■ The order in which the peers in the remote VCS cluster are listed here does not matter.
■ Whenever you add an extra VCS to a cluster (to increase capacity or improve redundancy, for example) you
will need to modify any VCSs which neighbor to that cluster to let them know about the new cluster peer.
Task 11: Configuring Traversal Zone Search Rules
To create the search rules to route calls via the traversal zone.
1. Go to Configuration > Dial plan > Search rules.
2. Click New.
3. Configure the fields as follows:
 VCS Control VCS Expressway
Rule name "Traversal zone search rule" for
example
"Traversal zone search rule" for
example
Description "Search traversal zone - VCSe" for
example
"Search traversal zone - VCSc" for
example
Priority 100 100
Protocol Any Any
Source Any Any
Request must be
authenticated
No No
Mode Any alias Any alias*
On successful match Continue Continue
Target Traversal zone Traversal zone
State Enabled Enabled
*This example routes any alias across the traversal zone towards the VCS Control. You can be more selective
by adding search rules or configuring call policy.
4. Click Create search rule.
