New and Changed Information
Cisco H.323, Version 2, Phase 2
Platforms: Cisco 7200 series routers
Cisco H.323 Version 2, Phase 2 upgrades Cisco IOS software by adding several optional features of the
H.323 Version 2 specification and facilitates customized extensions to the Cisco Gatekeeper.
Cisco H.323 Version 2, Phase 2 adds the following benefits to Cisco H.323 gatekeepers, gateways, and
proxies:
• H.323 Version 2 Fast Connect enables endpoints to establish media channels for audio exchange
without waiting for a separate H.245 connection to be opened.
• H.245 tunneling enables H.245 messages to be encapsulated within Q.931 messages using H.225
(using Fast Connect) without the use of a separate H.245 TCP connection.
• H.450.2 Call Transfer (without consultation) and H450.3 Call Deflection provide a limited subset
of features to support Internet call waiting.
• H.235 security allows only duly authorized and authenticated gateways to access Gatekeeper
resources.
• Translation of Foreign Exchange Station (FXS) hookflash to H.245 user input along with the
previously suggested translation of H.245 user input to Foreign Exchange Office (FXO) hookflash
provides end-to-end hookflash relay in FXS-to-FXO configurations.
• Gatekeeper Transaction Message Protocol (GKTMP) for the Cisco Gatekeeper with a
corresponding user API for the UNIX environment, allows a third party to develop elements to
control and utilize a Gatekeeper for applications beyond what is directly supported in Cisco IOS
Release 12.1(1)T.
• Cisco Gatekeeper supports the Gatekeeper MIB, which allows SNMP management.
• Gateway support for the Alternate Endpoint field in Advanced Communications Function (ACF)
enables third-party gatekeepers to provide more robust call establishment.
• Gateway support for network-based billing number on a per-interface basis enables third-party
gatekeepers to obtain per-call interface usage information for billing or other purposes.
• Gateway support for the voice-port description enables third-party gatekeepers to obtain
customer-specific, per-call interface usage information for billing or other purposes.
COPS for RSVP
Platforms: Cisco 7200 series and Cisco 7500 series routers
Common Open Policy Service (COPS) is a protocol for communicating network traffic policy
information to network devices. Resource Reservation Protocol (RSVP) is a means for reserving
network resources—primarily bandwidth—to guarantee that applications transmitting end-to-end
across the Internet will perform at the desired speed and quality. Combined, COPS with RSVP gives
network managers centralized monitoring and control of RSVP, including the ability to:
• Ensure adequate bandwidth and jitter and delay bounds for time-sensitive traffic such as voice
transmission
• Ensure adequate bandwidth for multimedia applications such as video conferencing and distance
learning
• Prevent bandwidth-hungry applications from delaying top-priority flows or harming the
performance of other applications customarily run over the same network
