4-5
Cisco CSS UCS Platform Series User Guide, CPS-UCS-1RU-K9 / CPS-UCS-2RU-K9
Chapter 4 Replacing Hardware Components
Preparing for Server Component Installation
c. Tighten the captive thumbscrew that secures the rear edge of the cover to the chassis.
Figure 4-2 Removing the Top Cover: Cisco Connected Safety and Security UCS C240
1
2
4
3
331832
1 Front cover panel 3 Rubber finger pads (two)
2 Release button 4 Captive thumbscrew
