Create VPN Wizard
Defining VPN Services Module (VPNSM) or VPN SPA Settings
When you select a Catalyst 6500/7600 device in the Endpoints table for editing,
the VPN Interface tab of the Edit Endpoints dialog box provides settings for
configuring a VPN Services Module (VPNSM) or VPN SPA on the device. You
can select more than one Catalyst 6500/7600 device at the same time. Your
changes are applied to all the selected devices.
Tracking IP Address The IP address of the destination device to which connectivity must
be maintained from the primary VPN interface connection. This is
the device that is pinged by the Service Assurance agent through the
primary route to track connectivity. The backup connection will be
triggered if connectivity to this device is lost.
Note If you do not specify an IP address, the primary hub VPN
interface will be used in a hub-and-spoke VPN topology. In
a point-to-point or full mesh VPN topology, the peer VPN
interface will be used.
Primary Next Hop IP Address Available only if the selected technology is IPSec, GRE, or GRE
Dynamic IP.
Enter the IP address to which the primary interface will connect
when it is active. This is known as the next hop IP address.
If you do not enter the next hop IP address, Security Manager will
configure a static route using the interface name.
Advanced button Available only if the selected technology is IPSec, GRE, or GRE
Dynamic IP.
Opens the Dial Backup Settings dialog box for configuring
additional (optional) settings. See Dial Backup Settings Dialog
Box, page B-32.
OK button Saves your changes locally on the client and closes the dialog box.
The changes appear in the Endpoints table for the selected
device(s).
Cancel button Closes the dialog box without saving your changes.
Help button Opens help for this tab.
Table B-7 Edit Endpoints Dialog Box > VPN Interface Tab (continued)
Element Description
