Release Notes for Cisco 7000 Family for Cisco IOS Release 12.1 T
78-10811-05
New and Changed Information
Wildcard Pre-Shared Key Enhancement
Platforms: Cisco 7100 series, Cisco 7200 series, and Cisco 7500 series routers
A wildcard pre-shared key allows a group of remote users with the same level of authentication to share
an IKE pre-shared key. The remote peer pre-shared key must match the local peer pre-shared key for
IKE authentication to occur. The term “wildcard” means that any remote peer with the pre-shared key
can access the local peer, regardless of the remote peer IP address assignment. The term “pre-shared
key” is a shared secret key exchanged during IKE negotiation.
A wildcard pre-shared key is usually distributed through a secure out-of-band channel. In a remote
peer-to-local-peer scenario, any remote peer with the IKE pre-shared key configured can establish IKE
security associations with the local peer.
The Wildcard Pre-shared Key feature is an enhancement to the crypto isakmp key global configuration
command. With a wildcard IP address of 0.0.0.0 and pre-shared key authentication method configured
on the local router, the local router can authenticate the IKE security associations with any remote peer
that has a matching wildcard pre-shared key.
MIBs
Current MIBs
If you have an account with Cisco.com, you can find the current list of Management Information Bases
(MIBs) supported by Cisco. To reach the Cisco Network Management Toolkit, log in to Cisco.com, and
click Service & Support: Software Center: Network Mgmt Software: Cisco Network Management
Toolkit: Cisco MIBs.
Deprecated and Replacement MIBs
Old Cisco MIBs will be replaced in a future release. Currently, OLD-CISCO-* MIBs are being
converted into more scalable MIBs—without affecting existing Cisco IOS products or NMS
applications. You can update from deprecated MIBs to the replacement MIBs as shown in Table 18.
Table 18 Deprecated and Replacement MIBs
Deprecated MIB Replacement
OLD-CISCO-APPLETALK-MIB RFC1243-MIB
OLD-CISCO-CHASSIS-MIB ENTITY-MIB
OLD-CISCO-CPUK-MIB To be decided
OLD-CISCO-DECNET-MIB To be decided
OLD-CISCO-ENV-MIB CISCO-ENVMON-MIB
OLD-CISCO-FLASH-MIB CISCO-FLASH-MIB
OLD-CISCO-INTERFACES-MIB IF-MIB CISCO-QUEUE-MIB
OLD-CISCO-IP-MIB To be decided
OLD-CISCO-MEMORY-MIB CISCO-MEMORY-POOL-MIB
OLD-CISCO-NOVELL-MIB NOVELL-IPX-MIB
OLD-CISCO-SYS-MIB (Compilation of other OLD* MIBs)
