User Manual

— 10 —
Item CBM-910II-24 CBM-910II-40
1 Printing method Dot matrix
2 Printing direction One-way printing
3 Character configuration (W × H) (5 + 1) × 8 (4 + 0.5) × 8
4 Number of columns per line 24 columns: 144 dots/line 40 columns: 180 dots/line
5 Printing speed Approx. 2.5 lines/sec. Approx. 1.8 lines/sec.
6 Character size (W × H) 1.62 × 2.4 mm 1.08 × 2.4 mm
7 Character spacing 1.98 mm 1.19 mm
8 Line pitch 3.52 mm
9 Paper feed speed Approx. 5 lines/s Approx. 3.6 lines/s
10 Paper Single sheet, copier paper (original and copy),
Total thickness: 0.13 mm or less
Paper roll: 57.5 ±0.5 (W) × 60 or 80 (Dia) mm
Core ID: φ12 ±1 mm Core OD: φ18 ±1 mm
11 Interface Parallel Interface (Conformity to Centronics) or
Serial Interface (RS-232C)
12 Input buffer 2k bytes/72 bytes
(Selectable by memory switch on Serial I/F model)
13 Emulation CBM-910 emulation and IDP3110 emulation
(selectable with memory switch)
14 Code page PC437, 852, 857, 858, 860, 863, 864, 865, 866, 869, WPC1252,
Katakana, CBM-910 emulation (Japan, International)
15 Paper-near-end detection Printing suspended when printing paper gets scarce.
16 Ink ribbon Black (Dedicated ribbon cassette)
Service life: approx. 200,000 letters
17 Voltage DC 7 V ±1 V (Printing)
Use exclusive adapter (DC 7 V 1.6 A)
18 Power consumption Printing: Approx. 7 VA
Stand-by: Approx. 0.5 VA
19 Weight Approx. 470 g
20 Reliability MCBF: 1.5 million lines MCBF: 1 million lines
21 Dimension 106 (W) × 180 (D) × 88( H) mm
22 Operating temperature and 0 to 40°C, 35 to 85% RH (without condensation)
humidity
23 Storage temperature and –20 to 60°C, 10 to 90% RH (without condensation)
humidity
24 Specifications CE Marking/TUV- GS/FCC class A/VCCI class A
(AC adapter PSE/UL/C- UL/TUV- GS)
2.3 Specifications
