Appendix 1: Configuration Details
This appendix summarizes the configuration required for the VCS Control and VCS Expressway. It is broken down into
3 sections:
■ VCS Control (configuration to apply to the VCS Control only)
■ VCS Expressway (configuration to apply to the VCS Expressway only)
■ VCS Control and VCS Expressway (configuration to apply to both the VCS Control and VCS Expressway)
VCS Control Configuration Details
Configuration item Value VCS page
System configuration
System name VCSc System > Administration
LAN1 IPv4 address 10.0.0.2 System > Network interfaces > IP
IPv4 gateway 10.0.0.1 System > Network interfaces > IP
LAN1 subnet mask 255.255.255.0 System > Network interfaces > IP
DNS server address 1 10.0.0.11 System > DNS
DNS server address 2 10.0.0.12 System > DNS
DNS Domain name internal-domain.net System > DNS
DNS System host name vcsc System > DNS
NTP server 1
pool.ntp.org
System > Time
Time zone GMT System > Time
Protocol configuration
SIP domain name example.com Configuration > Domains
Traversal zone
Zone Name TraversalZone Configuration > Zones > Zones
Zone Type Traversal client Configuration > Zones > Zones
Protocol SIP port 7001 Configuration > Zones > Zones
Protocol H.323 port 6001 Configuration > Zones > Zones
Location Peer 1 address 192.0.2.2 Configuration > Zones > Zones
Authentication username exampleauth Configuration > Zones > Zones
Authentication password ex4mpl3.c0m Configuration > Authentication > Devices > Local
database
Traversal search rule
Rule name Traversal zone search rule Configuration > Dial plan > Search rules
Description Search traversal zone (VCS
Control)
Configuration > Dial plan > Search rules
