Appendix B Site-to-Site VPN User Interface Reference
Create VPN Wizard
Mandatory settings for dial backup are configured in the VPN Interface tab on the
Edit Endpoints dialog box. See VPN Interface Tab, page B-17.
Note You must configure the dialer interface settings before dial backup can work
properly. For more information, see Configuring Dialer Interfaces on Cisco IOS
Routers, page 12-29.
Navigation Path
Open the VPN Interface Tab, page B-17 from the Edit Endpoints dialog box,
select the Enable check box in the Backup area, and click Advanced.
Note Make sure you selected the required router device in the table on the Endpoints
Page, page B-13 (or tab), before opening the Edit Endpoints dialog box.
Related Topics
• Defining the Endpoints and Protected Networks, page 9-18
• Configuring Dial Backup, page 9-28
• VPN Interface Tab, page B-17
Field Reference
Table B-12 Dial Backup Settings Dialog Box
Element Description
Next Hop Forwarding
Backup Next Hop IP Address If required, enter the next hop IP address of the ISDN BRI or analog
modem backup interface (that is, the IP address to which the backup
interface will connect when it is active).
If you do not enter the next hop IP address, Security Manager will
configure a static route using the interface name.
Tracking Object Settings
Timeout The number of milliseconds the Service Assurance Agent operation
waits to receive a response from the destination device. The default
is 5000 ms.
