Table Of Contents
- Cisco MDS 9000 Family Release Notes for Cisco MDS NX-OS Release 5.2(8c)
- Contents
- Introduction
- Components Supported
- MDS 9000 Chassis and Module Support
- Software Download Process
- Determining the Software Version
- Determining Software Version Compatibility
- Downloading Software
- Selecting the Correct Software Image for an MDS 9100 Series Switch
- Selecting the Correct Software Image for an MDS 9200 Series Switch
- Selecting the Correct Software Image for an MDS 9500 Series Switch
- NPE Software Images
- Upgrading Your Cisco MDS NX-OS Software Image
- Downgrading Your Cisco MDS SAN-OS Software Image
- New Features in Cisco MDS NX-OS Release 5.2
- New Features in Cisco MDS NX-OS Release 5.2(8c)
- Cisco MDS NX-OS Release 5.2(8c) is a maintenance release that includes bug fixes. It does not include new features.
- New Features in Cisco MDS NX-OS Release 5.2(8b)
- New Features in Cisco MDS NX-OS Release 5.2(8a)
- New Features in Cisco MDS NX-OS Release 5.2(8)
- New Features in Cisco MDS NX-OS Release 5.2(6b)
- New Features in Cisco MDS NX-OS Release 5.2(6a)
- New Features in Cisco MDS NX-OS Release 5.2(6)
- New Features in Cisco MDS NX-OS Release 5.2(2d)
- New Features in Cisco MDS NX-OS Release 5.2(2a)
- New Features in Cisco MDS NX-OS Release 5.2(2)
- New Features in Cisco MDS NX-OS Release 5.2(1)
- New Hardware in Cisco MDS NX-OS Release 5.2(1)
- Licensed Cisco NX-OS Software Packages
- Deprecated Features
- Limitations and Restrictions
- SME Quorum
- OUI Mismatch for SME Tape Targets
- FCIP Performance Drop
- FCoE Module
- IPv6
- User Roles
- Schedule Job Configurations
- Maximum Number of Zones Supported in Interop Mode 4
- InterVSAN Routing
- Java Web Start
- VRRP Availability
- Using a RSA Version 1 Key for SSH Following an Upgrade
- CFS Cannot Distribute All Call Home Information
- Availability of F Port Trunking and F Port Channels
- Reserved VSAN Range and Isolated VSAN Range Guidelines
- Applying Zone Configurations to VSAN 1
- Running Storage Applications on the MSM-18/4
- RSPAN Traffic Not Supported on CTS Ports on 8-Gbps Switching Modules
- I/O Accelerator Feature Limitations
- Support for FCIP Compression Modes
- Saving Copies of the Running Kickstart and System Images
- Configuring Buffer Credits on a Generation 2 or Generation 3 Module
- Features Not Supported on the Cisco MDS 9148 Switch
- PPRC Not Supported with FCIP Write Acceleration
- Configuring a Persistent FCID in an IVR Configuration with Brocade Switches
- Caveats
- Related Documentation
- Obtaining Documentation and Submitting a Service Request
31
Cisco MDS 9000 Family Release Notes for Cisco MDS NX-OS Release 5.2(8c)
OL-27554-07
Deprecated Features
Deprecated Features
Cisco MDS NX-OS Release 5.2 no longer supports the features listed in the following sections:
• Zoning Features, page 31
• SNIA Common Information Model, page 31
• IVR Non-NAT Mode, page 31
Zoning Features
LUN zoning, read-only zones, and broadcast zones are no longer supported. These features affect the
following hardware:
• Cisco MDS 9000 8-port 10-Gbps Fibre Channel over Ethernet (FCoE) module
• Cisco MDS 9000 48-port 8-Gbps Advanced Fibre Channel Switching module
• Cisco MDS 9000 32-port 8-Gbps Advanced Fibre Channel Switching module
You cannot bring up these modules if these features are already configured. You should completely
remove all configurations that include these features before you attempt to bring up these modules. In
addition, you cannot configure these features after you bring up these modules.
SNIA Common Information Model
SNIA Common Information Model (CIM or cimserver) commands are no longer supported. CIM is
supported in Cisco DCNM-SAN Release 5.2. The SMI-S agent that is installed on the Cisco
DCNM-SAN server allows external application to access fabric and switch profiles as specified in SNIA
CIM. For additional information, see the Cisco DCNM Release Notes, Release 5.2.
IVR Non-NAT Mode
IVR non-NAT mode is not supported in Cisco NX-OS Release 5.2(x). If you have IVR non-NAT mode
configured, see the “Upgrading Guidelines Specific to NX-OS Release 5.2(8c)” section on page 15 for
instructions on how to migrate to IVR NAT mode before upgrading to Cisco NX-OS Release 5.2(8).
Limitations and Restrictions
This section lists the limitations and restrictions. The following limitations are described:
• SME Quorum, page 32
• OUI Mismatch for SME Tape Targets, page 32
• FCIP Performance Drop, page 33
• FCoE Module, page 33
• IPv6, page 33
• User Roles, page 33
• Schedule Job Configurations, page 33
