Cisco UCS Cisco UCS C220 M4 High-Density Rack Server (Large Form Factor Disk Drive Model)
CONFIGURING the SERVER
27
Approved Configurations
(1) 1-CPU Systems
■ You can select up to one PCie option card (slot 1 for 1-CPU systems) listed in Table 9.
(2) 2-CPU Systems
■ You can select up to two PCie option cards (slots 1 and 2 for 2-CPU systems) listed in
Tab le 9.
10 Gb Converged Network Adapters (CNAs)
UCSC-PCIE-E14102 Emulex OCe14102-UX dual-port 10 GbE FCoE CNA Half
UCSC-PCIE-Q8362 Qlogic QLE8362 dual-port 10 GbE FCoE CNA Half
Host Bus Adapters (HBAs)
N2XX-AQPCI05 Qlogic QLE2562 Dual Port 8Gb Fibre Channel HBA Half
UCSC-PCIE-Q2672 Qlogic QLE2672-CSC, 16Gb Fibre Channel HBA with SR Optics Half
N2XX-AEPCI05 Emulex LPe 12002 Dual Port 8Gb Fibre Channel HBA Half
UCSC-PCIE-E16002 Emulex LPe16002-M6, 16Gb Fibre Channel HBA with SR Optics Half
UCS Storage Accelerators
2
UCSC-F-FIO-1000MP UCS 1000GB Fusion ioMemory3 PX Performance line for C-Series Half
UCSC-F-FIO-1300MP UCS 1300GB Fusion ioMemory3 PX Performance line for C-Series Half
UCSC-F-FIO-2600MP UCS 2600GB Fusion ioMemory3 PX Performance line for C-Series Half
UCSC-F-FIO-5200MP UCS 5200GB Fusion ioMemory3 PX Performance line for C-Series Full
UCSC-F-FIO-3200SS UCS 3200GB Fusion ioMemory3 SX Scale line for C-Series Half
UCSC-F-FIO-6400SS UCS 6200GB Fusion ioMemory3 SX Scale line for C-Series Full
Notes . . .
1. The mLOM cards do not plug into any of the riser 1 or riser 2 card slots; instead, they plug into a dedicated
connector inside the server chassis.
2. A maximum of two storage accelerator cards are supported if they are half height; the supported number of
full height cards is one. Note that the Cisco 12G SAS 9300-8e 12G SAS HBA also can only be installed in slot 1.
Table 9 Available PCIe Option Cards (continued)
Product ID (PID) PID Description
Card
Height
