Introduction to This Document
This guide introduces the Addressable Multimedia Strech™ Tap with
Tiering Capability.
The tap is designed to provide signal from the feeder cable to the drop.
It is available in 4-, 8-, 12-, and 16-port configurations and in a wide
range of tap values. Interchangeable directional couplers (DCs) make
it easy to change tap values and apply signal conditioning to equalize
the RF plant.
Who Should Use This Document
This document is intended for authorized personnel who have
experience working with similar equipment. The personnel should
have appropriate background and knowledge to complete the
procedures described in this document. Service engineers who help
system operators manage their systems will also find the contents of
this document useful.
Qualified Personnel
Only appropriately qualified and skilled personnel should attempt to
install, operate, maintain, and service this product.
WARNING:
Allow only qualified and skilled personnel to install, operate,
maintain, and service this product. Otherwise, personal injury or
equipment damage may occur.
1 Chapter 1
Introducing the Addressable
Multimedia Stretch Tap
