Chapter 2 Cisco Catalyst Blade Switch 3120 for HP Cisco IOS Commands
snmp-server enable traps
Note Though visible in the command-line help strings, the cpu [threshold] keyword is not supported. The
snmp-server enable informs global configuration command is not supported. To enable the sending of
SNMP inform notifications, use the snmp-server enable traps global configuration command
combined with the snmp-server host host-addr informs global configuration command.
Defaults The sending of SNMP traps is disabled.
pim
[invalid-pim-message |
neighbor-change |
rp-mapping-change]
(Optional) Enable Protocol-Independent Multicast (PIM) traps. The
keywords have these meanings:
• invalid-pim-message—(Optional) Enable invalid PIM message traps.
• neighbor-change—(Optional) Enable PIM neighbor-change traps.
• rp-mapping-change—(Optional) Enable rendezvous point
(RP)-mapping change traps.
port-security
[trap-rate value]
(Optional) Enable port security traps. Use the trap-rate keyword to set the
maximum number of port-security traps sent per second. The range is from
0 to 1000; the default is 0 (no limit imposed; a trap is sent at every
occurrence).
rtr (Optional) Enable SNMP Response Time Reporter traps.
snmp [authentication |
coldstart | linkdown |
linkup | warmstart]
(Optional) Enable SNMP traps. The keywords have these meanings:
• authentication—(Optional) Enable authentication trap.
• coldstart—(Optional) Enable cold start trap.
• linkdown—(Optional) Enable linkdown trap.
• linkup—(Optional) Enable linkup trap.
• warmstart—(Optional) Enable warmstart trap.
storm-control
trap-rate value
(Optional) Enable storm-control traps. Use the trap-rate keyword to set the
maximum number of storm-control traps sent per minute. The range is 0 to
1000; the default is 0 (no limit is imposed; a trap is sent at every occurrence).
stpx (Optional) Enable SNMP STPX MIB traps. The keywords have these
meanings:
• inconsistency—(Optional) Enable SNMP STPX MIB Inconsistency
Update traps.
• root-inconsistency—(Optional) Enable SNMP STPX MIB Root
Inconsistency Update traps.
• loop-inconsistency—(Optional) Enable SNMP STPX MIB Loop
Inconsistency Update traps.
syslog (Optional) Enable SNMP syslog traps.
tty (Optional) Send TCP connection traps. This is enabled by default.
vlan-membership (Optional) Enable SNMP VLAN membership traps.
vlancreate (Optional) Enable SNMP VLAN-created traps.
vlandelete (Optional) Enable SNMP VLAN-deleted traps.
vtp (Optional) Enable VLAN Trunking Protocol (VTP) traps.
