE
Max Cond Wat Out Setpt: (F)
MAX HEAT TRG LIM max_cw_temp_stp_1
135.0 °F 10 165 TRUE
Remote Cond Wat Out Setpt: (F)
Remote CW Setpoint rem_cw_stp_stat_1
75.0 °F 50 140 FALSE
Rem Max Neg CWR Setpt Reset: (F)
MAX NEG DEM LIM HEAT RESET max_neg_cw_stp_reset_1
0.0 °F 0 165 TRUE
Rem Max Pos CWR Setpt Reset: (F)
MAX POS DEM LIM HEAT RESET max_pos_cw_stp_reset_1
10.0 °F 0 165 TRUE
Auto Cond Wat Reset by OAT: (F)
Remote CW Setpoint auto_oat_cw_stp_reset_1
135.0 °F 10 165 TRUE
Active Cond Wat Out Setpt: (F)
Active Htg Setpoint cw_stp_stat_1
125.0 °F 10 165 FALSE
LINK(S): PREV, SYSTEM SETUP, HOME, ALARM
LEAD COMPR ROTATION SETUP
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
CoolLogic Lead Compr Rotation Setup
Manual Rotate LeadCompr:
Manually Refresh Lead Module man_refr_modlead_1
Do Not
Refresh Lead
Do Not Rotate,
Rotate
TRUE
Rotate Cmpr Lead on Runtime Hrs :
Lead Swap on Runtime lead_swap_runtime_1
168.0 hr 1 9999 TRUE
Refresh Runtime Hours:
runtime_refresh_4
1 999 TRUE
Stage Down Safety Index: (sec)
safety_ind_delay2_4
1 999 TRUE
Stage Up Safety Index: (sec)
safety_ind_delay1_4
1 999 TRUE
LINK(S): PREV, SYSTEM SETUP, HOME, ALARM
ALARM LOCKOUT RESET FN3
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
CoolLogic Alarm Lockout Reset FN3
Master Pnl Out-of-Range Alm Reset:
Reset Sensor OOR Alarm reset_oor_1
No Off, On TRUE
Master Pnl Temp Lockout Reset:
LOCK OUT RESET reset_1
Off Off, On TRUE
LINK(S): RESET ALL MODULE ALARMS AT ONCE,RESET COMP ALARMS,RESET COMP VFD ALARMS,RESET MODULE FREEZ & HOT ALARMS,RESET COMP RUNTIME & CYCLES,
RESET MODULE SENSOR OOR ALARMS,PREV, SYSTEM SETUP, HOME, ALARM
RESET ALL MODULE ALARMS AT ONCE
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
CoolLogic Reset Module Alarms at Once
Reset ALL Module#1 Alarms at Once?
Reset M1 All Slave Alarms m1_reset_all_slave_alarms_5
Off No, Yes TRUE
Reset ALL Module#2 Alarms at Once?
Reset M2 All Slave Alarms m2_reset_all_slave_alarms_5
Off No, Yes TRUE
Reset ALL Module#3 Alarms at Once?
Reset M3 All Slave Alarms m3_reset_all_slave_alarms_5
Off No, Yes TRUE
Reset ALL Module#4 Alarms at Once?
Reset M4 All Slave Alarms m4_reset_all_slave_alarms_5
Off No, Yes TRUE
Reset ALL Module#5 Alarms at Once?
Reset M5 All Slave Alarms m5_reset_all_slave_alarms_5
Off No, Yes TRUE
Reset ALL Module#6 Alarms at Once?
Reset M6 All Slave Alarms m6_reset_all_slave_alarms_5
Off No, Yes TRUE
LINK(S): PREV, SYSTEM SETUP, HOME, ALARM
RESET COMP ALARMS
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
CoolLogic Reset Compr Alarms
M1C1 in Alarm?
Module 1 Comp 1 Fail m1_comp1_fail_5
Off No, Yes FALSE
/M1C1Reset Alm?
M1C1 Alarm Reset m1reset_c1_alrm_5
Off No, Yes TRUE
M2C1 in Alarm?
Module 2 Comp 1 Fail m2_comp1_fail_5
Off No, Yes FALSE
/M2C1Reset Alm?
M2C1 Alarm Reset m2reset_c1_alrm_5
Off No, Yes TRUE
M3C1 in Alarm?
Module 3 Comp 1 Fail m3_comp1_fail_5
Off No, Yes FALSE
/M3C1Reset Alm?
M3C1 Alarm Reset m3reset_c1_alrm_5
Off No, Yes TRUE
M4C1 in Alarm?
Module 4 Comp 1 Fail m4_comp1_fail_5
Off No, Yes FALSE
/M4C1Reset Alm?
M4C1 Alarm Reset m4reset_c1_alrm_5
Off No, Yes TRUE
M5C1 in Alarm?
Module 5 Comp 1 Fail m5_comp1_fail_5
Off No, Yes FALSE
/M5C1Reset Alm?
M5C1 Alarm Reset m5reset_c1_alrm_5
Off No, Yes TRUE
M6C1 in Alarm?
Module 6 Comp 1 Fail m6_comp1_fail_5
Off No, Yes FALSE
/M6C1Reset Alm?
M6C1 Alarm Reset m6reset_c1_alrm_5
Off No, Yes TRUE
Page 4 of 15 10/9/2013
Product Line: UGW
Software Version: UGW-H.08B.13
Chiller Type: COOLING 4 PIPE
LOCAL ACCESS DISPLAY TABLE
LINK(S): COOL MODE SETPOINT,HEAT MODE SETPOINT,MASTER INPUT CHNLS 6, &10 SETUP,MASTER INPUT 8 & 11 SETUP,LEAD COMPR ROTATION SETUP,PREV, SYSTEM SETUP,
HOME, ALARM
COOL MODE SETPOINT
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
CoolLogic Cool Mode Setpoint Menu
Local Evap Wat Out Setpt: (F)
COOL LVG TRG chw_temp_stp_1
45.0 °F 0 75 TRUE
Min Evap Wat Out Setpt: (F)
MIN COOL TRG LIM min_chw_temp_stp_1
40.0 °F 0 75 TRUE
Max Evap Wat Out Setpt: (F)
MAX COOL TRG LIM max_chw_temp_stp_1
62.0 °F 0 75 TRUE
Remote Evap Wat Out Setpt: (F)
Remote CHW Setpoint rem_chw_stp_stat_1
40.0 °F 10 75 FALSE
Rem Max Neg CHW Setpt Reset: (F)
MAX NEG DEM LIM COOL RESET max_neg_chw_stp_reset_1
0.0 °F 0 75 TRUE
Rem Max Pos CHW Setpt Reset: (F)
MAX POS DEM LIM COOL RESET max_pos_chw_stp_reset_1
10.0 °F 0 75 TRUE
Remote Evap Wat Out Reset: (F)
Remote CHW Setpoint Reset rem_chw_stp_reset_1
0.0 °F 0 75 TRUE
Active Evap Wat Out Setpt: (F)
Active CHW Setpoint chw_stp_stat_1
45.0 °F 10 75 FALSE
LINK(S): PREV, SYSTEM SETUP, HOME, ALARM
HEAT MODE SETPOINT
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
CoolLogic Heat Mode Setpoint Menu
Local Cond Wat Out Setpt: (F)
HEAT LVG TRG cw_temp_stp_1
125.0 °F 10 165 TRUE
Min Cond Wat Out Setpt: (F)
MIN HEAT TRG LIM min_cw_temp_stp_1
75.0 °F 10 165 TRUE
Max Cond Wat Out Setpt: (F)
MAX HEAT TRG LIM max_cw_temp_stp_1
135.0 °F 10 165 TRUE
Remote Cond Wat Out Setpt: (F)
Remote CW Setpoint rem_cw_stp_stat_1
75.0 °F 50 140 FALSE
Rem Max Neg CWR Setpt Reset: (F)
MAX NEG DEM LIM HEAT RESET max_neg_cw_stp_reset_1
0.0 °F 0 165 TRUE
Rem Max Pos CWR Setpt Reset: (F)
MAX POS DEM LIM HEAT RESET max_pos_cw_stp_reset_1
10.0 °F 0 165 TRUE
Auto Cond Wat Reset by OAT: (F)
Remote CW Setpoint auto_oat_cw_stp_reset_1
135.0 °F 10 165 TRUE
Active Cond Wat Out Setpt: (F)
Active Htg Setpoint cw_stp_stat_1
125.0 °F 10 165 FALSE
LINK(S): PREV, SYSTEM SETUP, HOME, ALARM
LEAD COMPR ROTATION SETUP
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
CoolLogic Lead Compr Rotation Setup
Manual Rotate LeadCompr:
Manually Refresh Lead Module man_refr_modlead_1
Do Not
Refresh Lead
Do Not Rotate,
Rotate
TRUE
Rotate Cmpr Lead on Runtime Hrs :
Lead Swap on Runtime lead_swap_runtime_1
168.0 hr 1 9999 TRUE
Refresh Runtime Hours:
runtime_refresh_4
1 999 TRUE
Stage Down Safety Index: (sec)
safety_ind_delay2_4
1 999 TRUE
Stage Up Safety Index: (sec)
safety_ind_delay1_4
1 999 TRUE
LINK(S): PREV, SYSTEM SETUP, HOME, ALARM
ALARM LOCKOUT RESET FN3
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
CoolLogic Alarm Lockout Reset FN3
Master Pnl Out-of-Range Alm Reset:
Reset Sensor OOR Alarm reset_oor_1
No Off, On TRUE
Master Pnl Temp Lockout Reset:
LOCK OUT RESET reset_1
Off Off, On TRUE
LINK(S): RESET ALL MODULE ALARMS AT ONCE,RESET COMP ALARMS,RESET COMP VFD ALARMS,RESET MODULE FREEZ & HOT ALARMS,RESET COMP RUNTIME & CYCLES,
RESET MODULE SENSOR OOR ALARMS,PREV, SYSTEM SETUP, HOME, ALARM
RESET ALL MODULE ALARMS AT ONCE
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
CoolLogic Reset Module Alarms at Once
Reset ALL Module#1 Alarms at Once?
Reset M1 All Slave Alarms m1_reset_all_slave_alarms_5
Off No, Yes TRUE
Reset ALL Module#2 Alarms at Once?
Reset M2 All Slave Alarms m2_reset_all_slave_alarms_5
Off No, Yes TRUE
Reset ALL Module#3 Alarms at Once?
Reset M3 All Slave Alarms m3_reset_all_slave_alarms_5
Off No, Yes TRUE
Reset ALL Module#4 Alarms at Once?
Reset M4 All Slave Alarms m4_reset_all_slave_alarms_5
Off No, Yes TRUE
Reset ALL Module#5 Alarms at Once?
Reset M5 All Slave Alarms m5_reset_all_slave_alarms_5
Off No, Yes TRUE
Reset ALL Module#6 Alarms at Once?
Reset M6 All Slave Alarms m6_reset_all_slave_alarms_5
Off No, Yes TRUE
LINK(S): PREV, SYSTEM SETUP, HOME, ALARM
RESET COMP ALARMS
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
CoolLogic Reset Compr Alarms
M1C1 in Alarm?
Module 1 Comp 1 Fail m1_comp1_fail_5
Off No, Yes FALSE
/M1C1Reset Alm?
M1C1 Alarm Reset m1reset_c1_alrm_5
Off No, Yes TRUE
M2C1 in Alarm?
Module 2 Comp 1 Fail m2_comp1_fail_5
Off No, Yes FALSE
/M2C1Reset Alm?
M2C1 Alarm Reset m2reset_c1_alrm_5
Off No, Yes TRUE
M3C1 in Alarm?
Module 3 Comp 1 Fail m3_comp1_fail_5
Off No, Yes FALSE
/M3C1Reset Alm?
M3C1 Alarm Reset m3reset_c1_alrm_5
Off No, Yes TRUE
M4C1 in Alarm?
Module 4 Comp 1 Fail m4_comp1_fail_5
Off No, Yes FALSE
/M4C1Reset Alm?
M4C1 Alarm Reset m4reset_c1_alrm_5
Off No, Yes TRUE
M5C1 in Alarm?
Module 5 Comp 1 Fail m5_comp1_fail_5
Off No, Yes FALSE
/M5C1Reset Alm?
M5C1 Alarm Reset m5reset_c1_alrm_5
Off No, Yes TRUE
M6C1 in Alarm?
Module 6 Comp 1 Fail m6_comp1_fail_5
Off No, Yes FALSE
/M6C1Reset Alm?
M6C1 Alarm Reset m6reset_c1_alrm_5
Off No, Yes TRUE
Page 4 of 15 10/9/2013
Product Line: UGW
Software Version: UGW-H.08B.13
Chiller Type: COOLING 4 PIPE
LOCAL ACCESS DISPLAY TABLE
LINK(S): COOL MODE SETPOINT,HEAT MODE SETPOINT,MASTER INPUT CHNLS 6, &10 SETUP,MASTER INPUT 8 & 11 SETUP,LEAD COMPR ROTATION SETUP,PREV, SYSTEM SETUP,
HOME, ALARM
COOL MODE SETPOINT
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
CoolLogic Cool Mode Setpoint Menu
Local Evap Wat Out Setpt: (F)
COOL LVG TRG chw_temp_stp_1
45.0 °F 0 75 TRUE
Min Evap Wat Out Setpt: (F)
MIN COOL TRG LIM min_chw_temp_stp_1
40.0 °F 0 75 TRUE
Max Evap Wat Out Setpt: (F)
MAX COOL TRG LIM max_chw_temp_stp_1
62.0 °F 0 75 TRUE
Remote Evap Wat Out Setpt: (F)
Remote CHW Setpoint rem_chw_stp_stat_1
40.0 °F 10 75 FALSE
Rem Max Neg CHW Setpt Reset: (F)
MAX NEG DEM LIM COOL RESET max_neg_chw_stp_reset_1
0.0 °F 0 75 TRUE
Rem Max Pos CHW Setpt Reset: (F)
MAX POS DEM LIM COOL RESET max_pos_chw_stp_reset_1
10.0 °F 0 75 TRUE
Remote Evap Wat Out Reset: (F)
Remote CHW Setpoint Reset rem_chw_stp_reset_1
0.0 °F 0 75 TRUE
Active Evap Wat Out Setpt: (F)
Active CHW Setpoint chw_stp_stat_1
45.0 °F 10 75 FALSE
LINK(S): PREV, SYSTEM SETUP, HOME, ALARM
HEAT MODE SETPOINT
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
CoolLogic Heat Mode Setpoint Menu
Local Cond Wat Out Setpt: (F)
HEAT LVG TRG cw_temp_stp_1
125.0 °F 10 165 TRUE
Min Cond Wat Out Setpt: (F)
MIN HEAT TRG LIM min_cw_temp_stp_1
75.0 °F 10 165 TRUE
Max Cond Wat Out Setpt: (F)
MAX HEAT TRG LIM max_cw_temp_stp_1
135.0 °F 10 165 TRUE
Remote Cond Wat Out Setpt: (F)
Remote CW Setpoint rem_cw_stp_stat_1
75.0 °F 50 140 FALSE
Rem Max Neg CWR Setpt Reset: (F)
MAX NEG DEM LIM HEAT RESET max_neg_cw_stp_reset_1
0.0 °F 0 165 TRUE
Rem Max Pos CWR Setpt Reset: (F)
MAX POS DEM LIM HEAT RESET max_pos_cw_stp_reset_1
10.0 °F 0 165 TRUE
Auto Cond Wat Reset by OAT: (F)
Remote CW Setpoint auto_oat_cw_stp_reset_1
135.0 °F 10 165 TRUE
Active Cond Wat Out Setpt: (F)
Active Htg Setpoint cw_stp_stat_1
125.0 °F 10 165 FALSE
LINK(S): PREV, SYSTEM SETUP, HOME, ALARM
LEAD COMPR ROTATION SETUP
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
CoolLogic Lead Compr Rotation Setup
Manual Rotate LeadCompr:
Manually Refresh Lead Module man_refr_modlead_1
Do Not
Refresh Lead
Do Not Rotate,
Rotate
TRUE
Rotate Cmpr Lead on Runtime Hrs :
Lead Swap on Runtime lead_swap_runtime_1
168.0 hr 1 9999 TRUE
Refresh Runtime Hours:
runtime_refresh_4
1 999 TRUE
Stage Down Safety Index: (sec)
safety_ind_delay2_4
1 999 TRUE
Stage Up Safety Index: (sec)
safety_ind_delay1_4
1 999 TRUE
LINK(S): PREV, SYSTEM SETUP, HOME, ALARM
ALARM LOCKOUT RESET FN3
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
CoolLogic Alarm Lockout Reset FN3
Master Pnl Out-of-Range Alm Reset:
Reset Sensor OOR Alarm reset_oor_1
No Off, On TRUE
Master Pnl Temp Lockout Reset:
LOCK OUT RESET reset_1
Off Off, On TRUE
LINK(S): RESET ALL MODULE ALARMS AT ONCE,RESET COMP ALARMS,RESET COMP VFD ALARMS,RESET MODULE FREEZ & HOT ALARMS,RESET COMP RUNTIME & CYCLES,
RESET MODULE SENSOR OOR ALARMS,PREV, SYSTEM SETUP, HOME, ALARM
RESET ALL MODULE ALARMS AT ONCE
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
CoolLogic Reset Module Alarms at Once
Reset ALL Module#1 Alarms at Once?
Reset M1 All Slave Alarms m1_reset_all_slave_alarms_5
Off No, Yes TRUE
Reset ALL Module#2 Alarms at Once?
Reset M2 All Slave Alarms m2_reset_all_slave_alarms_5
Off No, Yes TRUE
Reset ALL Module#3 Alarms at Once?
Reset M3 All Slave Alarms m3_reset_all_slave_alarms_5
Off No, Yes TRUE
Reset ALL Module#4 Alarms at Once?
Reset M4 All Slave Alarms m4_reset_all_slave_alarms_5
Off No, Yes TRUE
Reset ALL Module#5 Alarms at Once?
Reset M5 All Slave Alarms m5_reset_all_slave_alarms_5
Off No, Yes TRUE
Reset ALL Module#6 Alarms at Once?
Reset M6 All Slave Alarms m6_reset_all_slave_alarms_5
Off No, Yes TRUE
LINK(S): PREV, SYSTEM SETUP, HOME, ALARM
RESET COMP ALARMS
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
CoolLogic Reset Compr Alarms
M1C1 in Alarm?
Module 1 Comp 1 Fail m1_comp1_fail_5
Off No, Yes FALSE
/M1C1Reset Alm?
M1C1 Alarm Reset m1reset_c1_alrm_5
Off No, Yes TRUE
M2C1 in Alarm?
Module 2 Comp 1 Fail m2_comp1_fail_5
Off No, Yes FALSE
/M2C1Reset Alm?
M2C1 Alarm Reset m2reset_c1_alrm_5
Off No, Yes TRUE
M3C1 in Alarm?
Module 3 Comp 1 Fail m3_comp1_fail_5
Off No, Yes FALSE
/M3C1Reset Alm?
M3C1 Alarm Reset m3reset_c1_alrm_5
Off No, Yes TRUE
M4C1 in Alarm?
Module 4 Comp 1 Fail m4_comp1_fail_5
Off No, Yes FALSE
/M4C1Reset Alm?
M4C1 Alarm Reset m4reset_c1_alrm_5
Off No, Yes TRUE
M5C1 in Alarm?
Module 5 Comp 1 Fail m5_comp1_fail_5
Off No, Yes FALSE
/M5C1Reset Alm?
M5C1 Alarm Reset m5reset_c1_alrm_5
Off No, Yes TRUE
M6C1 in Alarm?
Module 6 Comp 1 Fail m6_comp1_fail_5
Off No, Yes FALSE
/M6C1Reset Alm?
M6C1 Alarm Reset m6reset_c1_alrm_5
Off No, Yes TRUE
Page 5 of 15 10/9/2013
Product Line: UGW
Software Version: UGW-H.08B.13
Chiller Type: COOLING 4 PIPE
LOCAL ACCESS DISPLAY TABLE
LINK(S): PREV, SYSTEM SETUP, HOME
RESET COMP VFD ALARMS
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
CoolLogic Reset Compr VFD Alarms
M1 VFD in Alarm?
Module 1 Comp 1 VFD Fail m1_comp1_vfd_fail_5
Off No, Yes FALSE
/M1C1Reset Alm?
Mod 1 Reset VFD Fault m1_reset_vfdfault_5
Off No, Yes TRUE
M2 VFD in Alarm?
Module 2 Comp 1 VFD Fail m2_comp1_vfd_fail_5
Off No, Yes FALSE
/M2C1Reset Alm?
Mod 2 Reset VFD Fault m2_reset_vfdfault_5
Off No, Yes TRUE
M3 VFD in Alarm?
Module 3 Comp 1 VFD Fail m3_comp1_vfd_fail_5
Off No, Yes FALSE
/M3C1Reset Alm?
Mod 3 Reset VFD Fault m3_reset_vfdfault_5
Off No, Yes TRUE
M4 VFD in Alarm?
Module 4 Comp 1 VFD Fail m4_comp1_vfd_fail_5
Off No, Yes FALSE
/M4C1Reset Alm?
Mod 4 Reset VFD Fault m4_reset_vfdfault_5
Off No, Yes TRUE
M5 VFD in Alarm?
Module 5 Comp 1 VFD Fail m5_comp1_vfd_fail_5
Off No, Yes FALSE
/M5C1Reset Alm?
Mod 5 Reset VFD Fault m5_reset_vfdfault_5
Off No, Yes TRUE
M6 VFD in Alarm?
Module 6 Comp 1 VFD Fail m6_comp1_vfd_fail_5
Off No, Yes FALSE
/M6C1Reset Alm?
Mod 6 Reset VFD Fault m6_reset_vfdfault_5
Off No, Yes TRUE
LINK(S): PREV, SYSTEM SETUP, HOME
RESET MODULE FREEZ & HOT ALARMS
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
CoolLogic Reset Mod Freez &Hot Alarms
M1 inFreezAlm?
Module 1 Freeze Alarm m1_freeze_alrm_5
No No, Yes FALSE
/M1 Frz-CWReset?
Reset Mot1 Vlv Fail m1_reset_freeze_5
Off No, Yes TRUE
M1 in CWR Alm? (/)
Module 1 Leaving Cond Water
Alarm
m1_cwr_alrm_5
No No, Yes FALSE
M2 inFreezAlm?
Module 2 Freeze Alarm m2_freeze_alrm_5
No No, Yes FALSE
/M2 Frz-CWReset?
Reset Mot2 Vlv Fail m2_reset_freeze_5
Off No, Yes TRUE
M2 in CWR Alm? (/)
Module 2 Leaving Cond Water
Alarm
m2_cwr_alrm_5
No No, Yes FALSE
M3 inFreezAlm?
Module 3 Freeze Alarm m3_freeze_alrm_5
No No, Yes FALSE
/M3 Frz-CWReset?
Reset Mot3 Vlv Fail m3_reset_freeze_5
Off No, Yes TRUE
M3 in CWR Alm? (/)
Module 3 Leaving Cond Water
Alarm
m3_cwr_alrm_5
No No, Yes FALSE
M4 inFreezAlm?
Module 4 Freeze Alarm m4_freeze_alrm_5
No No, Yes FALSE
/M4 Frz-CWReset?
Reset Mot4 Vlv Fail m4_reset_freeze_5
Off No, Yes TRUE
M4 in CWR Alm? (/)
Module 4 Leaving Cond Water
Alarm
m4_cwr_alrm_5
No No, Yes FALSE
M5 inFreezAlm?
Module 5 Freeze Alarm m5_freeze_alrm_5
No No, Yes FALSE
/M5 Frz-CWReset?
Reset Mot5 Vlv Fail m5_reset_freeze_5
Off No, Yes TRUE
M5 in CWR Alm? (/)
Module 5 Leaving Cond Water
Alarm
m5_cwr_alrm_5
No No, Yes FALSE
M6 inFreezAlm?
Module 6 Freeze Alarm m6_freeze_alrm_5
No No, Yes FALSE
/M6 Frz-CWReset?
Reset Mot6 Vlv Fail m6_reset_freeze_5
Off No, Yes TRUE
M6 in CWR Alm? (/)
Module 6 Leaving Cond Water
Alarm
m6_cwr_alrm_5
No No, Yes FALSE
LINK(S): PREV, SYSTEM SETUP, HOME
RESET COMP RUNTIME & CYCLES
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
Reset Compr Runtime & Cycles Menu
M1C1Reset Runtm
M1C1 Runtime Reset m1reset_c1_rtim_5
Off No, Yes TRUE
/M1C1Reset Cyc
M1C1 Cycles Reset m1c1_cycles_reset_5
Off No, Yes TRUE
M2C1Reset Runtm
M2C1 Runtime Reset m2reset_c1_rtim_5
Off No, Yes TRUE
/M2C1Reset Cyc
M2C1 Cycles Reset m2c1_cycles_reset_5
Off No, Yes TRUE
M3C1Reset Runtm
M3C1 Runtime Reset m3reset_c1_rtim_5
Off No, Yes TRUE
/M3C1Reset Cyc
M3C1 Cycles Reset m3c1_cycles_reset_5
Off No, Yes TRUE
M4C1Reset Runtm
M4C1 Runtime Reset m4reset_c1_rtim_5
Off No, Yes TRUE
/M4C1Reset Cyc
M4C1 Cycles Reset m4c1_cycles_reset_5
Off No, Yes TRUE
M5C1Reset Runtm
M5C1 Runtime Reset m5reset_c1_rtim_5
Off No, Yes TRUE
/M5C1Reset Cyc
M5C1 Cycles Reset m5c1_cycles_reset_5
Off No, Yes TRUE
M6C1Reset Runtm
M6C1 Runtime Reset m6reset_c1_rtim_5
Off No, Yes TRUE
/M6C1Reset Cyc
M6C1 Cycles Reset m6c1_cycles_reset_5
Off No, Yes TRUE
LINK(S): PREV, SYSTEM SETUP, HOME
RESET MODULE SENSOR OOR ALARMS
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
CoolLogic Reset Module Sensor OOR Alms
M1C1 inOOR Alm?
Module 1 Comp 1 Sensor OOR m1_comp1_oor_5
Off No, Yes FALSE
/ Reset M1 OOR?
M1 Sensor OOR Reset m1_oorsl_reset_5
Off No, Yes TRUE
M2C1 inOOR Alm?
Module 2 Comp 1 Sensor OOR m2_comp1_oor_5
Off No, Yes FALSE
/ Reset M2 OOR?
M2 Sensor OOR Reset m2_oorsl_reset_5
Off No, Yes TRUE
M3C1 inOOR Alm?
Module 3 Comp 1 Sensor OOR m3_comp1_oor_5
Off No, Yes FALSE
/ Reset M3 OOR?
M3 Sensor OOR Reset m3_oorsl_reset_5
Off No, Yes TRUE
M4C1 inOOR Alm?
Module 4 Comp 1 Sensor OOR m4_comp1_oor_5
Off No, Yes FALSE
/ Reset M4 OOR?
M4 Sensor OOR Reset m4_oorsl_reset_5
Off No, Yes TRUE
Page 5 of 15 10/9/2013
Product Line: UGW
Software Version: UGW-H.08B.13
Chiller Type: COOLING 4 PIPE
LOCAL ACCESS DISPLAY TABLE
LINK(S): PREV, SYSTEM SETUP, HOME
RESET COMP VFD ALARMS
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
CoolLogic Reset Compr VFD Alarms
M1 VFD in Alarm?
Module 1 Comp 1 VFD Fail m1_comp1_vfd_fail_5
Off No, Yes FALSE
/M1C1Reset Alm?
Mod 1 Reset VFD Fault m1_reset_vfdfault_5
Off No, Yes TRUE
M2 VFD in Alarm?
Module 2 Comp 1 VFD Fail m2_comp1_vfd_fail_5
Off No, Yes FALSE
/M2C1Reset Alm?
Mod 2 Reset VFD Fault m2_reset_vfdfault_5
Off No, Yes TRUE
M3 VFD in Alarm?
Module 3 Comp 1 VFD Fail m3_comp1_vfd_fail_5
Off No, Yes FALSE
/M3C1Reset Alm?
Mod 3 Reset VFD Fault m3_reset_vfdfault_5
Off No, Yes TRUE
M4 VFD in Alarm?
Module 4 Comp 1 VFD Fail m4_comp1_vfd_fail_5
Off No, Yes FALSE
/M4C1Reset Alm?
Mod 4 Reset VFD Fault m4_reset_vfdfault_5
Off No, Yes TRUE
M5 VFD in Alarm?
Module 5 Comp 1 VFD Fail m5_comp1_vfd_fail_5
Off No, Yes FALSE
/M5C1Reset Alm?
Mod 5 Reset VFD Fault m5_reset_vfdfault_5
Off No, Yes TRUE
M6 VFD in Alarm?
Module 6 Comp 1 VFD Fail m6_comp1_vfd_fail_5
Off No, Yes FALSE
/M6C1Reset Alm?
Mod 6 Reset VFD Fault m6_reset_vfdfault_5
Off No, Yes TRUE
LINK(S): PREV, SYSTEM SETUP, HOME
RESET MODULE FREEZ & HOT ALARMS
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
CoolLogic Reset Mod Freez &Hot Alarms
M1 inFreezAlm?
Module 1 Freeze Alarm m1_freeze_alrm_5
No No, Yes FALSE
/M1 Frz-CWReset?
Reset Mot1 Vlv Fail m1_reset_freeze_5
Off No, Yes TRUE
M1 in CWR Alm? (/)
Module 1 Leaving Cond Water
Alarm
m1_cwr_alrm_5
No No, Yes FALSE
M2 inFreezAlm?
Module 2 Freeze Alarm m2_freeze_alrm_5
No No, Yes FALSE
/M2 Frz-CWReset?
Reset Mot2 Vlv Fail m2_reset_freeze_5
Off No, Yes TRUE
M2 in CWR Alm? (/)
Module 2 Leaving Cond Water
Alarm
m2_cwr_alrm_5
No No, Yes FALSE
M3 inFreezAlm?
Module 3 Freeze Alarm m3_freeze_alrm_5
No No, Yes FALSE
/M3 Frz-CWReset?
Reset Mot3 Vlv Fail m3_reset_freeze_5
Off No, Yes TRUE
M3 in CWR Alm? (/)
Module 3 Leaving Cond Water
Alarm
m3_cwr_alrm_5
No No, Yes FALSE
M4 inFreezAlm?
Module 4 Freeze Alarm m4_freeze_alrm_5
No No, Yes FALSE
/M4 Frz-CWReset?
Reset Mot4 Vlv Fail m4_reset_freeze_5
Off No, Yes TRUE
M4 in CWR Alm? (/)
Module 4 Leaving Cond Water
Alarm
m4_cwr_alrm_5
No No, Yes FALSE
M5 inFreezAlm?
Module 5 Freeze Alarm m5_freeze_alrm_5
No No, Yes FALSE
/M5 Frz-CWReset?
Reset Mot5 Vlv Fail m5_reset_freeze_5
Off No, Yes TRUE
M5 in CWR Alm? (/)
Module 5 Leaving Cond Water
Alarm
m5_cwr_alrm_5
No No, Yes FALSE
M6 inFreezAlm?
Module 6 Freeze Alarm m6_freeze_alrm_5
No No, Yes FALSE
/M6 Frz-CWReset?
Reset Mot6 Vlv Fail m6_reset_freeze_5
Off No, Yes TRUE
M6 in CWR Alm? (/)
Module 6 Leaving Cond Water
Alarm
m6_cwr_alrm_5
No No, Yes FALSE
LINK(S): PREV, SYSTEM SETUP, HOME
RESET COMP RUNTIME & CYCLES
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
Reset Compr Runtime & Cycles Menu
M1C1Reset Runtm
M1C1 Runtime Reset m1reset_c1_rtim_5
Off No, Yes TRUE
/M1C1Reset Cyc
M1C1 Cycles Reset m1c1_cycles_reset_5
Off No, Yes TRUE
M2C1Reset Runtm
M2C1 Runtime Reset m2reset_c1_rtim_5
Off No, Yes TRUE
/M2C1Reset Cyc
M2C1 Cycles Reset m2c1_cycles_reset_5
Off No, Yes TRUE
M3C1Reset Runtm
M3C1 Runtime Reset m3reset_c1_rtim_5
Off No, Yes TRUE
/M3C1Reset Cyc
M3C1 Cycles Reset m3c1_cycles_reset_5
Off No, Yes TRUE
M4C1Reset Runtm
M4C1 Runtime Reset m4reset_c1_rtim_5
Off No, Yes TRUE
/M4C1Reset Cyc
M4C1 Cycles Reset m4c1_cycles_reset_5
Off No, Yes TRUE
M5C1Reset Runtm
M5C1 Runtime Reset m5reset_c1_rtim_5
Off No, Yes TRUE
/M5C1Reset Cyc
M5C1 Cycles Reset m5c1_cycles_reset_5
Off No, Yes TRUE
M6C1Reset Runtm
M6C1 Runtime Reset m6reset_c1_rtim_5
Off No, Yes TRUE
/M6C1Reset Cyc
M6C1 Cycles Reset m6c1_cycles_reset_5
Off No, Yes TRUE
LINK(S): PREV, SYSTEM SETUP, HOME
RESET MODULE SENSOR OOR ALARMS
Screen Display
Content BACnet Object
Default Min. Value Max. Value Editable
CoolLogic Reset Module Sensor OOR Alms
M1C1 inOOR Alm?
Module 1 Comp 1 Sensor OOR m1_comp1_oor_5
Off No, Yes FALSE
/ Reset M1 OOR?
M1 Sensor OOR Reset m1_oorsl_reset_5
Off No, Yes TRUE
M2C1 inOOR Alm?
Module 2 Comp 1 Sensor OOR m2_comp1_oor_5
Off No, Yes FALSE
/ Reset M2 OOR?
M2 Sensor OOR Reset m2_oorsl_reset_5
Off No, Yes TRUE
M3C1 inOOR Alm?
Module 3 Comp 1 Sensor OOR m3_comp1_oor_5
Off No, Yes FALSE
/ Reset M3 OOR?
M3 Sensor OOR Reset m3_oorsl_reset_5
Off No, Yes TRUE
M4C1 inOOR Alm?
Module 4 Comp 1 Sensor OOR m4_comp1_oor_5
Off No, Yes FALSE
/ Reset M4 OOR?
M4 Sensor OOR Reset m4_oorsl_reset_5
Off No, Yes TRUE
