Installation Guide
Table Of Contents
- Cisco Security Manager 4.3 UCS Server Bundles Quick Start Guide
- Contents
- Product Description
- Deployment Mode-Standard Only; No HA or DR
- Steps to Get Up and Running with Cisco Security Manager
- BIOS Setup, OS Tuning, and Security Manager Tuning (these were done by Cisco before shipment of the Bundle to you)
- Performance Parameters
- Updates and Service Packs for Windows
- Patches and Service Packs for Security Manager
- Usernames and Passwords
- Windows Activation, Product Key, and EULA
- Windows Drivers for the UCS Server
- Updates and Service Packs for the UCS Server
- Cisco Security Manager License
- IP Address and Hostname
- Recovery Media and Recovery Procedure
- If You Need to Return Your Bundle to Cisco
- Related Documentation
6
Cisco Security Manager 4.3 UCS Server Bundles Quick Start Guide
78-21007-01
Updates and Service Packs for Windows
The high-end hardware configuration (24 GB RAM, 7 x 500 GB HDD) provides support for 150 devices.
This configuration is suitable for a medium enterprise deployment. The maximum number (cumulative)
of events per second supported is 10,000 events per second [this value is a 9:1 ratio of syslogs to IPS
SDEE (i.e., 9000 syslog + 1000 SDEE)].
Note Cisco does not recommend (1) attempting to expand the capabilities of the high-end hardware
configuration (24 GB RAM, 7 x 500 GB HDD) by adding licenses or hardware or (2) otherwise
attempting to change the license configuration or hardware or both; the Bundle was tested as shipped.
Updates and Service Packs for Windows
Your new Bundle was shipped to you with current Windows updates installed.
Also, Windows Update was set to “Check for updates but let me choose whether to download and install
them.”
Tip To change the Windows Update setting, select Control Panel > System and Security > Windows
Update > Let me Choose My Settings.
As the administrator of the Cisco UCS Server which forms part of this Bundle, you are responsible for
the necessary updates and service packs for Windows. Cisco does not provide Windows updates or
service packs.
Patches and Service Packs for Security Manager
Your new Bundle was shipped to you with current Cisco Security Manager patches and service packs
installed.
Note Service Pack 1 for Security Manager 4.3 is pre-installed in your new Bundle.
As the admin user of Security Manager installed on this Bundle, you are responsible for the necessary
patches and service packs for Security Manager. Cisco does not install them for you or notify you.
If you have a valid Cisco Service contract, you will be able to upgrade the Cisco Security Manager
software from Version 4.3 to a future version.
Usernames and Passwords
Windows:
• Default Windows username/password: Administrator/cisco@123
• To change the Windows username/password: Follow the procedures published by Microsoft for
Windows Server 2008.
Security Manager admin:
• Default Security Manager admin username/password: admin/cisco@123
