Reported AsDescriptionType of task
External Out TasksThese are calls initiated by agents from their extension that are placed
off-switch or pass through a voice gateway. Outgoing External Tasks
are always voice tasks.
Outgoing external
Consult, conference out, and transfer out calls are counted as outgoing
external calls if they are placed off-switch or to remote agent extensions
at another site.
Agent-to-Agent dialing is outgoing external for the agent initiating the
call if the call has to be placed off-switch to get to the destination agent.
Data for these calls are stored in the AgentOutCalls fields of the
Agent_Skill_Group_Half_Hour historical database table.
Internal Out TasksThese are calls initiated by agents from their extension to another
extension within the ACD or to another ACD within the network.
Outgoing Internal Tasks are always voice tasks.
Outgoing internal
Consult, conference out and transfer out calls are counted as outgoing
internal calls if they are placed to another device. The device could be
another agent line or any other extensions to the VRU.
Agent-to-Agent calls are outgoing internal for the agent initiating the
call if the destination agent is on the same ACD as the source agent.
Data for these calls are stored in the InternalCalls fields of the
Agent_Skill_Group_Half_Hour historical database table.
Tasks HandledAll calls that are routed by the ACD to the agent.ICM-routed/ACD
calls
Note that Tasks Handled
includes all ACD calls and
Outbound Option calls are considered Unified ICM-routed/incoming
calls.
ICM-routed calls, including
Data for these calls are stored in the CallsHandled fields of the
Agent_Skill_Group_Half_Hour historical database table.
calls that are transferred and
conferenced, and
consultative calls. Tasks
Handled provides a high
level view of routed tasks.
Other report columns such
as Transfer In and Conf Out
provide more details about
how the task was handled.
Transfer InCalls that are transferred to an agent. Both incoming and outgoing calls
can be transferred to an agent.
Transferred in
Data for these calls are stored in the TransferredIn fields of the
Agent_Skill_Group_Half_Hour historical database table.
