Chapter 3 Installing the Server
Installing the Cisco Connected Safety and Security UCS C240 Server In a Rack
Figure 3-8 Reversing the Cable Management Arm
Orientation for mounting to left slide rail
Orientation for mounting to right slide rail
3
3
1
1
2
2
4
4
50826
1 “TOP” stamp on CMA arms 3 Inner CMA tab attaches to CMA arm closest
to server
2 Captive thumbscrews on CMA arms 4 Outer CMA tab attaches to CMA arm farthest
from serv
er
