Specifications

Cisco UCS Cisco UCS C220 M4 High-Density Rack Server (Large Form Factor Disk Drive Model)
8
BASE SERVER STANDARD CAPABILITIES and FEATURES
Modular LAN on
Motherboard (mLOM)
slot
The mLOM slot can flexibly accommodate the following cards:
■ Cisco Virtual Interface Cards (VIC)
■ Quad Port Intel i350 1GbE RJ45 Network Interface Card (NIC)
Interfaces ■ Rear panel
• One DB15 VGA connector
• One RJ45 serial port connector
• Two USB 3.0 port connectors
• One RJ-45 10/100/1000 Ethernet management port, using Cisco
Integrated Management Controller (CIMC) firmware
• Two Intel i350 embedded (on the motherboard) GbE LOM ports
• One flexible modular LAN on motherboard (mLOM) slot that can
accommodate various interface cards
■ Front panel
• One KVM console connector (supplies two USB 2.0 connectors, one
VGA DB15 connector, and one serial port (RS232) RJ45 connector)
■ Various PCIe card ports (dependent on which cards are installed)
• Virtual Interface Card (VIC) ports
• Converged Network Adapter (CNA) ports
• Network Interface Card (NIC) ports
• Host Bus Adapter (HBA) ports
WoL The 1-Gb Base-T Ethernet LAN ports support the wake-on-LAN (WoL)
standard.
Front Panel A front panel controller provides status indications and control buttons
Power subsystem Up to two 770 W (AC) power supplies. One is mandatory; one more can be
added for 1 + 1 redundancy.
ACPI This server supports the advanced configuration and power interface (ACPI)
4.0 standard.
Fans Chassis:
■ Six hot-swappable fans for front-to-rear cooling
Table 1 Capabilities and Features (continued)
Capability/Feature Description
NOTE: The four Intel i350 ports are provided on an optional card
that plugs into the mLOM slot, and are separate from the two
embedded (on the motherboard) LAN ports
