10. Product specification
10.1. Technical details
Product category ITL (Intelli-tank level)
Voltage range
+9VDC…+16VDC (12V display p/n 113739)
+9VDC…+32VDC (24V display p/n 114378) LEDs will be dimmer at voltages less than 16V.
Power consumption
@13.8VDC
@27.6VDC
205 mA (12V display p/n 113739)
200 mA (24V display p/n 114378)
Operational temperature range -40ºC…+85ºC
Environmental range IP 67
CAN specification SAE J1939 proprietary, 250 Kbits/second
1-Wire specification Class 1 proprietary, 425 bits/second
Protection
Internal thermal fuse
Reverse voltage protection (pins 1 and 2 of connector)
CAN buses protected to 24V
ESD voltage protected to SAE J1113 specification for heavy duty trucks
Transient voltage protected to SAE J1113 specification for heavy duty trucks
Dimensions (W x H x D) in inches [mm] 2.75 [69.85] x 3.75 [95.25] x 2.06 [52.32]
Weight in ounces 6.7
10.2. WEEE (Waste of Electrical and Electronic Equipment) directive
This symbol [crossed-out wheeled bin WEEE Annex IV] indicates separate collection of waste electrical and
electronic equipment in the European Union countries.
Please do not throw the equipment into the domestic refuse.
Each individual European Union member state has implemented the WEEE regulations into national law in
slightly different ways. Please follow your national law when you want to dispose of any electrical or electronic
products.
More details can be obtained from your national WEEE recycling agency.
10.3. CE statement
This device complies with the European Regulations for Electromagnetic Compatibility (EMC) of the European
Union and it is equipped with the CE mark. This unit must be used in accordance with the details specified within
this manual.
