■ If an H.323 or a non-encrypted connection is also required, a separate pair of traversal zones must be
configured.
To configure the traversal zone:
1. Go to Configuration >Zones > Zones.
2. Click New.
3. Configure the fields as follows. Leave all other fields with default values:
VCS Control VCS Expressway
Name
Enter TraversalZone Enter TraversalZone
Type Traversal client Traversal server
Username
Enter exampleauth Enter exampleauth
Password
Enter ex4mpl3.c0m
Not applicable
H.323 Mode On On
H.323 Protocol Assent Assent
H.323 Port
Enter 6001 Enter 6001
H.323 H.460.19 demultiplexing mode Not applicable Off
SIP Mode On On
SIP Port
Enter 7001 Enter 7001
SIP Transport TLS TLS
SIP TLS verify mode Off Off
SIP Accept proxied registrations Allow Allow
Location Peer 1 address
Enter 192.0.2.2
Not applicable
4. Click Create zone.
