BASE SERVER STANDARD CAPABILITIES and FEATURES
BASE SERVER STANDARD CAPABILITIES and FEATURES
Tab le 1 lists the capabilities and features of the base server. Details about how to configure the server for
a particular feature or capability (for example, number of processors, disk drives, or amount of memory)
are provided in
CONFIGURING the SERVER, page 10.
Table 1 Capabilities and Features
Capability/Feature Description
Chassis One rack unit (1RU) chassis
CPU One or two Intel® Xeon E5-2600 v3 series processor family CPUs
Chipset Intel® C610 series chipset
Memory 24 slots for DDR4 registered DIMMs (RDIMMs) or load-reduced DIMMs
(LRDIMMs)
Multi-bit Error
Protection
This server supports multi-bit error protection.
Embedded NIC Two embedded (on the motherboard) Intel i350 GbE ports, supporting the
following:
■ Pre-Execution Boot (PXE boot)
■ iSCSI boot
■ Checksum and segmentation offload
■ NIC teaming
Expansion slots ■ Riser 1 (controlled by CPU 1):
• One full-height profile, 3/4-length slot with x24 connector and x16
lane
■ Riser 2 (controlled by CPU 2):
• One half-height profile, half-length slot with x24 connector and x16
lane
■ Dedicated Cisco 12G SAS Modular RAID controller slot (see Figure 6 on
page 53)
• An internal slot is dedicated for the 12G SAS Modular RAID controller
card.
Internal storage devices Drives are installed into front-panel drive bays that provide hot-pluggable
access.
• Large Form Factor (LFF) drives. Up to four 3.5-inch SAS
hot-swappable hard disk drives (HDDs).
■ The server also contains one internal USB 3.0 port on the motherboard
that you can use with a an optional 16 GB USB thumb drive for additional
storage
■ UCS Storage Accelerators are also available. These PCIe flash storage
devices provide independent high-speed storage.
