The Cisco PRP-2 delivers all these functions with enhanced performance and capabilities. It also
delivers the following feature enhancements (depending on the software version running):
●
Gigabit Ethernet management port
●
Hard-drive support (optional part)
●
BITS input ports
●
Up to 4 GB compact image Flash memory support (optional part)
●
Memory scalability up to 4 GB
The Cisco XR 12000 and 12000 series routers are a portfolio of intelligent routing solutions that
scale from 2.5 to n x 10 Gbps/slot capacity, enabling carrier-class IP/MPLS networks and
accelerating the evolution toward IP Next-Generation Networks. Built upon a foundation of
investment protection, this portfolio delivers up to 1.28 terabits per second switching capacity with
wire-speed feature performance, scalability, and graceful hardware and software upgrade paths.
For a detailed list of feature support for Cisco IOS
®
XR Software and Cisco IOS Software on these
products, refer to the release notes of the appropriate version.
Product Specifications
Table 1. Technical Specifications
Description Specification
Chassis Compatibility
●
Cisco 12816, 12810, 12416, 12410, 12406, 12404, 12016, 12012, 12010, 12008, 12006,
and 12004 routers
●
Cisco XR 12416, XR 12410, XR 12406, XR 12404, XR 12016, XR 12010, XR 12006, and
XR 12004 routers
PRP-2 Memory Options
●
One or two 1-GB synchronous dynamic RAM (SDRAM)
●
One or two 2-GB SDRAM modules
●
64-MB Advanced Technology Attachment (ATA) PC Card
●
128-MB ATA PC Card
●
256-MB ATA PC Card
●
512-MB ATA PC Card
●
1-GB ATA PC Card
●
2-GB ATA PC Card
●
4-GB ATA PC Card
●
1-GB compact flash for image storage
●
2-GB compact flash for image storage
●
4-GB compact flash for image storage
●
40-GB hard drive
Connectivity
●
Console port (RJ-45 connector)
●
Auxiliary port (RJ-45 connector)
●
Two 10/100 Ethernet ports (RJ-45 connectors)
●
One 10/100/1000 Ethernet port over copper (with Cisco IOS Software Release 12.0(30)S)
●
Two RJ-48 connectors for BITS input clocks (for future BITS option)
Table 2. Power Requirements
Description Specification
Power 60W
Indicators Alphanumeric and LED status display
