Eclipse Omega Instruction Manual
5-2
IVC-32 CARD FRONT-PANEL LIGHTS AND BUTTONS
Reset Button
Pressing the reset button causes the card and all links to momentarily
stop their current activity and to restart.
During the reset, configuration information downloads to the card from
the CPU card. If the entire system is operating except for one IVC-32
interface press the reset button for that card only.
Note: The reset button is slightly recessed from the front panel to
prevent it from being accidentally pressed. A tool such as a
bent paper clip is required to press this button.
Power Supply & Status Lights
+3.3-Volt Power Supply Light
The matrix’s +3.3-volt power supply provides electric current to this
green light. When lit, the light indicates that the +3.3-volt supply is
present and supplying power to the card.
