Owner's manual NX602 Navigation
Thank you for choosing the Clarion NX602 as your navigator. Start using Clarion NX602 right away. This document is the detailed description of the navigation software. You can easily discover Clarion Mobile Map while you are using it; however, we still recommend that you read this manual to fully understand the features and functions. Easy navigation map updates It is easy to keep the navigation system up to date.
Table of contents 1. Warnings and Safety information .......................................................................................... 6 2. Getting started.......................................................................................................................... 7 2.1 Buttons and other controls on the screen ........................................................................................... 8 2.1.1 Using keyboards...............................................................
3.1.2.3 Searching for a Place of Interest by category..................................................................................................... 46 3.1.2.4 Searching for a Place of Interest by name .......................................................................................................... 48 3.1.2.5 Searching for a Place of Interest by its Phone Number ...................................................................................... 51 3.1.2.
.1.7 Speed limit warning ..................................................................................................................................81 5.2 'More' menu ...................................................................................................................................... 81 5.3 Settings menu.................................................................................................................................... 82 5.3.1 Sound and Warnings ....................
1. Warnings and Safety information The navigation system helps you find your way to your destination with a connected GPS receiver. Clarion Mobile Map does not transmit your GPS position; others cannot track you. It is important that you look at the display only when it is safe to do so. If you are the driver of the vehicle, we recommend that you operate Clarion Mobile Map before you start your journey. Plan the route before your departure and stop if you need to change the route.
2. Getting started Clarion Mobile Map is optimized for in-car use. You can use it easily by tapping the screen buttons and the map with your fingertips. When using the navigation software for the first time, an initial setup process starts automatically. Do as follows: 1. Select the written language of the application interface. Later you can change it in Regional settings (page 93). 2. Read the End User License Agreement. Tap 3. The Configuration wizard starts. Tap 4.
7. The initial setup is now complete. The Configuration wizard can be restarted later from the Settings menu (page 82). After the initial setup, the Map screen appears and you can start using Clarion Mobile Map. 2.1 Buttons and other controls on the screen When you are using Clarion Mobile Map, you usually tap buttons on the touch screen. Type Example Description How to use it Button Tap it to initiate a function, to open a new screen, or to set a parameter.
Switch When there are only two choices, a checkmark shows whether the feature is enabled. Slider When a feature can be set to different values in a range, Clarion Mobile Map shows an indicator on a gauge that displays and sets the value. Alphabetic and alphanumeric keyboards to enter text and numbers. Virtual keyboard Tap it to turn the switch on or off. • Drag the handle to move the slider to its new position. • Tap the slider where you want the handle to appear; the thumb jumps there.
Entering numbers and symbols to switch to a keyboard offering numeric and symbol Tap characters. Finalizing the keyboard entry (accepting the suggested search result) Finalizing the keyboard entry (opening the list of search results) Tap . Tap . Tap . Tap . Finalizing the keyboard entry (saving your input) Canceling the keyboard entry (returning to the previous screen) 2.1.2 Beyond single screen tap You usually need to tap the screen only once.
Gestures (drag&drop) You need to drag and drop the screen only in cases like: • Moving the handle on a slider. • Scrolling the list: grab the list anywhere and slide your finger up or down. Depending on the speed of the sliding, the list will scroll fast or slow, only a bit or till the end. • Moving the map in map browsing mode: grab the map, and move it in the desired direction. 2.2 Map screen 2.2.
There are screen buttons and data fields on the screen to help you navigate. During navigation, the screen shows route information. By default, only one data field is displayed in the bottom right corner. Tap this field to see all route data fields. Tap any of the data fields to suppress others and display only the selected one. The data fields are different when you are navigating an active route and when you have no specified destination (the orange line is not displayed).
2.2.2 Position markers 2.2.2.1 Vehimarker and Lock-on-Road When your GPS position is available, Clarion Mobile Map marks your current position with the Vehimarker. By default, this marker is a red arrow, but you can change this icon in Settings. When on-road navigation is selected, the Vehimarker may not show your exact GPS position and heading. If roads are near, it is aligned to the nearest road to suppress GPS position errors, and the direction of the icon is aligned to the direction of the road.
2.2.3.2 Turn preview and Next street When navigating a route, the top section of the Map screen shows information about the next route event (maneuver) and the next street or the next city/town. There is a field in the top left corner that displays the next maneuver. Both the type of the event (turn, traffic circle, exiting freeway, etc.) and its distance from the current position are displayed. A smaller icon shows the type of the second next maneuver if it is near the first one.
Enter traffic circle (second next maneuver). Enter freeway. Exit freeway. Board ferry. Leave ferry. Approaching a waypoint. Approaching the destination. 2.2.3.3 Lane information and Signposts When navigating on multi-lane roads, it is important to take the appropriate lane in order to follow the recommended route. If lane information is available in the map data, Clarion Mobile Map displays the lanes and their directions using small arrows at the bottom of the map.
2.2.3.4 Junction view If you are approaching a freeway exit or a complex intersection and the needed information exists, the map is replaced with a 3D view of the junction. The lanes you need to take are displayed with arrows. Signposts can also be present if information is available. If you want to hide the currently displayed junction, tap the picture and the Map screen returns. 2.2.3.5 Freeway exit services You may need a gas station or a restaurant during your journey.
2.2.3.6 3D object types Clarion Mobile Map supports the following 3D object types: Type Description 3D terrain 3D terrain map data shows changes in terrain, elevations or depressions in the land when you view the map in 2D, and use it to plot the route map in 3D when you navigate. Hills and mountains are shown in the background of the 3D map, and illustrated by color and shading on the 2D map.
2.2.4 Manipulating the map Tap the map anywhere to browse it during navigation. The map stops following the current position (the Vehimarker, a red arrow by default, is not locked in a fix position on the screen any more) and control buttons appear to help you modify the map view. Action Moving the map with drag&drop Button(s) No buttons Zooming in and out , Description You can move the map in any direction: tap and hold the map, and move your finger towards the direction you want to move the map.
Compass in 3D map view mode , The direction of the compass shows North. Tap the button to switch to North-up view, and then tap again to rotate the map in the previous direction. Location information Tap this button to open a new screen with information about the selected map point, the Cursor. Return to normal navigation Tap this button to move the map back to follow the current GPS position. Automatic map rotation is also re-enabled. The map manipulation buttons disappear and navigation continues.
This button opens the list of your Favorite destinations. Find / Favorite (page 54) This button opens the History list. You can select one of your Find / History (page 56) previous destinations. This button opens the route editing function. My Route / Edit Route This button opens the route related settings. More / Settings / Route Settings (page 86) This button opens the map related settings.
This button opens the list of maneuvers (the itinerary). With this function you can save the active route for later use. Tap the top of the Map screen during navigation. My Route / More / Save Route With this function you can replace the active route with a My Route / More / Load Route previously saved route. With this function you can search for Places of Interest in various Find / Find Places (page 42) different ways.
2.2.6 Checking the details of the current position (Where Am I?) This screen contains information about the current position (or about the last known position if GPS reception is not available) and a button to search for useful Places nearby. . You can access this screen from the map in one of the following ways: • If the current street is displayed below the Vehimarker (the current position on the map), tap it to open the Where Am I? screen. • Open the Quick menu and tap the button.
The following services can be searched around the current position or the last known position: • : Car repair and roadside assistance services • : Police stations • : Medical and emergency services • : Gas stations Tap any of the buttons, select a Place from the list, and navigate to it. 2.3 Navigation Menu You can reach all parts of Clarion Mobile Map from the Navigation Menu.
• to customize the way the navigation software works, to simulate demo Tap routes or to run some additional applications. • to start navigating on the map. The button itself is a miniature live map Tap that shows your current position, the recommended route and the surrounding map area. Tap the button to enlarge the map to the full screen.
3 On-road navigation When first started, Clarion Mobile Map calculates routes using the road network of the high quality vector maps provided with the product. You can set up your route in different ways: • If you need a route for immediate navigation, you can select the destination and start navigating to it right away (normal navigation).
3.1.1.1 Entering an address (United States) To enter an address as the destination, do as follows: to return to the Navigation Menu. 1. If you are on the Map screen, tap 2. In the Navigation Menu, tap the following buttons: 3. By default, Clarion Mobile Map proposes the country and state where you are. If needed, tap , . , enter the first few letters of the destination country or state on the keyboard, and select one from the list.
5. Enter the street name: a. Tap b. Start entering the street name on the keyboard. c. Find the street you need: . • The most likely street name is always shown in the input field. To accept it, tap • If the desired name does not show up, the names that match the string appear in a list after entering a couple of characters (to open the list of results before it appears ). Select the street from the list. automatically, tap 6. 7. . Enter the house number: . a. Tap b.
8. After a short summary of the route parameters, the map appears showing the entire route. The to modify route parameters, or tap route is automatically calculated. Tap and start your journey. Tip! If you know that you will use this destination frequently, before tapping to confirm the destination, put it on the list of your Favorites first: tap then , give a name for the new Favorite, and to save the location. The map with the destination returns tap automatically.
4. If needed, select a new city/town: a. Tap b. Start entering the name of the city/town on the keyboard. c. Find the city/town you need: • . The most likely city/town name is always shown in the input field. To accept it, tap . • If the desired name does not show up, the names that match the string appear in a list after entering a couple of characters (to open the list of results before it appears ). Select the city/town from the list. automatically, tap 5. Enter the street name: . a.
6. 7. Enter the house number: . a. Tap b. Enter the house number on the keyboard. (To enter letters, tap c. to finish entering the address. (If the entered house number Tap cannot be found, the midpoint of the street is selected as the destination.) ). A full screen map appears with the selected point in the middle. If necessary, tap the map somewhere else to modify the destination. The Cursor ( to confirm the destination, or tap ) appears at the new location.
3.1.1.3 Entering an address (Mexico) To enter an address as the destination, do as follows: to return to the Navigation Menu. 1. If you are on the Map screen, tap 2. In the Navigation Menu, tap the following buttons: 3. By default, Clarion Mobile Map proposes the country and city/town where you are. If needed, tap , . , enter the first few letters of the country name on the keyboard, and select one country from the list of results. 4. If needed, select a new city/town: . a. Tap b.
5. Enter the street name: . a. Tap b. Start entering the street name on the keyboard. c. Find the street you need: • The most likely street name is always shown in the input field. To accept it, tap • If the desired name does not show up, the names that match the string appear in a list after entering a couple of characters (to open the list of results before it appears ). Select the street from the list. automatically, tap 6. 7. . Enter the house number: . a. Tap b.
8. After a short summary of the route parameters, the map appears showing the entire route. The route is automatically calculated. Tap to modify route parameters, or tap and start your journey. 3.1.1.4 Entering an address starting with the street name (in the United States only) You can leave the city/town name empty and start the search with the street name. This way you can search in all streets of a state. Do as follows: to return to the Navigation Menu. 1. If you are on the Map screen, tap 2.
• If the desired name does not show up, the names that match the string appear in a list after entering a couple of characters (to open the list of results before it appears ). Select the street from the list. automatically, tap 5. 6. Enter the house number: . a. Tap b. Enter the house number on the keyboard. (To enter letters, tap c. to finish entering the address. (If the entered house number Tap cannot be found, the midpoint of the street is selected as the destination.) ).
7. After a short summary of the route parameters, the map appears showing the entire route. The route is automatically calculated. Tap to modify route parameters, or tap and start your journey. 3.1.1.5 Entering the midpoint of a street as the destination You can navigate to the midpoint of a street if the house number is not available: to return to the Navigation Menu. 1. If you are on the Map screen, tap 2. In the Navigation Menu, tap the following buttons: 3.
. The midpoint of the street is 5. Instead of entering the house number, tap selected as the destination. 6. A full screen map appears with the selected point in the middle. If necessary, tap the map somewhere else to modify the destination. The Cursor ( ) appears at the new location. Tap to confirm the destination, or tap to select a different destination. 7. After a short summary of the route parameters, the map appears showing the entire route. The route is automatically calculated.
c. Find the street you need: • The most likely street name is always shown in the input field. To accept it, tap • If the desired name does not show up, the names that match the string appear in a list after entering a couple of characters (to open the list of results before it appears ). Select the street from the list. automatically, tap 5. Enter the intersecting street name: 1. 6. . Tap . • If only a few intersecting streets exist, their list appears immediately.
3.1.1.7 Selecting a city/town center as the destination The city/town center is not the geometric center of the city/town but an arbitrary point the map creators have chosen. In towns and villages, it is usually the most important intersection; in larger cities, it is one of the important intersections. to return to the Navigation Menu. 1. If you are on the Map screen, tap 2. In the Navigation Menu, tap the following buttons: 3. Select the country and state as described earlier (page 26). 4.
5. Instead of entering the street name, tap city/town becomes the destination of the route. 6. A full screen map appears with the selected point in the middle. If necessary, tap the map . This way the center of the displayed ) appears at the new location. Tap somewhere else to modify the destination. The Cursor ( to confirm the destination, or tap to select a different destination. 7. After a short summary of the route parameters, the map appears showing the entire route.
to open the numeric keypad. b. Tap c. Start entering the ZIP code. d. Find the city/town you need: • The most likely ZIP code is always shown in the input field. To accept it, tap • If the desired number does not show up, open the list of results by tapping . . Select the ZIP code from the list. 5. Enter the street name: . a. Tap b. Start entering the street name on the keyboard. c. Find the street you need: • The most likely street name is always shown in the input field.
c. 7. Tap to finish entering the address. (If the entered house number cannot be found, the midpoint of the street is selected as the destination.) A full screen map appears with the selected point in the middle. If necessary, tap the map somewhere else to modify the destination. The Cursor ( to confirm the destination, or tap ) appears at the new location. Tap to select a different destination. 8. After a short summary of the route parameters, the map appears showing the entire route.
• If one of the streets is shorter, search for that one first. You can then find the second one faster. • You can search for both the type and the name of a road. If the same word appears in several names, for example in the name of streets, roads and avenues, you can obtain the result faster if you enter the first letter of the street type: For example, enter 'PI A' to obtain Pine Avenue and skip all Pine Streets and Pickwick Roads. • You can also search in ZIP codes.
3. After entering a few letters, tap containing the entered character sequence. 4. (optional) The Places in the list are ordered by the length of the necessary detour (when navigating a route) or by their distance from the current position (when no destination is given). If you need to to open the list of Places with names . reorder the list, tap 5. Browse the list if necessary and tap one of the list items. A full screen map appears with the selected point in the middle.
3.1.2.2 Searching for a Place of Interest using preset categories The Preset search feature lets you quickly find the most frequently selected types of Places. 1. If you are on the Map screen, tap 2. In the Navigation Menu, tap the following buttons: 3. The preset search categories appear: • to return to the Navigation Menu. , . : • If an active route exists, gas stations are searched along the route.
• : • If an active route exists, accommodation is searched around the destination of the route. • If there is no active route (destination is not selected), they are searched around the current position. • If the current position is not available either (no GPS signal), they are searched around the last known position. 4. Tap any of the quick search buttons to get an instant list of Places. 5.
3.1.2.3 Searching for a Place of Interest by category You can search for Places of Interest by their categories and subcategories. to return to the Navigation Menu. 1. If you are on the Map screen, tap 2. In the Navigation Menu, tap the following buttons: 3. Tap 4. Select the area around which the Place should be searched for: 5. , . . • to search around the current position or if it is not available, Tap around the last know position.
6. Select one of the main Place categories (e.g. Accommodation) or tap Places around the selected location or along the route. 7. to list all Select one of the Place subcategories (e.g. Hotel or Motel) or tap Places in the selected main category around the selected location or along the route. 8. Sometimes the list of brands in the selected Place subcategory appears. Select one brand or tap to list all to list all Places in the selected subcategory around the selected location or along the route. 9.
11. Browse the list if necessary and tap one of the list items. A full screen map appears with the selected point in the middle. The name and address of the Place is displayed at the top of the screen. 12. (optional) Tap the map. to see the details of the selected Place. Tap to return to 13. If necessary, tap the map somewhere else to modify the destination. The Cursor ( at the new location. Tap to select a different destination. ) appears to confirm the destination, or tap 14.
• Tap to search for a place around the destination of the active route. (The result list will be ordered by the distance from the destination.) • to search along the active route, and not around a given point. Tap This is useful when you search for a later stopover that results in a minimal detour only, such as searching for upcoming gas stations or restaurants. (The result list will be ordered by the length of the necessary detour.) , select the city/town to search in. 5.
if you have not done it before. 8. Tap 9. Using the keyboard, start entering the name of the Place. 10. After entering a few letters, tap containing the entered character sequence. to open the list of Places with names 11. (optional) The Places in the list are ordered by their distance from the current or last known position, from the selected city/town, from the destination or by the length of the necessary detour. If you need to reorder the list, tap . 12.
15. After a short summary of the route parameters, the map appears showing the entire route. The route is automatically calculated. Tap to modify route parameters, or tap and start your journey. 3.1.2.5 Searching for a Place of Interest by its Phone Number You can search for Places of Interest by their phone number: to return to the Navigation Menu. 1. If you are on the Map screen, tap 2. In the Navigation Menu, tap the following buttons: 3. The numeric keyboard appears.
9. If necessary, tap the map somewhere else to modify the destination. The Cursor ( ) appears to confirm the destination, or tap at the new location. Tap to select a different destination. 10. After a short summary of the route parameters, the map appears showing the entire route. The to modify route parameters, or tap route is automatically calculated. Tap and start your journey. 3.1.2.
• : Medical and emergency services • : Police stations • : Gas stations 4. Tap any of the quick search buttons to get an instant list of that type of Places. 5. (optional) The Places in the list are ordered by their distance from the current or last known position, from the selected city/town, from the destination or by the length of the necessary detour. If you need to reorder the list, tap . 6. Browse the list if necessary and tap one of the list items.
3.1.3 Selecting a map location as the destination 1. If you are on the Map screen, tap to return to the Navigation Menu. 2. In the Navigation Menu, tap the following buttons: 3. Locate your destination on the map: move and scale the map as needed. 4. Tap the location that you want to select as your destination. The Cursor ( 5. Tap 6. After a short summary of the route parameters, the map appears showing the entire route. The , . ) appears. to select the Cursor as the destination.
2. Tap 3. Tap the Favorite that you want to set as your destination. If necessary, browse down to see more . The list of Favorite destinations is displayed. and enter a few letters from the name of the Favorite of the list or tap destination. 4. A full screen map appears with the selected point in the middle. If necessary, tap the map ) appears at the new location. Tap somewhere else to modify the destination. The Cursor ( to confirm the destination, or tap to select a different destination. 5.
• 2. and then tap If you are in the Navigation Menu, tap . A full screen map appears with the selected point in the middle. If necessary, tap the map ) appears at the new location. Tap somewhere else to modify the destination. The Cursor ( to confirm the destination, or tap to select a different destination. 3. After a short summary of the route parameters, the map appears showing the entire route. The to modify route parameters, or tap route is automatically calculated. Tap and start your journey.
3. Select a destination from the list. 4. A full screen map appears with the selected point in the middle. If necessary, tap the map somewhere else to modify the destination. The Cursor ( ) appears at the new location. Tap to confirm the destination, or tap to select a different destination. 5. After a short summary of the route parameters, the map appears showing the entire route. The to modify route parameters, or tap route is automatically calculated. Tap and start your journey. 3.1.
then and enter the coordinate 5. (optional) If necessary, tap in UTM format. 6. When finished, tap 7. A full screen map appears with the selected point in the middle. If necessary, tap the map . somewhere else to modify the destination. The Cursor ( ) appears at the new location. Tap to confirm the destination, or tap to select a different destination. 8. After a short summary of the route parameters, the map appears showing the entire route.
5. A full screen map appears with the selected point in the middle. If necessary, tap the map somewhere else to modify the destination. The Cursor ( ) appears at the new location. Tap to confirm the destination, or tap to select a different destination. 6. After a short summary of the route parameters, the map appears showing the entire route. The to modify route parameters, or tap route is automatically calculated. Tap and start your journey.
to select the destination. 5. Tap 6. The Destination menu appears and you can select the destination of the route the same way as described in the previous sections. 7. When the new destination is selected, the list returns. 8. To add more destinations, tap repeat the above procedure. where you want to insert the new route point in the list, and 3.2 Viewing the entire route on the map It is easy to get a map overview of the active route. Do as follows: to return to the Navigation Menu. 1.
3.3 Checking route parameters and accessing route related functions You can check different parameters of the route recommended by Clarion Mobile Map. to return to the Navigation Menu. 1. If you are on the Map screen, tap 2. In the Navigation Menu, tap 3. The following pieces of information are displayed: 4. . • The name and/or address of the destination. • Warning icons (if any). They provide extra information about your route (e.g. unpaved roads or toll roads to be taken).
3.4 Modifying the route When navigation is already started, there are several ways to modify the active route. The following sections show some of those options. 3.4.
3. If you already have a route, tap . If you are starting a new route, tap . and confirm 4. The first line is the start of the route, normally the current GPS position. Tap your action at the warning message. 5. The Destination menu appears and you can select the start point of the route the same way you select a destination. 6. When the new start point is set, tap 7. The map returns with a transparent Vehimarker (showing that there is no GPS reception).
8. . To return to normal navigation, tap 3.4.3 Editing the list of destinations (Edit Route) You can edit the route by modifying the list of destinations. You can add or remove destinations, modify the start position or reorder the list. 1. If you are on the Map screen, tap 2. In the Navigation Menu, tap 3. Tap 4. You have the following options: to return to the Navigation Menu. . . • Tap to add a new destination. • Tap to delete a destination. • Tap • to reorder the list.
3.4.4 Pausing the active route You do not need to pause the active route: when you start driving again, Clarion Mobile Map restarts the voice instructions from your position. 3.4.5 Canceling the active route To cancel the navigated route, do one of the following: • If you are on the Map screen, tap you need to tap • and then tap . (If you have a route with waypoints, until all waypoints are deleted.) In the Navigation Menu, tap route is deleted with all its waypoints. and then tap ..
4. You see the basic details of three route alternatives with the selected route planning method. Tap any of them to see it on the map. 5. Or if you cannot find a good alternative, tap different routing methods. 6. to return to the previous screen. Select one of the route alternatives and tap Clarion Mobile Map recalculates the route. The orange line now shows the new recommended route. and scroll down for routes with 3.4.
3. Tap . 4. Tap . 5. You see the basic details of three route alternatives with the selected route planning method. Tap any of them to see it on the map. 6. Or if you cannot find a good alternative, tap different routing methods. 7. for a few seconds to Select one of the route alternatives then tap and hold return to the Map screen. Clarion Mobile Map recalculates the route. The orange line now shows the new recommended route.
3.4.8 Changing the vehicle used in route planning To recalculate the active route for a different vehicle, do as follows. These changes can also be made in Settings (page 86). 1. On the Map screen, tap 2. Tap and then tap . and then tap one of the following: • • • • 3. Clarion Mobile Map recalculates the route optimized for the new vehicle type. The orange line now shows the new recommended route. 3.4.
2. 3. Tap any of the listed road types to modify the route. If needed, scroll the list for all road types. You have the following options (their order depends on the selected vehicle type): • - You might need to avoid freeways when you are driving a slow car or you are towing another vehicle. • - Charge roads are pay roads where you can purchase a pass or vignette to use the road for a longer period of time. They can be enabled or disabled separately from toll roads.
3.5 Saving a location as a Favorite destination You can add any location to Favorites, the list of frequently used destinations. Planning a route to one of the Favorite destinations is described on page 54. 1. Select a destination as described before. It can be an address, a Place, any location on the map, a previously used destination from History, etc. 2. When the full screen map appears with the selected location in the middle, tap . . 3. Tap 4.
3.6 Saving a location as an alert point You can save any map location as an alert point (for example a speed camera or a railroad crossing). 1. Browse the map and select a location. The red Cursor appears there. 2. Tap 3. Scroll down the list and tap 4. On the newly opened screen, select the type of the alert point, the direction from which you expect the alert, and (if applicable) the speed limit for this alert point. 5. Tap . . to save the location as a new alert point.
3.7 Editing an alert point You can edit a previously saved or uploaded alert point (for example a speed camera or a railroad crossing). 1. Browse the map and select the alert point to edit. The red circle appears around the alert point. 2. Tap 3. Scroll down the list and tap 4. On the newly opened screen, modify the type of the alert point, the direction from which you expect the alert, or (if applicable) the speed limit for this alert point. 5. Tap 72 NX702 English . .
3.8 Watching the simulation of the route You can run a simulated navigation that demonstrates the active route. Do as follows: to return to the Navigation Menu. 1. If you are on the Map screen, tap 2. In the Navigation Menu, tap 3. Tap 4. . The simulation starts from the starting point of the Scroll down the list and tap route, and using a realistic speed, it leads you through the whole recommended route. . .
1. (optional) You have the following controls during the simulation (the control buttons disappear after a few seconds but you can open them again if you tap the map): • : Jump to the next route event (maneuver). • : Pause the simulation. • : Jump to the previous route event (maneuver). • 2. : Tap to increase the speed of the simulation to 4, 8 or 16 times faster. Now tap again to return to the normal speed. Tap 74 NX702 English to stop the simulation.
4 Off-road navigation When first started, Clarion Mobile Map calculates routes using the road network of the high quality vector maps provided with the product. You can switch the application to off-road mode in Navigation settings in one of the following ways: • , From the Main menu, tap , and then . • From the Map screen, tap , and then . Most of the procedures described for on-road navigation also apply to off-road navigation.
5 Reference Guide On the following pages you will find the description of the different concepts and menu screens of Clarion Mobile Map. 5.1 Concepts 5.1.1 Smart Zoom Smart Zoom provides much more than just a usual automatic zoom feature: • While following a route: when approaching a turn, it will zoom in and raise the view angle to let you easily recognize your maneuver at the next junction.
5.1.3 Tunnel view When entering a tunnel, the map is replaced with a generic tunnel image so that surface roads and buildings cannot distract you. The top-down overview of the tunnel helps you orient yourself. The remaining distance in the tunnel is also displayed. After leaving the tunnel, the original map view returns. This feature can be turned off in Settings (page 92). 5.1.
• Vehicle types: When creating a new vehicle profile, select one of the below vehicle types. Besides the below mentioned conditions, dimension, weight and freight hazard restrictions can also be taken into account when planning a route. • : • Maneuver restrictions and directional constraints are taken into account when planning a route. • Roads are used only if access for cars is allowed. • Private roads and resident-only roads are used only if they are inevitable to reach the destination.
• • U-turns are excluded from routes (turning back on a divided road is not considered as a U-turn). Road types used or avoided in route calculation: • • • • • • Clarion Mobile Map automatically recalculates the route if you deviate from the proposed itinerary. For further information about Route settings, see page 86. 5.1.5 Green routing Route calculation is not only about finding the quickest or shortest route.
If the selected route planning method is not Green, and you have allowed the application to show the green alternative, the price, fuel consumption and CO2 emission differences between your selected route and the Green route are also shown on this screen: Tap the field with these details to switch the route to Green immediately. 5.1.
5.1.7 Speed limit warning Maps may contain information about the speed limits of the road segments. Clarion Mobile Map is able to warn you if you exceed the current limit. This information may not be available for your region (ask your local dealer), or may not be fully correct for all roads in the map. The maximum speed set in the vehicle profile is also used for this warning. Clarion Mobile Map alerts you if you exceed the preset value even if the legal speed limit is higher.
The scientific calculator helps you in all your calculation needs. Tap the Mode button for additional functions and use the memory to save your results. The Fuel consumption monitor helps you keep track of the consumption of your car even if you do not use navigation for all your journeys. Set the initial odometer value and then record the distance taken and fuel filled in whenever you fill your car. You can also set reminders for regular car maintenance.
Button Description Adjust the sound volume, mute your device or change the voice guidance language. In addition, you can enable and set up different warnings and alerts. The content of the Quick menu (page 19) is fully customizable. Tap the button you want to change, and select its new function from the list. These settings determine how routes will be calculated. Select the type of vehicle you are driving, the road types used in route planning, and the route planning method.
5.3.1 Sound and Warnings Adjust the different sounds of the application or change the voice guidance language. In addition, you can enable and set up different warnings and alerts. Button Description Tap this button to adjust the volume of the different sounds in the application. A new screen shows the different sound types and their controls. See below for details. This button shows the current voice guidance profile.
Maps may contain information about the speed limits of the road segments. Clarion Mobile Map is able to warn you if you exceed the current limit. This information may not be available for your region (ask your local dealer), or may not be fully correct for all roads in the map. The maximum speed set in the vehicle profile is also used for this warning. Clarion Mobile Map alerts you if you exceed the preset value even if the legal speed limit is higher.
5.3.2 Customize Quick menu The content of the Quick menu (page 19) is fully customizable. Tap the button you want to change, and select its new function from the list. The list of available functions and their descriptions are on page 19. 5.3.3 Route settings These settings determine how routes will be calculated. Button Description You can set the type of vehicle you will use to navigate the route.
Clarion Mobile Map includes toll roads (pay roads where there is a per-use charge) in the routes by default. If you disable toll roads, Clarion Mobile Map plans the best toll-free route. Clarion Mobile Map includes ferries in a planned route by default. However, a map does not necessarily contain information about the accessibility of temporary ferries. You might also need to pay a fare on ferries.
Select the engine and fuel type of your vehicle. This helps in estimating the CO2 emission. Enter the average fuel price for travel cost calculation. The currency can be set in Regional Settings. Set the maximum speed you travel with the vehicle. Check this box to enable more settings for the below parameters. Set the total length of the vehicle. Set the width of the vehicle. Set the height of the vehicle. Set if there is a trailer attached to the vehicle. Set the maximum allowed weight of the vehicle.
• All maneuvers are available in intersections. • Directional constraints are taken into account the way that opposite direction is allowed with a low speed. • A private road is used only if the destination is there. • Walkways are excluded from routes. • : • Maneuver restrictions and directional constraints are taken into account when planning a route. • Roads are used only if access for buses is allowed. • Private roads, resident-only roads and walkways are excluded from routes.
Gives a quick but fuel efficient route based on the fuel consumption data given in Route settings (page 86). Travel cost and CO2 emission calculations are estimations only. They cannot take elevations, curves and traffic conditions into account. For vehicle types where Green routing is not available, this method combines the benefits of Fast and Short: Clarion Mobile Map calculates as if it were calculating the Fast route, but it takes other roads as well to save fuel.
Button Description Switch the map view between a 3D perspective view and a 2D top-down view. Adjust the basic zoom and tilt levels to your needs. Three levels are available. Switch between daytime and night color modes or let the software switch between the two modes automatically a few minutes before sunrise and a few minutes after sunset. Select the color scheme used in daytime mode. Select the color scheme used in night mode. Replace the default position marker to one of the 3D vehicle models.
5.3.6 Visual guidance settings Adjust how the software helps you navigate with different kinds of route related information on the Map screen. The data fields in the corner of the Map screen can be customized. Tap this button and select the values you want to see. The values can be different when you navigate a route from when you are just cruising without a given destination.
Similar to the above possibility, alternative routes can be suggested when driving on normal roads. Clarion Mobile Map will select a different turn in the upcoming intersection and offers you a different route for the next section of the route. Your options are the similar as above but you cannot modify the offered detour. Parking at the destination may not be easy in city areas. As you approach the destination, Clarion Mobile Map can offer parking category Places near your destination.
5.3.9 Trip monitor settings Trip logs contain useful information about your trips. Trip logs can be saved manually when you reach your destination or you can turn on the automatic saving here. You can access these logs in the Trip monitor. Trip monitor is available from the More menu. Trip monitor can record statistical data of your trips. If you need these logs later, you can let the application save them automatically for you. This is not a button.
6 Glossary 2D/3D GPS reception The GPS receiver uses satellite signals to calculate its (your) position and needs at least four signals to give a three-dimensional position, including elevation. Because the satellites are moving and because objects can block the signals, your GPS device might not receive four signals.
You can use digital maps interactively: you can zoom in and out (increase or decrease the scale), you can tilt them up and down, and rotate them left and right. In GPS-supported navigation, digital maps facilitate route planning. North-up map orientation In North-up mode the map is rotated so its top always faces North. This is the orientation for example in Find on Map. Road Safety Camera Special alert points for speed, red light or bus lane cameras. Different data sources are available.
7 End User License Agreement 1 The contracting parties 1.1 This Agreement has been entered into by and between NNG Kft. (registered seat: 23 Bérc utca, H1016 Budapest, Hungary; Company reg.no.: 01-09-891838) as Licensor (hereinafter: Licensor) and You as the User (hereinafter: User; the User and the Licensor jointly referred to as: Parties) in subject of the use of the software product specified in this Agreement. 2 Conclusion of the Agreement 2.
from the Database owners in order to utilize the Database, to offer it for utilization and to transfer it for utilization as set forth in this Agreement. 5.4 Pursuant to this Agreement, all rights vested in the Software Product shall remain in the ownership of the Licensor, except for those to which the User is entitled under law or by virtue of this Agreement. 6 Rights of the User 6.
8.5 The Licensor also draws the attention of the User to the fact that, when using the Software Product in any form of vehicle, observing the traffic regulations and rules (e.g. use of obligatory and/or reasonable and suitable security measures, proper and generally expected care and attention in the given situation, and special care and attention required due to the use of the Software Product) is the exclusive responsibility of the User.
Uploading is executed through Licensor’s special software or by the User navigation device, and the upload may be enabled or disabled by User. After successful data upload, the collected data is deleted from the Software Product storage media. 10.3 Collected data is transmitted, stored and handled anonymously and no connection of the data with the User shall be established by Licensor or any third party.
8 Copyright note The product and the information contained herein are subject to change without prior notification. This manual may not, in whole or in part, be reproduced or transmitted in any form either electronically or mechanically, including photocopying and recording, without the express written consent of Clarion. © 2011 - Clarion Data Source © 2006-2010 Tele Atlas. All rights reserved.
