Instruction Manual
Table Of Contents

CD8620-Series/CD6620-Series
ClearCube Technology, Inc. www.clearcube.com (866) 652-3500 1 of 5
Overview
Package
Contents
CD8620- or CD6620-series thin client
Pedestal and thumb screw
Power adapter and power cable
This Quick Start Guide
Specifications
Processor: Intel Atom D2550 Dual Core 1.86 GHz
Chipset: Intel NM10
Memory: 1 × SODIMM, DDR3, up to 4 GB
Graphics: Integrated in Atom D2550
Audio: HD Audio VIA 1708S
Network: All models: 10/100/1000BASE-T Ethernet (RJ45)
CD6620-series also includes one of the following:
1000BASE-SX, LC connector (fiber SFP module)
10/100BASE-FX, LC connector (fiber SPF module)
1000BASE-T Ethernet (RJ45 SPF module)
Smart Card Reader: Models CD8624 and CD6624 only
BIOS: AMI UEFI BIOS (16 Mb SPI ROM)
USB: 4 × USB 2.0, 2 × USB 3.0
Storage: Flash SATA SSD module, up to 32 GB
Power: DC in 12 V/4 A external power adapter
Dimension: 230 mm (H) × 210 mm (D) × 57 mm (W)
Continued on next page
