Clear-Com
Eclipse Omega Instruction Manual
6-4
Status Lights
When lit, a “status” light indicates successful communication between
an E1/T1 port on the LMC-64 interface and a connected E1/T1 device
such as an active antenna or splitter. Normally no E1/T1 devices are
connected to an LMC-64 interface and these lights will not be active.
LAN Data Light
The green “LAN DATA” light illuminates to indicate there is data
passing through the LAN port.
LAN Link Light
The amber “LAN LINK” light illuminates to indicate a connection to the
LAN port. This light must be on for IP connectivity.
3
4
5
