XPS 2200 Performance Specifications
Table 21 lists the performance specifications for the power supplies.
Please note that the same power supplies used in the 3750-X and 3560-X are all usable in the XPS-2200 (please
refer to Table 12).
Table 21. XPS 2200 Performance Specifications
Performance Numbers for XPS 2200
Total Power Sharing Capability (Stack Power Mode, 9 Switches and 20 total 1100W power supplies)
22kW
Maximum Power Back-up Capability (RPS Mode, 2x1100W power supplies in XPS 2200)
2200W
Nominal Voltage
56V
Nominal Maximum Current per Port (input or output)
40A
Flash
8MB
Heat Dissipation
Table 22 provides heat dissipation information for the Cisco XPS 2200.
Table 22. Heat Dissipation
Cisco XPS 2200 Power Supply
Configuration
Heat Dissipation
No Load (BTU/hr)
Full Load (BTU/hr)
1 x 350WAC
120
480
2 x 350WAC
160
665
1 x 715WAC
155
610
2 x 715WAC
205
920
1 x 1100WAC
155
825
2 x 1100WAC
205
1350
1 x 440WDC
115
645
2 x 440WDC
155
990
Physical and Environmental Specifications
Table 23 lists the physical and environmental specifications for XPS-2200.
Table 23. Physical and Environmental Specifications
Description
Specification
Physical specifications
H x W x D:
1.73 x 17.5 x 20.5 in.
(4.4 x 44.5 x 52.1 cm)
Weight:
19.8 lb (9.0 kg)
Total input BTU (1000 BTU/Hr = 290W)
8525 BTU/Hr
Operating temperature
-5 to 45°C up to 5000ft elevation, -5 to 40°C up to 10000ft elevation
Storage temperature
-40 to 70°C
Relative humidity operating,
non-condensing
5 to 95% non-condensing
Relative humidity non-operating,
non-condensing
5 to 95% non-condensing
Operating altitude
10,000 ft. (3000m)
