Specifications

Cisco UCS Cisco UCS C220 M4 High-Density Rack Server (Large Form Factor Disk Drive Model)
24
CONFIGURING the SERVER
Caveats
■ A maximum of one Cisco 9300-8e 12G SAS HBA can be installed, and it can be installed in any
slot (depending on the number of CPUs installed). The system can support combinations of
one Storage Accelerator card and one Cisco 9300-8e 12G SAS HBA.
■ For the Cisco 12G SAS Modular RAID controller, you can choose an optional RAID
configuration (RAID 0, 1, 10, 5, or 6), which is preconfigured at the factory. The RAID level
you choose must be an available RAID choice for the controller selected. RAID levels 50 and
60 are supported, although they are not available as configuration options.
NOTE: For more important information regarding RAID support, see RAID Details,
page 60 and RAID Option ROM (OPROM) Settings, page 61.
