49
Release Notes for Cisco 7000 Family for Cisco IOS Release 12.1 T
78-10811-05
New and Changed Information
interfaces. Prior to this release, IP addresses for LAN interfaces were obtained using BOOTP during
the AutoInstall process. The AutoInstall Using DHCP for LAN Interfaces feature also enables the
routing device to recognize IP address allocation messages coming from regular BOOTP servers,
providing a seamless transition for those devices already using BOOTP servers for AutoInstall.
Additionally, this feature enables uploading of configuration files using unicast TFTP.
CEF Switching for Routed Bridge Encapsulation
Platforms: Cisco 7200 series routers
The CEF Switching for Routed Bridge Encapsulation feature adds Cisco Express Forwarding (CEF)
switching support to ATM routed bridge encapsulation (RBE). Prior to this release, ATM RBE
supported only fast switching and process switching.
The ATM RBE feature is used to route IP over bridged RFC 1483 Ethernet traffic from a stub-bridged
LAN.
Cisco 7200-I/O-GE+E and Cisco 7200-I/O-2FE/E Input/Output Controllers
Platforms: Cisco 7200 VXR routers
The Cisco 7200-I/O-GE+E is an Input/Output controller that provides one Gigabit Ethernet and one
Ethernet port. It is equipped with a GBIC receptacle for 1000 megabits per second (Mbps) operation
and an RJ-45 receptacle for 10 Mbps operation.
The Cisco 7200-I/O-2FE/E is an Input/Output controller that provides two autosensing Fast Ethernet
ports and is equipped with two RJ-45 receptacles for 10/100 Mbps operation.
I/O controllers support the following features:
• Dual EIA/TIA-232 channels for local console and auxiliary ports
• NVRAM for storing the system configuration and environmental monitoring logs
• Two PC card slots that hold Flash Disks or Flash memory cards for storing the default Cisco IOS
software image
• Flash memory for storing the boot helper image
• Two environmental sensors for monitoring the cooling air as it enters and leaves the chassis
Cisco Quality of Service Device Manager 2.0 Support
Platforms: Cisco 7100 series, Cisco 7200 series, and Cisco 7500 series routers with VIP
Cisco Quality of Service Device Manager (QDM) is a web-based Java application with which users can
configure and monitor advanced IP-based Quality of Service (QoS) functionality within Cisco routers
using a graphical user interface (GUI).
QDM 2.0 is available as a separate product download and is free of charge. If you would like to install
or reinstall QDM, see the Release and Installation Notes for Cisco Quality of Service Device Manager
2.0 on Cisco.com and the Documentation CD-ROM.
