Chapter 4 Replacing Hardware Components
Installing or Replacing Server Components
Figure 4-10 PCIe Riser card Retainers (Slot 5 on PCIe Riser 2 Shown)
1 2 3 4
331850
1 Long card retainer 
(on riser 2, slot 5 only)
3 Securing clip on hinged card retainer
2 Card socket on riser 4 Hinged card retainer
Related Documentation
For more information, see “Replacing a PCIe Card” in the Cisco UCS C240 Server Installation and
Service Guide. Topics include:
• Special Considerations for Cisco UCS Virtual Interface Cards
• RAID Controller Card Cable Routing
• Installing Multiple PCIe Cards and Resolving Limited Resources
Replacing Additional Hardware Components (Related Documentation)
For instructions to replace additional hardware components, refer to the following documentation:
• Cisco Connected Safety and Security UCS C220: “Installing or Replacing Server Components” in
the Cisco UCS C220 Server Installation and Service Guide.
• Cisco Connected Safety and Security UCS C240: “Installing or Replacing Server Components” in
the Cisco UCS C240 Server Installation and Service Guide.
Note The Cisco Connected Safety and Security UCS series servers support a sub-set of the hardware and
features available in the Cisco UCS series servers. Review the information in this document carefully,
including the “Overview” section on page 1-1.
This documentation includes the following topics:
• Replacing Hard Drives
• Replacing Fan Modules
• Replacing a PCIe Card
• Replacing Power Supplies
