Chapter 3 Installing the Server
Installing the Cisco Connected Safety and Security UCS C240 Server In a Rack
Figure 3-6 Inserting the Server Into the Slide Rails
1
2
3
4
330534
1 Inner rail on server 3 Slide rail assembly on rack post
2 Slide rail locking clip 4 Right-front rack post
Step 3 Optional–If you want to install the cable management arm, continue with Installing the Cable
Management Arm (Optional), page 3-12.
