Specifications
The following are the specifications for the tap.
Note: Specifications are subject to change without notice.
Dimensions
Item Faceplate Specification Faceplate and Housing Specification
Height 1.9 in. (4.7 cm) 5.4 in. (13.6 cm)
Width 11 in. (28 cm) 11 in. (28 cm)
Depth 4 in. (10.2 cm) 4 in. (10.2 cm)
Electrical Specifications
Item Specification
Frequency bandpass 5 MHz to 1000 MHz
Power passing 12 A, 60 V AC to 90 V AC
Impedance
75 Ω
Interface

ports: KS-connectors

drop ports: F-connectors
Operating temperature
-40°F to +140°F (-40°C to +60°C)
Port current limiting
250 mA (at 60°C)
Surge resistance

KS ports: 6 kV combination wave

Tap ports: 6 kV ring wave, 2 kV
combination wave
AC/RF Bypass Switch Performance
Item Specification
System open circuit time 0 ms
Contact resistance
10 mΩ max
Current and voltage capacity 15 A, 60 V AC to 90 V AC
Frequency bandpass 5 MHz to 1000 MHz
