MARINE CD RECEIVER

LECTEUR MARINE CD

RECEPTOR CD MARINO

RICEVITORE CD MARINO

M109

Owner’s manual

Mode d’emploi

Manual de instrucciones

Istruzioni per l’uso

01_M109_EN.book Page 1 Thursday, February 19, 2009 10:43 AM

Summary of content (21 pages)

PAGE 1
01_M109_EN.
PAGE 2
01_M109_EN.book Page 2 Thursday, February 19, 2009 10:43 AM CAUTIONS: This appliance contains a laser system and is classified as a “CLASS 1 LASER PRODUCT”. To use this model properly, read this Owner’s Manual carefully and keep this manual for your future reference. In case of any trouble with this player, please contact your nearest “AUTHORIZED service station”. To prevent direct exposure to the laser beam, do not try to open the enclosure.
PAGE 3
01_M109_EN.book Page 3 Thursday, February 19, 2009 10:43 AM CLARION PRODUCT REGISTRATION INFORMATION For USA and Canada only www.clarion.com Dear Customer: Congratulations on your purchase of a Clarion mobile electronic products. We are confident that you’ll enjoy your Clarion experience. There are many benefits to registering your product. We invite you to visit our website at www.clarion.com to register your Clarion product. We have made product registration simple with our easy to use website.
PAGE 4
01_M109_EN.book Page 4 Thursday, February 19, 2009 10:43 AM English Thank you for purchasing this Clarion product. ∗ Please do not use this product on vehicles. ∗ Please fully read this owner’s manual before operating this equipment. ∗ Check the contents of the enclosed warranty card and store it in a safe place with this manual. Contents 1. FEATURES ...................................................................................................................................... 4 2. PRECAUTIONS ....
PAGE 5
01_M109_EN.book Page 5 Thursday, February 19, 2009 10:43 AM This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
PAGE 6
01_M109_EN.book Page 6 Thursday, February 19, 2009 10:43 AM English 3. CONTROLS Names of the Buttons and Their Main Functions [RELEASE] [ ] [IR RECEIVER] [CD SLOT] [BND] [Q ] [AUX] [AUDIO] [DISP] [SRC] [ISR] [ROTARY] [SCN] [RPT] [UP ] [ DN] [RDM] [DIRECT] [RELEASE] button [RDM] button • Press to unlock DCP. • Perform random play while in CD/MP3/WMA mode. [ ] button • Perform preset scan while in the radio mode. • Play or pause a track while in CD/MP3/WMA mode.
PAGE 7
01_M109_EN.book Page 7 Thursday, February 19, 2009 10:43 AM When detaching the control panel, store it in the DCP (DETACHABLE CONTROL PANEL) case to prevent scratches. Removing the DCP 1. Press and hold the [SRC] button (1 sec.) to switch off power. 2. Press the [RELEASE] button. Storing the DCP in the DCP Case Hold the DCP, in the orientation as shown in the figure below, and put it into the supplied DCP case. (Ensure the DCP is in the correct orientation.
PAGE 8
01_M109_EN.book Page 8 Thursday, February 19, 2009 10:43 AM English ● Radio mode 5. REMOTE CONTROL [BND] button ∗ If you buy the RCB-176-200 sold separately, you can enjoy the use of the Remote Control function. Functions of Remote Control Unit Buttons • Switches reception band. [x], [v] buttons • Change preset channels. [SCN] button • Press for preset scan play. • Press and hold (2 sec.) for auto store. ∗ Some buttons on the remote have different functions from those on the main unit.
PAGE 9
01_M109_EN.book Page 9 Thursday, February 19, 2009 10:43 AM 1 Slide remote control unit’s rear cover in the direction shown. 2 Insert battery (CR2025) into insertion guides with printed side (+) up. 3 Press battery into compartment as shown. 4 Replace and slide cover until it clicks into place. 6. OPERATIONS English Inserting the Battery Note: • Refer to the diagrams in “3. CONTROLS” (page 6) when reading this chapter.
PAGE 10
01_M109_EN.book Page 10 Thursday, February 19, 2009 10:43 AM English Sound Adjustment Sound effects and tone can be adjusted as desired. To change sound settings 1. Press the [AUDIO] button to switch to the sound adjustment display. ∗ The factory default sound setting is “ZEHCR+”. 2. Press [x] or [v] to select the sound adjustment mode.
PAGE 11
01_M109_EN.book Page 11 Thursday, February 19, 2009 10:43 AM ● Adjusting the fader 2-1. Select “FADER”. 3-1. Turn the [ROTARY] knob to adjust balance between front and rear speakers. ∗ The factory default setting is “CENTER”. (Adjustment range: FRONT12 to REAR12) ● Adjusting the non-fader volume Adjust volume output from the unit’s non-fader output terminal. 2-1. Select “NF VOL”. 3-1. Turn the [ROTARY] knob clockwise to increase volume; turn counterclockwise to decrease volume.
PAGE 12
01_M109_EN.book Page 12 Thursday, February 19, 2009 10:43 AM English Listening to broadcasts Auto store 1. Press the [SRC] button and select radio mode. 2. Press the [BND] button and select the reception band. Each time the button is pressed, the band changes as follows: F1 (FM1) ➜ F2 (FM2) ➜ F3 (FM3) ➜ AM ➜ F1 (FM1)... The auto store function stores up to 6 stations automatically tuned in sequential order. If 6 stations cannot be found, any previously stored station remains in its memory position. 1.
PAGE 13
01_M109_EN.book Page 13 Thursday, February 19, 2009 10:43 AM MP3/WMA This unit supports to play MP3/WMA files. Notes: • If you play a WMA file with active DRM (Digital Rights Management), no audio is output (WMA indicator flashes). • Windows Media™, and the Windows ® logo are trademarks, or registered trademarks of Microsoft Corporation in the United States and/or other countries. ● To disable DRM (Digital Rights Management) 1. In Windows Media Player 9/10/11, click on TOOL ➜ OPTIONS ➜ MUSIC RECORD tab.
PAGE 14
01_M109_EN.book Page 14 Thursday, February 19, 2009 10:43 AM English Loading a CD Selecting a track 1. Insert a CD into the centre of the CD SLOT with label facing up. “LOADING” appears in the display, the CD enters the slot, and play begins. ● Track advance 1. Press the [v] button to move to the beginning of the next track. 2. Each time the [v] button is pressed, the track advances to the beginning of the next track. ● Track back 1. Press the [x] button to return to the beginning of the current track.
PAGE 15
01_M109_EN.book Page 15 Thursday, February 19, 2009 10:43 AM English ● Folder repeat play Repeatedly plays all tracks of the current folder on an MP3/WMA disc. 1. Press and hold the [RPT] button (1 sec.) for folder repeat play. ● Random play This function plays all tracks recorded on a disc in random order. 1. Press the [RDM] button for random play. ● Folder random play This function plays all the tracks of all the folders recorded on an MP3/WMA disc in random order. 1.
PAGE 16
01_M109_EN.book Page 16 Thursday, February 19, 2009 10:43 AM English Operations Common to Each Mode To change settings 1. Press and hold the [DISP] button (1 sec.) to switch to the adjustment display. 2. Press [x] or [v] to select the “item name” as follows: “CLOCK” ↔ “SETTINGS” ↔ “SCRN SVR” ↔“SCROLL” ↔ “DIMMER” ↔ “TEL-SP” ↔ “TEL-SW” ∗ The adjustment item will be displayed for 2 seconds before showing the desired value. 3. Turn the [ROTARY] knob to select the desired value.
PAGE 17
01_M109_EN.book Page 17 Thursday, February 19, 2009 10:43 AM English ● Cell phone interrupt setting If you connect this unit and your cell phone with an optional cable, you can listen to your calls on your speakers. When the AUX input jack is used to connect an AUX BLUETOOTH BB (BLT370) (sold separately): ∗ The factory default setting is “OFF”. 2-1. Select “TEL-SW”. 3-1. Turn the [ROTARY] knob to select setting.
PAGE 18
01_M109_EN.book Page 18 Thursday, February 19, 2009 10:43 AM General Problem Cause Measure Power does not turn on. (No sound) Fuse is blown. Replace with a fuse of the same amperage. If the fuse blows again, consult your dealer. Incorrect wiring. Consult your dealer. No sound when operating the unit with amplifiers or power antenna attached. Power antenna lead is short circuited, or excessive current is required for remotely powering on the amplifiers or power antenna. 1. Turn the unit off. 2.
PAGE 19
01_M109_EN.book Page 19 Thursday, February 19, 2009 10:43 AM English 8. ERROR DISPLAYS If an error occurs, one of the following messages is displayed. Take the measures described below to eliminate the problem. CD/MP3/WMA Error Display Cause Measure ERROR 2 A CD is caught inside the CD This is a failure of the CD deck mechanism. Consult deck and is not ejected. your dealer. ERROR 3 A CD cannot be played due to scratches, etc. ERROR 6 A CD is loaded upside-down Eject the disc and reload properly.
PAGE 20
01_M109_EN.book Page 20 Thursday, February 19, 2009 10:43 AM English 9. SPECIFICATIONS FM Tuner General Frequency Range: U.S.A: 87.9 MHz to 107.9 MHz Europe: 87.5 MHz to 108.0 MHz Australia: 87.0 MHz to 108.0 MHz Usable Sensitivity: 9 dBf 50dB Quieting Sensitivity: 15 dBf Alternate Channel Selectivity: 70 dB Stereo Separation (1 kHz): 35 dB Frequency Response (±3 dB): 30 Hz to 15 kHz Power Supply Voltage: 14.4 V DC (10.8 to 15.
