DescriptionColumn (Field
The percentage of time the interval that agents have spent
in Wrap-up state after incoming or outgoing tasks in relation
to LoggedOnTime or interval, whichever is less.
% Wrap Up
Derived from: (Skill_Group_Interval.WorkReadyTime +
Skill_Group_Interval.WorkNotReadyTime) /
Skill_Group_Interval.LoggedOnTime)
The percentage of time the interval that the agents of this
skill group spent in busy other state.
% Busy Other
Derived from: (Skill_Group_Interval.BusyOtherTime /
Skill_Group_Interval.LoggedOnTime)
Report Summary: There is a summary for each Enterprise Skill Group Name and a total report
summary. See About Report Summaries (page 200).
Available Fields in the Enterprise Skill Group Historical All Fields Grid View
Available fields for this report include the fields that display by default as Current. Additional
Available fields in this report are derived from the Skill_Group_Interval table as documented
in the Database Schema Guide (http://www.cisco.com/en/US/products/sw/custcosw/ps1844/
prod_technical_reference_list.html)..
One exception is Enterprise Skill Group, which is derived from:
Enterprise_Skill_Group.EnterpriseName.
Most fields but one take their value directly from the database.
Exceptions are the FTE Agent State fields. These are calculated based on how you have
configured interval reporting. For example, FTE Agents Active is derived from:
(Skill_Group_Interval.TalkTime / 1800) or from (Skill_Group_Interval.TalkTime / 900)
Sample Enterprise Skill Group Historical All Fields Report
This illustration is a sample of the report generated from the Enterprise Skill Group Historical
All Fields template.
Figure 58: Enterprise Historical Skill Group All Fields Report 1 of 3
Report Template Reference Guide For Cisco Unified Intelligence Center Release 8.0(4)
147
Chapter 8: Unified CCE Release 8.x Enterprise and Peripheral Skill Group Reports
Enterprise Skill Group Historical All Fields
