Optical Interface Board Part Number
8-position, Optical Interface Board, 4Rx / 4Tx 4011927
6-position, Optical Interface Board, 4Rx / 2Tx / bdr 4011928
Power Supply
Node Power Supply 4011930
Local Control Modules & Status Monitoring Module
Local Control Module, with craft port 4024775
Local Control Module, with HMS status monitor module & craft port 4024776
Local Control Modules & Transponder (with USB interface)
Local Control Module with Transponder 4025871
Local Control Module without Transponder 4027114
Test Point Cable Kit
Test Point Cable Kit, (includes the 6 cables required to enable GS7000 housing external test points) 4025059
Optical Fiber Tray Kit
Standard Fiber Tray 4027376
Expanded Fiber Tray (additional fiber handling/routing capacity) - includes brackets for passives and 4 SC
APC bulkheads
4026885
Expanded Fiber Tray (additional fiber handling/routing capacity) - includes brackets for passives and 4 SC
UPC bulkheads
4028274
Brackets for passives used in Expanded Fiber Tray 4027000
SC APC bulkheads, package of 10 4027740
SC UPC bulkheads, package of 10 4027741
Optical Amplifiers and Switch
17 dBm Broadcast Amplifier 4027007
20 dBm Broadcast Amplifier 4027008
22 dBm Broadcast Amplifier 4027009
17 dBm Narrowcast Gain Flattened Amplifier - Low Gain 4027010
17 dBm Narrowcast Gain Flattened Amplifier - High Gain 4027011
20 dBm Narrowcast Gain Flattened Amplifier - Low Gain 4027012
20 dBm Narrowcast Gain Flattened Amplifier - High Gain 4027013
Optical Switch 4027014
