Installation Guide

INSTALLATION
CLEARVIEW GLASS RAILINGS • 737 Quentin Avenue South • Lakeland, MN 55043 • ClearViewGlassRailings.com
Part Number
CVGR 316 SSOD48-180
Satin Finish
Product Name
Round Deck Mount
Spigot
Spigot Size
1.9” diameter x 7.1” tall
Spigot Weight
5.5 lbs.
Glass Thickness/
Dimensions/Weight
(per panel)
1/2”/ 60” width x 39.37”
height/98.5 lbs.
Accessories
Included
Base Cover, Rubber
Gasket
Wood Deck Installation
We suggest using 3/8” diameter x 3.5” long lag bolts with flat washer to fasten spigots to wood deck. Lag bolts and
washer should be cadmium plated or stainless steel so they do not rust.
Lag bolts must be installed into rim joists or lam beam or properly blocked sub structure. If lag bolts are attached to
deck planks only failure will occur as a result of improper installation. Improper installation and failure may result in
injuries or death. Do it once and do it right!
ClearViewClearView
GLASS RAILINGS
G
C
ClearViewClearView
GLASS RAILINGS
G
C
ClearViewClearView
GLASS RAILINGS
G
C
Helpful Installation Tips
• Apply a bit of talcum powder to the inside of the spigot rubber boot to help the glass slide in the rubber
boot, not grab the rubber boot.
• Mark spigot location on glass panels with a crayon or wax marker. This allows for fast and easier installation
of panel in proper location.
• Some clients have suggested screwing the rim joist to the joist as the screws will hold the rim joist tight to the joist
where as nails may not.
