E1/T1 MATRIX TO MATRIX CROSSOVER CABLE
For E1 and T1 direct matrix to matrix connections the CAT5 crossover
cables should be wired as shown in Table 7-2.
Table 7-2: E1/T1 Crossover Cable
E1/T1 STRAIGHT CABLE CONNECTIONS
Table 7-3: Connections for E1/T1 Straight Cables
E1/T1 straight cables may be used to connect E1 or T1 ports to E1 or
T1 networks or third party equipment.
MATRIX 1 PIN MATRIX 2 PIN
1to4
2to5
3 not connected 3
4to1
5to2
6 not connected 6
7 not connected 7
8 not connected 8
MATRIX 1 PIN NETWORK PIN
1to1
2to2
3 not used 3
4to4
5to5
6 not used 6
7 not used 7
8 not used 8
