Clear-Com
Eclipse Omega Instruction Manual
6-5
LMC-64 INTERFACE REAR CONNECTIONS
The LMC-64 interface rear card contains eleven RJ45 connectors; 8
E1/T1 ports (not used), 2 DECT sync ports (not used) and a LAN port.
Figure 6-2: LMC-64 Interface Rear Card
The E1/T1 and DECT ports are not used on the LMC-64 interface and
should not be connected.
LAN Port (RJ-45)
DECT port (not used)
DECT port (not used)
Port 1 (not used)
Port 2 (not used)
Port 3 (not used)
Port 4 (not used)
Port 5 (not used)
Port 6 (not used)
Port 7 (not used)
Port 8 (not used)
