E1 TO FREESPEAK/CELLCOM ANTENNA PINOUT
CAT5 cables for connecting an E-QUE card to an antenna or splitter
are straight through cables. The E1 pinout for connection to an
antenna or splitter is shown in Table 7-4. The cable wiring is shown in
Table 7-5.
Table 7-4: FreeSpeak/CellCom E1 Cable Pinout
Table 7-5: E1 to Antenna Cable
PIN DESCRIPTION
1Tx+
2Tx-
3* DECTSYNC+
4Rx+
5Rx-
6* DECTSYNC-
7* GND
8* 12V
MATRIX 1 PIN ANTENNA PIN
1to1
2to2
3to3
4to4
5to5
6to6
7to7
8to8
