Manual

3-3
Cisco TEO Adapter Guide for SAP Java
OL-24781-02
Chapter 3 Using SAP Java Activities
Defining an SAP Java Activity
Defining an SAP Java Activity
Use the following steps to define an SAP Java Adapter activity in the Process Editor. The property pages
that display depend on the activity. Refer to the appropriate section for instructions on completing the
activity property pages.
Step 1 On the Toolbox pane, navigate to the SAP Java section, click the activity and drag it onto the Workflow
pane.
The Activity Properties dialog box displays.
Note The Required Value icon displayed on a tab or page indicates that the field is required and
is either missing a value or contains an invalid value.
The Insert Wildcard tool displayed next to a text field indicates that you can select a
wildcard to include in the field.
The Reference tool displayed next to a text field indicates that you can select a defined
variable or reference an object within the process. For additional information, see the Tidal
Enterprise Orchestrator Reference Guide.
Step 2 On the General tab, enter the following information:
Step 3 Click the Activity-specific tab and enter the required information. See the appropriate section in this
chapter for instructions on completing the fields on the activity-specific tab.
Step 4 Click the Target tab to specify the process target. You can use the process target or override it and
specify a different target for the specific activity.
Field Description
Display name Name of the activity.
Type Display only. Displays the type of activity.
Description Text description of the activity.
Field Description
Execute on the process target Click this radio button to use the same target that was
specified for the process.
Execute on activity target Click this radio button to indicate that the activity should
execute against a target selected in an activity within the
process. Choose the activity from the drop-down list.
Execute on this target Click this radio button and then click the Browse tool
to launch the Select Target dialog box and choose a
specific target on which to execute the activity.
The targets that display in the Select Target dialog box are
targets already defined in TEO.
To view the properties for the selected target, click the
Properties
tool.
