Ordering Information
The GS7000 Node is available in a wide variety of configurations. The GS7000 Ordering Matrix provides ordering
information for configured node stations. This page contains ordering information for required and optional
accessories. Please consult with your Account Representative, Customer Service Representative, or
Applications Engineer to determine the best configuration for your particular application.
Required Accessories Part Number
Plug-in Pads (attenuators) – Available in 0.5 dB steps from 0 to 20 dB
1 required for each Optical Receiver Module installed in the node (for Optical Interface Board)
1 required for each Optical Transmitter Module installed in the node (for Optical Interface Board)
1 required for each Reverse input path activated (for Launch Amplifier)
589693 (0 dB)
sequentially thru
589734 (20.5dB)
Optional Accessories Part Number
Plug-in Forward Linear Equalizers – Available in 1.5 dB steps from 0 to 21 dB
Node shipped with 7.5 dB Linear Equalizers (2)* installed for 14.5dB of tilt to 1002 MHz (*4008782)
4007228 (0 dB)
see table below
Plug-in Signal Directors – 2 required
Node shipped with Jumpers installed to activate 4 RF output ports
Optional 2-Way Splitters are required to activate 5 or 6 RF output ports
4011907
4011908
Note: Configured nodes ship without reverse input pads and any of the pads on the OIB. All other standard accessories are shipped from the
factory. Forward Launch Amp attenuator pads, (2) 7.5 dB linear Eqs, and (2) signal director jumpers are shipped with every configured node.
GS7000 Forward Launch Amplifiers Part Number
Node Launch Amplifier, 2-way forward segmentation, 40/52 MHz split 4011887
GS7000 Forward Configuration Modules
Forward Configuration Module, 1x2 4011900
Forward Configuration Module, 1x2 Redundant 4011901
Forward Configuration Module, 1x2, Forward RF Injection, Redundant 4017858
Forward Configuration Module, 2x2 4011902
Forward Configuration Module, 2x2 Redundant 4011903
Forward Linear Equalizers
0 dB 1GHz Forward Linear EQ 4007228
1.5 dB 1GHz Forward Linear EQ 4008778
3.0 dB 1GHz Forward Linear EQ 4008779
4.5 dB 1GHz Forward Linear EQ 4008780
6.0 dB 1GHz Forward Linear EQ 4008781
7.5 dB 1GHz Forward Linear EQ 4008782
9.0 dB 1GHz Forward Linear EQ 4008783
10.5 dB 1GHz Forward Linear EQ 4008784
12.0 dB 1GHz Forward Linear EQ 4008785
13.5 dB 1GHz Forward Linear EQ 4008786
15.0 dB 1GHz Forward Linear EQ 4008787
16.5 dB 1GHz Forward Linear EQ 4019258
18.0 dB 1GHz Forward Linear EQ 4019259
19.5 dB 1GHz Forward Linear EQ 4019260
21.0 dB 1GHz Forward Linear EQ 4019261
GS7000 Node Signal Directors
Node Signal Director Jumper 4011907
Node Signal Director Splitter 4011908
GS7000 Forward Low Current Optical Receivers
Optical Receiver, SCA connector 4013593
Optical Receiver, SCU connector 4013594
Optical Receiver, FCA connector 4013595
GS7000 Forward Local Injection Module Kit (does not include FCM)
Forward Local Injection Module 4013575
