SIP support includes the following:
TLS/SRTP: Cisco Unified Communications Manager SIP trunk integrations support authentication and encryption of the Cisco Unity Connection
voice messaging ports.
Keypad Stimulus Protocol (KPML): For Cisco Unified Communications Manager SIP trunk integrations, administrators can configure the
integration to send dual tone multifrequency (DTMF) keystrokes in the Real-Time Transport Protocol (RTP) media stream (in-band) or in a SIP
message (out-of-band).
Port multiplexing: SIP integrations (such as for PIMG/TIMG or Cisco SIP Proxy Server) can share the same SIP port on the Cisco Unity
Connection server.
●
Simple Network Management Protocol (SNMP) Versions 1, 2, and 3 are supported.
●
Event logging is supported.
●
Full mailbox warning is supported.
●
Installation is simple and quick.
●
A list of observed holidays is configurable.
●
You can configure how Cisco Unity Connection handles messages that are interrupted by disconnected calls.
●
MWI is supported, including enhanced MWI that displays a constant message count on certain Cisco Unified IP Phone.
●
Multiple administrative levels allow you to control access to pages in the system administration GUI by CoS (read, modify, or delete rights).
●
Music on hold (MOH) is supported.
●
Nondelivery or delivery receipt reason details are presented in the GUI inbox.
●
You can specify the public distribution lists to which new users will be added.
●
Restriction tables are configurable.
●
You can exclude return receipts.
●
The system schedule is configurable.
●
Self-enrollment allows you to set your password, record your voice name, and specify your directory listing.
●
A status monitor allows for real-time administrator status of telephone ports, reports in progress, and system configuration.
●
System broadcast messages for officewide announcements are supported.
●
System greetings are configurable.
●
The system offers 12- and 24-hour clock support for time stamps.
●
The system time clock adjusts automatically for Daylight Savings Time.
●
A TUI greetings administrator (Cisco Unity Connection Greetings Administrator) is supported.
●
LDAP Directory Integration allows users to be quickly imported, synchronized, and authenticated within the directory.
●
You can create up to nine mailbox stores in addition to the default mailbox store that is created when Cisco Unity Connection is installed.
●
You can simulate abbreviated extensions by using prepended digits for call handlers and user mailboxes.
Security
●
A host intrusion prevention system, the Cisco Security Agent standalone agent, protects Cisco Unity Connection servers from worm and virus
attacks; an optional Cisco Security Agent management console is available.
●
Password and personal identification number (PIN) security policy options to enforce expiration, complexity, reuse, and lockout are supported.
●
Call-restriction tables to prevent toll fraud are supported.
●
Security event logging and reports of failed login and account lockouts to help prevent unauthorized PIN use are supported.
●
Secure, private messaging prevents the playing of private messages accidentally forwarded outside the enterprise.
●
A message aging policy for secure messages automatically deletes all secure messages that are older than the specified number of days.
●
Secure RTP and signaling encryption provides for secure communication between Cisco Unity Connection and Cisco Unified Communications
Manager.
●
A user telephone PIN reset feature in Cisco Unity Connection Assistant reduces help-desk calls and operating expenses.
●
Message archiving utilities enforce corporate electronic records-retention policies.
●
Support for HTTPS provides for secure web access to Cisco Unity Connection and allows for playback of secure messages within Outlook.
Voice Quality
●
G.722 and Internet Low Bitrate Codec (iLBC) voice codecs are supported (advertised or “on the line”). G.711 mu-law, G.711 a-law, and G.729 are
also supported.
●
System-level recording is available for linear pulse code modulation (PCM), G.711 mu-law, G.711 a-law, G.729a, and G.726 through system-based
transcoding resources.
