Datasheet

4. Security Anomaly Detection by examining flows that do not traverse trust boundaries for inside the perimeter

attacks

5. Impacts of network and application changes

6. Compliance conformation

7. Traffic patterns for capacity planning

Enabling FNF at the access switch ensures you get all flows. The access switch is the most logical place in the

network for collecting statistics and monitoring all flows. With Netflow, you can obtain MAC-address and access

port information associated with the flow, to get directly to the source of the flow. Most collectors are able to

leverage the location based on MAC-address and interface port number provided by the access switch to the

collector. Thus by enabling FNF at the access switch you are able to get the location information of the flow. The

access switch has a variety of identity mechanism for user authentication and adding user awareness is the natural

progression that can be developed. Access switches are an order of magnitude greater than distribution and core

which makes them scale well for FNF and ensure there are no performance impacts of oversubscription at

aggregation and core.

10GB-T Module

The new Cisco 10G Base-T module is hot-swapable and can operate at either 10GE or GE speed (with manual

configuration).

Table 5 shows the cable types and supported lengths of the new Cisco 10G Base-T module.

Table 5. 10GB-T Cable Types and Supported Lengths

Cable Type

Supported Length

Category 7a

100 meters

Category 7

100 meters

Category 6

55 meters

Category 6a

100 meters

Category 6a requires 3db Insertion Loss margin at 250MHz.

MACsec

The Cisco Catalyst 3750-X and 3560-X Series Switches offer exceptional security with integrated hardware support

for MACsec defined in IEEE 802.1AE. MACsec provides MAC layer encryption over wired networks using out-of-

band methods for encryption keying. The MACsec Key Agreement (MKA) protocol provides the required session

keys and manages the keys required for encryption when configured. MKA and MACsec are implemented following

successful authentication using 802.1x Extensible Authentication Protocol (EAP) framework. In Cisco Catalyst

3750-X and 3560-X Series Switches both the user/down-link ports (links between the switch and endpoint devices

such as a PC or IP phone) and, using the service module, the network/up-link ports can be secured using MACsec.

With the service module you can encrypt switch to switch links such as access to distribution, or encrypt dark fiber

links within a building or between buildings.
