Specifications

Cisco UCS Cisco UCS C220 M4 High-Density Rack Server (Large Form Factor Disk Drive Model)
BASE SERVER STANDARD CAPABILITIES and FEATURES
7
Cisco Flexible Flash
drives
The server supports up to two internal 32 GB or two internal 64 GB Cisco
Flexible Flash drives (SD cards).
The second SD card is blank and can be used to mirror the first SD card. It
can be used to protect the Hypervisor Partition with RAID1.
Video The Cisco Integrated Management Controller (CIMC) provides video using the
Matrox G200e video/graphics controller:
■ Integrated 2D graphics core with hardware acceleration
■ DDR2/3 memory interface supports up to 512 MB of addressable memory
(8 MB is allocated by default to video memory)
■ Supports display resolutions up to 1920 x 1200 16bpp @ 60Hz
■ High-speed integrated 24-bit RAMDAC
■ Single lane PCI-Express host interface running at Gen 1 speed
Storage controller ■ Cisco 12G SAS Modular RAID controller card with internal SAS
connectivity.
• Supports up to 24 internal drives (note however that this server can
be configured with a maximum of 4 drives)
• Plugs into a dedicated RAID controller slot
• Can be purchased alone, or along with an onboard Flash-Backed
Write Cache (FBWC) upgrade option, as shown in the table below
■ Cisco 9300-8E 12G SAS HBA with external SAS connectivity
• Provides 8 external SAS ports
• Plugs into a PCIe slot at the rear of the server
• No FBWC (cache) or cache power backup
•SAS 3.0 compliant
Table 1 Capabilities and Features (continued)
Capability/Feature Description
RAID Card Version Supported RAID Levels
Onboard TMM
Cache
UCSC-MRAID12G
1
Notes . . .
1. Base RAID controller card
JBOD, 0, 1, 10 None
UCSC-MRAID12G-512
2
JBOD, 0, 1, 10, 5, 6, 50 512 MB
UCSC-MRAID12G-1GB
2
JBOD, 0, 1, 10, 5, 6, 50, 60 1 GB
UCSC-MRAID12G-2GB
2
JBOD, 0, 1, 10, 5, 6, 50, 60 2 GB
UCSC-MRAID12G-4GB
2
JBOD, 0, 1, 10, 5, 6, 50, 60 4 GB
2. FBWC option
