Corporate Headquarters:

Cisco Systems, Inc., 170 West Tasman Drive, San Jose, CA 95134-1706 USA

Release Notes for Cisco Voice Interworking

Service Module Release 3.1(1)

January 2003

The Voice Interworking Service Module (VISM) product is supported by MGX Voice Media Gateways.

Refer to these release notes for Media Gateway and version level support guidelines.

The software Release 3.1(1) for VISM/VISM-PR is an upgrade from the VISM 3.1(0) Release. For

details related to new features added in Release 3.1, refer to Release Notes for Cisco Voice Interworking

Service Module Release 3.1(0).

The software Release 3.1(1) for VISM/VISM-PR is supported by the Cisco VISM Installation and

Configuration Guide, which is available on the Web at the following locations:

• http://www.cisco.com/univercd/cc/td/doc/product/wanbu/mgx8850/vism31

• http://www.cisco.com/univercd/cc/td/doc/product/wanbu/mgx8250/vism31

• http://www.cisco.com/univercd/cc/td/doc/product/wanbu/mgx8230/vism31

• http://www.cisco.com/univercd/cc/td/doc/product/wanbu/mgx8830/vism31

• http://www.cisco.com/univercd/cc/td/doc/product/wanbu/8850px45/release3/vism/relnotes

• http://www.cisco.com/univercd/cc/td/doc/product/wanbu/8850px1e/release3/vism/relnotes

Contents

These release notes contain the following sections:

• “Features Introduced in Previous Releases of VISM Software” section on page 2

• “Elements of Release 3.1(1)” section on page 2

• “Installation and Upgrade Procedures” section on page 8

• “Caveats” section on page 15

• “Related Documentation” section on page 17

• “Obtaining Documentation” section on page 17

Summary of content (20 pages)

PAGE 1
Release Notes for Cisco Voice Interworking Service Module Release 3.1(1) January 2003 The Voice Interworking Service Module (VISM) product is supported by MGX Voice Media Gateways. Refer to these release notes for Media Gateway and version level support guidelines. The software Release 3.1(1) for VISM/VISM-PR is an upgrade from the VISM 3.1(0) Release. For details related to new features added in Release 3.1, refer to Release Notes for Cisco Voice Interworking Service Module Release 3.1(0).
PAGE 2
Features Introduced in Previous Releases of VISM Software Features Introduced in Previous Releases of VISM Software You can access lists of features and descriptions of features contained in previous releases of VISM software at the following location: • http://www.cisco.com/univercd/cc/td/doc/product/wanbu/mgx8850/index.htm Elements of Release 3.1(1) This section describes the following elements of software Release 3.
PAGE 3
Elements of Release 3.1(1) dsplinesabyte Use the dsplinesabyte to display the transmit and receive SA buffers. Syntax dsplinesabyte Syntax Description Parameter Description line_number Line number in the range 1–8. Example cvgmgx1a.1.20.VISM8.
PAGE 4
Elements of Release 3.1(1) Syntax Description Parameter Description line_number Line number in the range 1–8. sa_byte Type of sabyte. sa_value • 1 = sa4-byte • 2 = sa5-byte • 3 = sa6-byte • 4 = sa7-byte • 5 = sa8-byte Range is 0–255. The possible error includes invalid parameters. Example This example shows configuring SA buffers on line 1 and displaying the results. cvgmgx1a.1.20.VISM8.a > cnflinesabyte 1 3 0 cvgmgx1a.1.20.VISM8.
PAGE 5
Elements of Release 3.1(1) Note You can use a VISM-PR card as a redundant card for a VISM card, but a VISM card cannot be used as a redundant card for a VISM-PR card. There is support for Bulk Distribution using the SRM-3T3 and SRM-E (OC3) cards. VISM Call Rate Software Release 3.1(1) for VISM/VISM-PR handles at least 10 CAS, SS7, or PRI calls per second per VISM card.
PAGE 6
Elements of Release 3.1(1) Table 2 VISM Software Interoperability (continued) Product CW2000 Name Latest Firmware Min. Firmware MGX 1 MGX 1 1.2.11 1.1.42 MGX 2 MGX 2 3.0.10 2.1.80 MGX-AUSM-8E1/B AUSMB-8E1 10.2.00 10.0.23 MGX-AUSM-8T1/B AUSMB-8T1 10.2.00 10.0.23 MGX-CESM-8T1/B CESM-8T1/B 10.2.00 — MGX-CESM-E3 CESM-E3 10.2.00 10.0.22 MGX-CESM-T3 CESM-T3 10.2.00 10.0.22 MGX-FRSM-2CT3 FRSM-2CT3 10.2.00 10.0.23 MGX-FRSM-2T3E3 FRSM-2T3 10.2.00 10.0.
PAGE 7
Elements of Release 3.1(1) VISM software interoperability with other Cisco products is described in Table 3. Table 3 Software Release 3.1(1) for VISM/VISM-PR Interoperability with Other Cisco Products Cisco 3810 12.2(8)T1 AS5400 122-10.7 Virtual Switch Controller Software VSC 9.1.5 Table 4 describes the software images available for Release 3.1(1) for VISM/VISM-PR. Table 4 Software Images for Release 3.
PAGE 8
Installation and Upgrade Procedures • Cisco recommends that you use the cnfcodecjtrdelay command to configure the jitter-delay argument to 20 msec when using DSP firmware versions 3.4 and 3.6. • Table 6 describes the design constraint which is identified in software Release 3.1(1) for VISM/VISM-PR. Table 6 Known Design Constraint DDTS Issue Description CSCdv37382 The addcid command can put VISM into the fail state.
PAGE 9
Installation and Upgrade Procedures d. put POPEYE@SM_1_.FW quit Do not enter two put commands in the same TFTP session. Note Step 3 Proceed to the “Installing VISM Software Updates with PXM1 Cards” section on page 11 to install the download. VISM Firmware and Boot Code Download Procedure for PXM1E and PXM45 Step 1 Access the image on the Cisco Web site in order to download the image.
PAGE 10
Installation and Upgrade Procedures • Two VISM cards are involved in a redundancy group, initially with the primary card in the active state and the secondary card in the standby state. • Old-rev refers to the firmware before the upgrade (2.2). • New-rev refers to the firmware after the upgrade (3.1). Step 1 Log in to the active PXM1 card (slot 7 or 8).
PAGE 11
Installation and Upgrade Procedures Note If the VISM card is not part of a redundancy group, Step 1 to Step 3 are sufficient. VISM to VISM-PR Hardware Upgrade Complete the following steps to upgrade your system from VISM cards to VISM-PR cards. Caution You must install the redundant (standby) VISM-PR card first; failure to follow this recommendation results in traffic loss.
PAGE 12
Installation and Upgrade Procedures Caution Installing VISM software updates from VISM Release 2.2 with CALEA to VISM Release 3.0 without CALEA is not graceful. Caution Temporary traffic loss occurs during Step 4 and Step 5 of the VISM graceful upgrade procedure of the Upgrade Procedure for software Release 3.1(1) for VISM/VISM-PR.
PAGE 13
Installation and Upgrade Procedures You have completed the steps. Proceed to the VISM Boot Code Upgrade Procedure with PXM1E and PXM45 Cards, page 14. VISM Boot Code Upgrade Procedure with PXM1 Cards There is a new backup boot code change from VISM Release 2.2(0) to software Release 3.1(1) for VISM/VISM-PR.
PAGE 14
Installation and Upgrade Procedures VISM Boot Code Upgrade Procedure with PXM1E and PXM45 Cards There is a new backup boot code change from VISM Release 2.2(0) to software Release 3.1(1) for VISM/VISM-PR. Complete the following steps to upgrade the new backup boot code when you are using PXM1E or PXM45 cards in your MGX 8000 Series chassis: Step 1 Complete the steps in the VISM Firmware and Boot Code Download Procedure for PXM1E and PXM45, page 9. Step 2 Log on to the PXM1E or PXM45 card.
PAGE 15
Caveats The VISM card will be reset again. When the card comes active, it will have the old-rev firmware running and will have the old configuration. Step 5 Reconfigure redundancy group, if required. Caveats This section describes resolved and open software caveats for this release of VISM. Caveats describe unexpected behavior or defects in VISM software. Resolved Caveats Table 7 describes the caveats issued against VISM software that have been resolved in software Release 3.1(1) for VISM/VISM-PR.
PAGE 16
Caveats Open Caveats Table 8 describes possible unexpected behavior by software Release 3.1(1) for VISM/VISM-PR. Table 8 Open Caveats for Software Release 3.1(1) for VISM/VISM-PR DDTS Issue Description CSCdx94130 Title: VISM loses some DTMF digits when ON time is less than 45ms Description: VISM randomly fails to detect some of the digits resulting in call failure. Workaround: The equipment should generate DTMF digits with ON time greater than or equal to 45ms. CSCdz65510 Title: CSCdz65510 T.
PAGE 17
Related Documentation Related Documentation The following documents contains information that may be useful to software Release 3.1(1) for VISM/VISM-PR: • Cisco VISM Installation and Configuration Guide, Release 3.
PAGE 18
Obtaining Technical Assistance • Registered Cisco.com users can order the Documentation CD-ROM (Customer Order Number DOC-CONDOCCD=) through the online Subscription Store: http://www.cisco.com/go/subscription • Nonregistered Cisco.com users can order documentation through a local account representative by calling Cisco Systems Corporate Headquarters (California, U.S.A.) at 408 526-7208 or, elsewhere in North America, by calling 800 553-NETS (6387).
PAGE 19
Obtaining Technical Assistance Technical Assistance Center The Cisco TAC is available to all customers who need technical assistance with a Cisco product, technology, or solution. Two levels of support are available: the Cisco TAC website and the Cisco TAC Escalation Center. The avenue of support that you choose depends on the priority of the problem and the conditions stated in service contracts, when applicable.
PAGE 20
Obtaining Additional Publications and Information Obtaining Additional Publications and Information Information about Cisco products, technologies, and network solutions is available from various online and printed sources. • The Cisco Product Catalog describes the networking products offered by Cisco Systems as well as ordering and customer support services. Access the Cisco Product Catalog at this URL: http://www.cisco.com/en/US/products/products_catalog_links_launch.
