Chapter 1 Overview
System Overview
Summary of Cisco Connected Safety and Security UCS C240 Server Features
Table 1-3 lists a summary of server features.
.
Ta b l e 1-3 Cisco Connected Safety and Security UCS C240 Server Features
Chassis Two rack-unit (2RU) chassis.
Processors Two Intel Xeon E5-2600 Series processors.
Memory 8 BG of internal memory (DIMM
1
).
See the “DIMM Memory Configuration” section on page 1-20.
Baseboard
management
Pilot III BMC, running Cisco Integrated Management Controller (CIMC)
firmware.
• The CIMC can be accessed only through the 1Gb Ethernet dedicated
management port.
• See the “Cisco Integrated Management Interface (CIMC)” section on
page 1-22.
Network and
management I/O
The server provides these connectors:
• One 1-Gb Ethernet dedicated management port
• Two 1-Gb Base-T Ethernet LAN ports
Note Only LAN1 and LAN2 ports are supported (referred to as “Eth 0” and
“Eth1” in the Cisco Connected Safety and Security applications, such as
Cisco Video Surveillance). The LAN3 and LAN4 ports are not supported.
• One RS-232 serial port (RJ-45 connector)
• One 15-pin VGA
2
connector
• Two USB
3
2.0 connectors
• One front-panel KVM connector that is used with the included KVM cable,
which provides two USB, one VGA, and one serial connector.
Power Two 650 W power supplies are supported, including 1+1 redundancy (the 1200 W
is not supported). Do not mix power supply types in the server.
See Power Specifications, page A-4.
Cooling Six hot-swappable fan modules for front-to-rear cooling.
PCIe I/O Five horizontal PCIe
4
expansion slots on two risers.
See Replacing a PCIe Card, page 4-13 for specifications of the slots.
