4. Configure the fields as follows:
Field name Value
Rule name
Enter DNS zone search rule for example
Description
Enter Search DNS zone (external calling) for example
Priority
150
Protocol Any
Source All zones
Request must be authenticated No
Mode Alias pattern match
Pattern type Regex
Pattern string
Enter (?!.*@example\.com.*$).*
Pattern behavior Leave
On successful match Continue
Target DNSZone
State Enabled
5. Click Create search rule.
36
Cisco VCS Expressway and VCS Control - Basic Configuration Deployment Guide
Routing Configuration
