User's Guide

1-2
Cisco CSS UCS Platform Series User Guide, CPS-UCS-1RU-K9 / CPS-UCS-2RU-K9
Chapter 1 Overview
System Overview
System Overview
Refer to the following topics for an overview of the supported server models and features.
Note The Cisco Connected Safety and Security UCS series servers support a subset of the features available
on the Cisco UCS series servers.
• Server Model Comparison, page 1-2
• Cisco Connected Safety and Security UCS C220 (1RU) Overview, page 1-2
• Cisco Connected Safety and Security UCS C240 (2RU) Overview, page 1-6
Server Model Comparison
The Cisco Connected Safety and Security UCS series servers are available in a 1RU and 2RU
configuration and include the following features:
Ta b l e 1-1 Supported Hardware Feature Comparison
Feature
Cisco Connected Safety and Security UCS C220
(C
PS-UCS-1RU-K9)
Cisco Connected Safety and Security UCS C240
(CPS-UCS-2RU-K9)
Form-Factor 1 RU 2 RU
Processor Single E5-2609 CPU Dual E5-2620 CPUs
Memory 8GB,DDR3,1600-MHz RDIMM, PC3-12800 8GB/processor,DDR3,1600-MHz RDIMM,
PC3
-12800
I/O Hub Patsburg Patsburg
PCIe Riser cards Only Riser1 and PCIe slot 1 are supported Both Riser 1 and Riser 2 are supported.
Both PCIe slot1 and slot 2 are supported.
HDD 4 large form factor (LFF) drives
(3.5” hard drives)
12 LFF drives
(3.5” hard drives)
Note The supported features described in Table 1-1 are a sub-set of the features supported by the Cisco UCS
platform.
Cisco Connected Safety and Security UCS C220 (1RU) Overview
The Cisco Connected Safety and Security UCS C220 (1RU) is a 1RU server available in the large form
factor (LFF) only, which supports up to four 3.5-inch hard drives.
Note The small form-factor (SFF) version of the Cisco Connected Safety and Security UCS C220 is not
supported for Cisco Physical Security applications.
• Cisco Connected Safety and Security UCS C220 Front Panel, page 1-3
